LSD PSK1 Installation

by Portasol
This kit provides a convenient sol-
dering solution for ensuring proper
signal integrity in wire connectors
and other electrical connections.
Manufactured by Portasol, this sys-
tem uses an efficient butane fueled
catalytic heating system that concen-
trates the heat at the soldering tip
for effective and accurate soldering.
The soldering wand has a built-in
igniter and an intensity adjustment
wheel to allow a range of heat adjust-
ment settings from 10 to 60 watts.
SIGNATURE SERIES
The wand uses replaceable tips, flints
and fuel supplies.
Our Portasol Soldering Kit include a 7" butane soldering wand with replacement flints, a
standard 2.4 mm tip (on the wand) a wider 4.8 mm replacement tip, 1 oz of 60/40 solder
Ready to
tackle just
about any-
thing!
Portasol Soldering Kit
Portasol Soldering Kit (without butane)
1-800-445-5218
(308) 235-4645
sales@grisk.com
Compact Soldering Kit
2.4 mm
tip
along with a protective carrying case for all kit components. The case
includes a convenient belt loop so that you can carry the kit with you
for ready access on all your installation jobs. If shipment is within the
United States, the kit will also include a 1.9 oz refill canister of ultra pure
premium butane (54-100 PSK1). If shipped out of the United States,
you will need to order the butane free kit (54-101 PSK2).
DESCRIPTION
Accessories and Replacement Parts page 23.
INSTALLATION,
STAGING & SET UP
4.8 mm tip
PART NO.
LS-54-100
LS-54-101
22
Built-in igniter
in the cap
MODEL
PSK1
PSK2
1-800-523-1227
FAX (308) 235-3561
lsdinc.com
