Summary of Contents for Rugged Radios CS-IPHONE-6P
- Page 1 Smart Device & Intercom System Hookup Using A Phone Call System To Connect With An Intercom I NSTALL ATIO N I NSTR UCTIO N S CS-IPHONE-6P V1.0 - 08/2024...
- Page 2 Note: This guide uses a 6100 Race Intercom, however this cable will work with other Rugged Radios intercoms (696+, STX, 5100 intercoms) Attach the female end of the CS-IPHONE-6P to the AUX port on the intercom (White). Step 2 The 3.5mm male end of CS-IPHONE-6P inserts into the phone’s headphone jack or USB-C audio adapter.
- Page 3 The red and blue marked male ends (interchangeable) of SPLITTER-6P-2-6P each plug into the female ends of a CS-IP- HONE-6P. The CS-IPHONE-6P cable can be connected to the 3.5mm audio jack on the adapter or audio device. Do the same for the other audio device. Each device should have its own adapter and CS-IPHONE-6P cable connected Step 5 Use USB-C to 3.5mm audio adapter cables to hook up to the...
- Page 4 Performance Test Now it's time to test. It’s always best to check performance in an outdoor open area. Turn intercom system (and radio if used). Check system operation and set VOLUME and VOX levels. Some intercoms are live mic so VOX level adjust- ment is not applicable.
