42V7 PLASMA PANEL
42V7 PLASMA PANEL
QUICK REFERENCE
QUICK REFERENCE
ALIGNMENT HAND BOOK
ALIGNMENT HAND BOOK
MODELS USING THE 42V7 PANEL
42PC3DVUD
42PM2DS / 2DW
42PM3MVATA / MVHMC / MVMC / MVTA / MVZA
42PM3RV / RV1NC / RVA / RVANC / RVNC / RVS / RVW
42PX3DV / DVA / DVANC / DVAW /
42PX3DVB / DVBNC / DVBW
42PX3DVNC / DVW
42PX3RVMC / RVZA
42PX4DVAZC / DVEA / DW
42PX4MVHTA
42PX4RVHTA / RVMC / RVTA / RVZA
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for LG 42PC3DVUD
Summary of Contents for LG 42PC3DVUD
- Page 1 QUICK REFERENCE ALIGNMENT HAND BOOK ALIGNMENT HAND BOOK MODELS USING THE 42V7 PANEL 42PC3DVUD 42PM2DS / 2DW 42PM3MVATA / MVHMC / MVMC / MVTA / MVZA 42PM3RV / RV1NC / RVA / RVANC / RVNC / RVS / RVW 42PX3DV / DVA / DVANC / DVAW /...
- Page 2 Intentionally left blank (42V7 PANEL) The Following Models use the 42V7 Panel (2006)
- Page 3 42V7 SMPS BOARD ADJUSTMENT POINTS Part Number: 6709V00003A These two voltages are adjustable and should be adjusted to the correct values as indicated by the panel label. Example shown below just above the PWB drawing. Always adjust “Highest to Lowest” voltages. VS and VA adjustment resistors are shown in the drawing below.
- Page 4 42V7 SMPS BOARD ADJUSTMENT POINTS Part Number: EAY32808901 These two voltages are adjustable and should be adjusted to the correct values as indicated by the panel label. Example shown below just above the PWB drawing. Always adjust “Highest to Lowest” voltages. VS and VA adjustment resistors are shown in the drawing below.
- Page 5 42V7 Y-SUS BOARD ADJUSTMENT POINTS...
- Page 6 VSC and –Vy Voltage Adjustment Locations These voltages are Adjustable and should be adjusted to the correct values as indicated by the panel’s voltage label. Example shown in the top right. VSC (VR3) adjustment resistor located top center of the board is shown in the picture below.
- Page 7 42V7 Y-Drive Waveform Test Point Figure 1 shows the Y-SUS PWB with the area of the Waveform TP outlined in the white box. Figure 2 Shows a close-up image of the Y-Drive waveform test point B32. (Fig. 2) Lower Left Hand Side of the Y-SUS PWB (Fig.
- Page 8 42V7 Y-DRIVE WAVEFORM ADJUSTMENT VS, VA, VSC, -Vy should have been completed. See Y-SUS Test Points and Using a Full White Raster, adjust the Set- Adjustments diagram up and Set-dn section of the Y-Drive for locations. waveform. Oscilloscope TP B32 on the “Waveform” TP on the Y-SUS PWB.
- Page 9 42V7 Z-SUS BOARD ADJUSTMENT POINTS...
- Page 10 42V7 Z-SUS PWB ADJUSTMENT POINTS VS, VA, VSC, -Vy should have been completed. Full White Raster 1) Z-Bias TP: Connect DVM across R23. 2) Adjust Z-Bias (VR1) to match the panel’s voltage label. Z Bias Test Point Across R23 Z Bias Adjust Bottom of the Y-SUS Board...
