Sony XE-90 Service Manual

oe
Pee
STR
eee oa
US Model
Canadian Model
AEP. Model
E Model
SPECIFICATIONS — | | FUSE REPLACEMENT
Center frequencies
|
If the fuse blows, check the power
60 Hz, 125 Hz, 250 Hz, connection and replace the fuse. If the fuse
500 Hz, 1 KHz, 2 kHz, blows again after replacement, there may be
4 kHz, 8kHz, 16kKHz an internal malfunction. In this case, consult
Boost/cut range +12dB
a a _
your nearest Sony dealer.
Sub woofer cut-off frequency
80 Hz, 120 Hz (at -3 dB)
Output gain: —« to +8dB
or more (cut off slope
| — 12 dB/oct)
Frequency response
10 Hz-50 kHz * odB
AONeHO nese ratio
More than 95 dB
(A-weighted)
Harmonic distortion (at 1 kHz)
Less than 0.008%
Gain 0OdB .
General
Input Line inputs (phono jacks)
| x] ,
Output Line outputs (phono jacks)
x3
Power requirements = |
12 V DC car battery
(negative ground)
Current drain 300mA
Mounting dimensions
178 x 25 x 135 mm (w/h/d)
(74x 1x 5% inches) -
Weight ? Approx. 650 g (1 Ib 7 oz)
la supplied
Mounting hardware (1 set)
Connecting cord (1 set}
- STEREO GRAPHIC EQUALIZER
