Summary of Contents for Audiovox CSW5000Q
-
Page 2: Specifications & Package Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS FEATURES INSTALLATION & CONTROL KEYS - 4 CAMERAS - QUAD-VIEW - A/V - 4 CAMERAS SEQUENTIAL SCANNING - AUTOMATIC TRIGGERING SPECIFICATIONS & PACKAGE CONTENTS... -
Page 3: Important Safety Instructions
Important Safety Instructions When using your product, always follow these safety precautions. Use correct input power. Do not expose the product to water or any other liquid. Do not disassemble the product. Take it to a qualified service person when service or repair work is required. - Page 6 4 CAMERAS Select the button (#-1) to display the corresponding camera in full screen mode. QUAD Push the QUAD button (#-2) to see all cameras in one screen. In this mode, the audio will be available only with CA1. Push A/V button (#-3) to see A/V device that is connected to A/V-In terminal(4) 4 CAMERAS SEQUENTIAL SCANNING Push the SCAN button(#-4) to adjust the sequential dwell time.
-
Page 7: Specifications
SPECIFICATIONS .* Video Signal NTSC * Input Power 12V DC ~ 42V DC Input * Connectors 4 Camera In : 4-Pin Mini Din/12V DC Outl 1 A/V In : 2-RCA 2 A/V Out 1) 2-RCA for Recorder (VCR or DVR) 2) 4-Pin Mini Din/12V 1A DC Out for Monitor Control Switch : RJ-11 Power Input &... - Page 8 WARRANTY 90 DAY / 12 MONTH LIMITED WARRANTY AUDIOVOX SPECIALIZED APPLICATION. LLC (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 90 days from the date of original purchase, such defect(s) will be repaired or replaced (at the Company’s option) without charge for parts and repair labor.
