hooga HG-MSK-03 Instruction Sheet

Red/NIR Face Mask
Instruction Sheet
Specifications
Model Number HG-MSK-03
Color Black
Wavelengths 660nm (Red) and 850nm (near infrared)
Number of LEDs 64 Dual-Chip
Surface Irradiance 60 mW/cm2
Beam Angle 120 degrees
Pulsed Frequencies 73 / 146 / 292 Hz
Rated Power 5W
5V DC
Input Voltage
3000mAh
Battery Capacity
USB Type-C
Charging Port
0.79lbs
Weight
1 year
Warranty
Nogier Frequencies
Dr. Paul Nogier (1908-1996) was a French neurologist who discovered
seven frequencies with which the body's cells naturally vibrate. He
identified these frequencies as harmonics of the musical note D.
According to Dr. Nogier, sickness results when cells, molecules or particles
of matter are out of their normal resonance or vibratory pattern. Applying
these frequencies help the cells to resonate with their natural healthy
vibration. Nogier frequencies together with LED lights act as a trigger to
stimulate the electrical nature of the body.
0.6cm/0.24inch 39.1cm/15.39inch
Controller Functions
USB Out: Connects
the mask to the
controller
USB Type-C:
Charging port
73 Hz: Stimulation of the Body and Nervous System. Resonates with certain parts of the brain
which control metabolism and hormones. Boosts Blood Circulation.
146 Hz: Reduces inflammation and scar tissue. Fights infection. Promotes relaxation by resonating
with the cerebral cortex. Alleviates anxiety. Boosts memory. Improves mood: It is the serotonin
frequency and can treat feelings of sadness and depression. Promotes circulation: When applied
locally, it will cause blood circulation to rush to the treatment location to help reduce pain.
292 Hz: Resonates with Ectoderm: This frequency resonates with the ectoderm, the outermost
tissue that forms skin, glands, nerves, eyes, ears, teeth, brain, and spinal cord. Assists wound
healing, skin and nerve repair. Reduces scar tissue and inflammation. Known as a universal
frequency to try for any condition.
4.88cm/1.92inch
20.7cm/8.15inch
2.48cm/0.98inch
10.38cm/4.09inch
Brightness: Click to cycle through
brightness levels 25% / 50% / 75% / 100%.
Brightness indicator lights will display
along the bottom arc of the screen.
On/Off/Time: Press and hold for 3
seconds to turn on/off. Click to select
time setting 5/10/15/20 min. Button
can also be used to pause/continue
treatment after the timer has been
started.
Pulse: Click to select 73/146/292 Hz
pulsed light. Long press to toggle
between Red/NIR/Both.
