Summary of Contents for Ridder LogicPower RLP200
- Page 1 Product Manual Ridder LogicPower RLP200 265220EN - V02 - 2014.02 Ridder Drive Systems Lorentzstraat 36-38 3846 AX Harderwijk P.O. Box 360 3840 AJ Harderwijk The Netherlands T +31 (0)341 416 854 F +31 (0)341 416 611 I www.ridder.com E info@ridder.com...
-
Page 2: Table Of Contents
LogicPower RLP200 product manual ........ -
Page 3: Rlp200 Description
The RLP200 is fitted with terminal strips and cable glands to connect the cables. 2.2 RLP200 application The LogicPower RLP200 emergency power supply is used to power and control the Ridder LogicDrive RLD80 or RLD200 drive units with the LogicControl RLC100 control unit in livestock houses and crop stores. -
Page 4: Rlp200 Main Functions
Self-test Integrated self-test feature for checking the condition of the battery pack. The LogicPower RLP200 is activated in the following two situations: ● The 24V DC power supply is interrupted for more than 5 seconds . ● The RLP200 battery is then used to adjust the LogicDrive to a pre-set emergency position with the LogicControl RLC100. -
Page 5: Rlp200 Technical Specifications
2004/108/EC Low Voltage Directive 2006/95/EC 2.5 RLP200 item numbers The LogicPower RLP200 is packaged in a box as a complete set. This box contains the items specified in the table below. Ridder Drive Systems T +31 (0)341 416 854 F +31 (0)341 416 611... -
Page 6: Rlp200 Dimensions
2.6 RLP200 dimensions 3.1 Mounting the RLP200 The LogicPower RLP200 is suitable for wall mounting. You can mount the RLP200 by inserting and tightening 4 screws (up to ø4.5 mm) in the mounting holes, located in the corners of the housing. -
Page 7: Connecting The Rlp200 - Schematic
4.1 Connecting the RLP200 - Schematic Connect the LogicPower RLP200 as shown on the schematic below. This schematic shows a Logic Control RLC102 for controlling two LogicDrives RLD80. If a RLC101 is used, the RLD-2 connections are absent. §4.4 shows a detailed wiring diagram for connecting the RLP200. -
Page 8: Connecting The Rlp200 - Wiring Considerations
4.2 Connecting the RLP200 - Wiring considerations Please note the following points when connecting the LogicPower RLP200: RLP200 ● The RLP200 is powered by the LogicControl RLC100. power supply ● Use a 4-core cable (at least 1.5mm²) to connect the RLP200 to the Cabling RLC100. -
Page 9: Connecting The Rlp200 - Wiring Diagram
4.4 Connecting the RLP200 - Wiring diagram Ridder Drive Systems T +31 (0)341 416 854 F +31 (0)341 416 611 I www.ridder.com... -
Page 10: Using The Rlp200 - Operating The Unit And Normal Operation
5.1 Using the RLP200 - Operating the unit and normal operation The LogicPower RLP200 emergency power supply is equipped with a control button and two status LEDs on the front panel. The control button of the RLP200 has 3 functions: ●... - Page 11 ● Alarm: The LogicPower RLP200 is active as power supply. ● Battery: The battery voltage is in order. ● Alarm: The LogicPower RLP200 is active as power supply. No power is being supplied by the LogicControl RLC100. ● Battery: The battery voltage is too low.
-
Page 12: Using The Rlp200 - Weekly Inspection And Maintenance
● Alarm: The battery alarm is being suppressed (see §5.5). 5.3 Using the RLP200 - Weekly inspection and maintenance Although the LogicPower RLP200 is essentially maintenance free, it is recommended to check the following on a weekly basis: ● The mechanical conditions (e.g. the attachment of the box). -
Page 13: Using The Rlp200 - Battery Test
LED alarm LED starts blinking. If this is the case, make sure the RLP200 is checked more thoroughly and replace the battery pack if necessary. Ridder Drive Systems T +31 (0)341 416 854 F +31 (0)341 416 611... -
Page 14: Using The Rlp200 - Battery Alarm
5.5 Using the RLP200 - Battery alarm When in operation, the LogicPower RLP200 also issues a battery alarm if the battery voltage drops too low. The battery alarm is generated in the following situations: ● If the battery voltage drops below 27.6 V while the battery is charging during normal operation. -
Page 15: Rlp200 Troubleshooting
This section describes possible problems you may encounter and their solutions. If you run into a problem not listed below, please contact your supplier or the manufacturer. Problem 1 The LogicPower RLP200 is generating a battery alarm. Observation 1 The signal LEDs on the front of the RLP200 are showing blink code 9 (see §5.2). - Page 16 www.ridder.com...
