Field Controls EvenAir T21WF Installation And User Manual

Wi
The EvenAir WiFi thermostat controls heating, cooling and AIRFLOW to the sleeping and living
areas in a home and provides remote access to your HVAC system using a smart phone, tablet or
PC. The thermostat is installed in the downstairs living area, a temperature sensor is installed in the
upstairs bedroom area and two modulating dampers are installed to control the airflow to the
living and sleeping area.
The EvenAir thermostat monitors the temperature at the sensor and the temperature at the
thermostat every 2 minutes during heating and cooling calls. If the temperatures are different, the
EvenAir thermostat automatically adjusts the modulating dampers 2% so that more airflow is
directed to the space that needs it for a uniformly comfortable home.
COMPONENTS:
EvenAir T21WF Thermostat
EvenAir TS51 or TS52 Wired Temperature Sensor(s) (sold separately)
EvenAir AMT Type Motorized Damper, With Terminals (sold separately)
READ THESE INSTRUCTIONS CAREFULLY AND COMPLETELY BEFORE PROCEEDING WITH THE INSTALLATION.
This device MUST be installed by a qualified agency in accordance with the manufacturer's installation instructions.The definition of
a qualified agency is: any individual, firm, corporation or company which either in person or through a representative is engaged in,
and is responsible for, the installation and operation of HVAC applicances, who is experienced in such work, familiar with all the
precautions required, and has complied with all the requirements of the authority having jurisdiction.
Installed By:_______________________________________
INSTALLATION AND USER MANUAL
THERMOSTAT WITH AIRFLOW CONTROL
Sleeping
Airflow %
WiFi
Living
Day
Tu
AM
MENU MODE
Fi
Please retain these instructions after installation.
www.fieldcontrols.com
T21WF
R
R
Cool
Set To
Schedule
COOL
Living
SYSTEM
AUTO
FAN
F I
E L
D
C
Phone: _____________________
R
O
N T
R
O L
S
Installation Date: _____________
P/N 780101703 5/22 Rev B
