- Page 1 MiPod Ultra Remote Series 1 User Manual Version 1.0.0...
-
Page 2: Table Of Contents
Contents 1. Safety Precautions............................3 2. Getting Started ..............................4 2.1 Basic Information ............................4 2.2 In the Box ..............................4 2.4 Installation ..............................4 Location ....................................... 4 Securing ....................................... 4 Plumbing ..................................... 5 Wiring ......................................6 Sealing Cedar Panelling ................................7 Installation Checklist ................................... -
Page 3: Safety Precautions
Modification to the internal piping and electrical equipment is not covered under warranty, unless prior written approval from iCoolSport is given. Where required by the Regulatory Authority, all relevant permits, and notices to carry out the work, should be obtained prior to commencing installation of this product. -
Page 4: Getting Started
2.1 Basic Information The MiPod Ultra Remote is a complete package designed to be connected to an external iCoolSport heat pump system. The bath is installed with a pump built in under the step with all internal plumbing already completed. -
Page 5: Plumbing
Plumbing The MiPod Ultra Remote connects externally to an iCoolSport heat pump system through 40mm PVC pressure pipe. The external plumbing is a great place to add in optional extras such as filters and water quality equipment. A drain is fitted to the bath through the floor and its connection is located on the left or right side (depending on how the bath was ordered). -
Page 6: Wiring
The MiPod Ultra Remote requires its internal pump to be wired directly to the pump output of your chosen iCoolSport heat pump for correct operation. The bath must be connected to the heat pumps earth to ensure the bath is correctly bonded to earth for protection. -
Page 7: Sealing Cedar Panelling
This is because the UV will break down these coatings and are very difficult to maintain long term. -
Page 8: Installation Checklist
☐ Cedar Panelling is sealed with a stain. ☐ Plumbing is connected to external filtration and iCoolSport heat pump, in the correct flow direction. ☐ Electrical connections between MiPod Ultra and external iCoolSport heat pump are complete. -
Page 9: First Start
2.4 First Start On first start, the bath may require priming to remove trapped air in the lines. It may take a few starts to push this air out. To help with the process, it is recommended to fill the bath up just below the top return fittings so that water returning into the bath can be seen visually. -
Page 10: Technical Data
3. Technical Data 3.1 Specifications Specification Unit Value Voltage 220-240 Frequency Power 0.43 Run Current Start Current Noise Dimensions (L x W x H) 1550 x 1520 x 1220 Inlet/Outlet 40mm Class 12 Pressure Water connection type Drain 32mm Weight Water Volume Water Temperature Range Notes:... -
Page 11: Dimensions
3.2 Dimensions Outer Inner... -
Page 13: Operation
Under glow and internal water lights on the MiPod Ultra Remote will come on when the pump is turned on. If the pump is connected to an iCoolSport heat pump, lighting will remain on even when the water is at... -
Page 14: Maintenance
6. Maintenance 6.1 Water Quality Never use bromine to maintain water quality in any iCoolSport bath. The use of bromine may result in permanent damage to external equipment. To sanitise the water, there are many options available. It will also depend on external filters and sanitisation equipment that has been installed. -
Page 15: Replacing Internal Parts
Warning: Relevant maintenance must be performed by all relevant certified trades. Do not open this unit without proper licensing in accordance with all local laws and regulations. Warning: Isolate and disconnect all power before opening unit for servicing. To replace any internal parts, please contact iCoolSport directly for information. 7. Troubleshooting Problem...
