NightSearcher NexSun 2000 Manual

Solar Powered Floodlight
Find a sunny location to install the floodlight.
2 installation methods:
A. Wall Mounted:
1
2
1. Align the mounting bracket with the screws and tighten
the screws.
2. Drill 4 holes in wall and install using expansion screws.
Operating the floodlight:
1. Press the On/OFF button for 1.5 seconds
2. The battery indicator will show the battery status:
Green = >70%
Orange = 30-70%
Red = <30%
PIR Sensor
and battery
status indicator
ON/OFF button
B. Straight pole:
1
2
1. Align the mounting bracket with the screws and tighten
the screws.
2. Use the U-shaped brackets to fix the lamp on the pole.
3. The poles diameter should be Φ60mm.
Supplied with:
1 x Solar floodlight
2 x U shaped brackets
1 x Remote control
and fixings
