Sealey WORKSAFE 9000 Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
REFER TO INSTRUCTIONS
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS.
USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE
DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. INTRODUCTION
Provides respiratory protection when used with filters and
cartridges. Suitable for Sealey Model No's 9001, 9002,
9003, 9004, 9005, 9007, 9008 filters. Accepts filters with
a suitable bayonet fixing. Fitted ergonomic shape ensures
optimal vision. Made from Thermoplastic Rubber. Medium
Type Examination Ref.:
Notified Body:
Notified Body Number:
2. SAFETY
This half mask does not supply oxygen (O
8
the oxygen content is equal to or greater than 19.5% by volume.
The appropriate type of filter should be selected depending on the concentration and type of contaminants.
9
DO NOT use the respirator in environments where the concentration value of contaminants is unknown
8
creating an immediate danger to life or health.
When using the half-mask, you must always wear two filtering pieces.
9
DO NOT use for protection against carbon monoxide.
8
DO NOT modify the mask, or use if damaged.
8
DO NOT use in containers, wells, sewers or in confined spaces without ventilation.
8
DO NOT use the half-mask if facial hair or a beard prevents the mask from sealing.
8
It is unlikely that the requirements for leakage will be achieved if facial hair passes under the face seal.
9
Leave the workplace if the respirator is damaged, breathing is difficult and / or dizziness or nausea occurs.
9
DO NOT use in an explosive environment.
8
Use only in conjunction with CE approved filters in accordance with EN 143:2000 + A1:2006 and / or with
9
cartridge filters in accordance with EN 14387:2004 + A1:2008 standard. The applicable country regulations
have to be followed. In order to get guidelines EN529: 2005 standard (recommendations for selection, use,
care and maintenance) is available).
DO NOT use in an oxygen enriched atmosphere or in an oxygen enriched atmosphere.
8
3. INSTRUCTIONS
3.1. BEFORE USE
Ensure the respirator has all parts: harness and straps, inhalation valves and exhaust, seals etc. Ensure the half mask is in perfect
condition, does not show signs of dirt/cracks/damage/impacts; on any of its elements. DO NOT use if damaged. Ensure all components
are suitable for the intended use. Ensure the two available air-purifying components are of the same type.
3.2. ASSEMBLY
Align the plastic filter adapter with the filter holder on the mask (Fig.1). Press and turn filter all the way to the right (Fig.2). Repeat the
procedure for the other filter.
3.3. FITTING
Adjust the plastic part of the headband (cradle) so that it fits comfortably around your head. Place the plastic cradle over your head so
that the arrow is next to the face drawing (on the cradle) was facing up. Hold the ends of the lower elastic bands with one hand and slide
mask over your face with the other, covering mouth and nose (Fig.3). Grab the ends of the straps, place them on the back of your neck
and connect them together. (Fig.4) Adjust the strap tension, pulling the ends of the straps until a secure and comfortable fit is achieved.
Strap tension can be reduce by pushing the buckle out of the back. To remove the mask, loosen the elastic straps, undo the lower
straps and take it off your head.
3.4. CHECKING THE TIGHTNESS & FIT
3.4.1. Positive Pressure Facelift Check:
Using filters, absorbers and filter absorbers for the half-mask. Cover the exhalation valve with your hand, exhale gently to build up
positive pressure, and make sure that no air leaks were detected. (Fig.5) If there is no leakage a proper fit has been achieved.
© Jack Sealey Limited
HALF MASK - REUSABLE - NO FILTERS
9000
MODEL NO:
0082/1694/079/11/21/0716
Apave Sudeurope sas
0082
) and must be used in a ventilated working environment in which
2
Original Language Version
1. Faceseal: sizes S (ref. TPR601),
M (ref. TPR602), L (ref. TPR603)
2. Inhalation Valves. (ref. FFP615)
3. Exhalation Valve (ref. HMS606).
4. Head straps connected to the
body adjustable and unzipped (ref.
HMS709).
9000 Issue 1 01/05/24
