Summary of Contents for Tiger LED-NEON-360D
- Page 1 ° COB LED NEON FLEX LED-NEON-360D Version: A1.1...
- Page 2 IP67 DC 24V 360° 3Years 5Years Optical & Electrical Parameters Model No. Voltage Color Lm/m Lm/W 24V DC 2700K LED-NEON-360D-XXXXK 1062 >90 3500K 1158 5500K 1085 Model No. LED QTY (pcs/m) Standard Run Working Temperature Storage Temperature Single color 5000mm -20~+60°C...
- Page 3 Beam Angle: 90.00° Diameter Note: The above two pictures are tested with the sample LED-NEON-360D at 2700K. For more info, please contact sales rep. The error of luminous flux and power is ± 10%; Recommended power supply upon working length...
-
Page 4: Installation
360° LED FLEX Item: Screw (For fixing clips ) Item: Screw ( For fixing grooves ) Dimensions L*W*H: 4*13mm Dimensions: 3*16mm Quantity (5m): Quantity (5m): Optional Optional Free/Optional Free/Optional LED-NEON-GL Item: Silicone Glue Dimensions: 45g/pc Quantity (5m): Free/Optional Optional Profile Drawings (neon + profile) Groove Clip Installation... -
Page 5: Packaging Information
360° LED NEON FLEX Packaging Information Roll up the product Wrap it tightly with PE Put the bag Put the boxes Seal and label Use packing belt film and then put into a into a box; into a carton the carton; to pack. -
Page 6: Attentions Before Installation
360° LED FLEX Warning Do not disassemble or retrofit the light. Do not touch the surface of the light with a sharp object. Do not do live-line working during installation,especially for high voltage product. Do not use any organic chemical solvents. Use neutral glass adhesive to fix this product and it needs to be dried 4 hours in the open environment after operation.
