Osram INVENTRONICS DALI-2 REPEATER LI Manual

DALI-2 REPEATER LI

Εισαγωγέας: Inventronics Netherlands B.V., Polluxstraat 21, 5047RA Tillburg

Forgalmazó: Inventronics Netherlands B.V., Polluxstraat 21, 5047RA Tillburg

Inventronics Poland Sp. z o.o., Al. Jerozolimskie 94, 00-807 Warsaw, Poland

Inventronics Turkey Teknoloji Ticaret Limited Şirketi, Buyukdere Cad. Bahar Sok. River Plaza No: 13/5 Sisli 34394 Istanbul, Turkey

Uvoznik: Inventronics Netherlands B.V., Polluxstraat 21, 5047RA Tillburg

Inventronics Netherlands B.V., Polluxstraat 21, 5047RA Tillburg

Инвентроникс Нидерландия Б.В., Полукстраат 21, 5047 РА Тилбург
INVENTRONICS is a licensee of ams OSRAM. OSRAM is a trademark of ams OSRAM.
C15129034
EN 61347-2-11
G15129572
EN 55015
www.inventronicsglobal.
EN 61547
23.09.24
2)
1) 3)
1 Control input 3 Service button
31) 33)
2 Mains voltage 4 Feedback LED
32) 34)
Wiring diagram: BASIC mode / Verdrahtungsschema: Betriebsart BASIC
BASIC mode:
Up to 64 ECGs can be switched and dimmed collectively via a DALI application controller.
Dimensions / Abmessungen
Technical Data / Technische Daten
2)
Power Supply
Nominal input voltage
Mains frequency
Max. input current
Total harmonic distortion
Max. inrush current
8)
IN: DA / DA
Inventronics GmbH
Input voltage range
Berliner Allee 65
Current consumption
86153 Augsburg
Germany OUT: DA+ / DA-
com
Output voltage range
DALI Supply current
Short circuit protection
5)
Overcurrent protection
17)
TOUCH DIM
Total wire length
Ambient temperature range t a
Max. case temperature t c
Max. case temperature in fault condition
Insulation type (Power supply / DALI)
LED Indicator / LED Anzeige
4) 6)
Green "flashing"
5 DIP switch
35)
Green "permanent"
6 DALI interface
36)
Yellow "flashing"
Yellow "permanent"
53)
46)
Red "flashing"
Red "permanent"
The DALI-2 Repeater LI was developed exclusively for installation in luminaires. Stand-alone installation (e.g. ceiling installation) is possible using
the ECO CI KIT (EAN: 4008321392091).
The DALI interfaces IN and OUT are isolated from the mains connection. Connecting the DALI OUT interface to an external voltage, especially
the mains voltage, will severely damage the device! The DALI-2 Repeater LI is not cascadable. The device can be operated in four different
operating modes, set by the DIP switch. Additional settings can be made with the T4T software via the DALI IN interface in GROUP mode. The
DALI IN interface is DALI certified in BASIC mode.
Start-up:
1. Set the operating mode using the DIP switch.
2. Connect the components.
3. Switch on the power.
Please note: Changing the operating mode will immediately impact the DALI output. Example: existing configuration in EXTEND mode is over-
written in GROUP mode.
54)
24)
1)
3)
110-230 V
4)
50/60 Hz
5)
20 mA
6)
< 10%
7)
20 A
9)
9,5-22,5 V
10)
< 2 mA
11)
12)
9,5-22,5 V
13)
130 mA
14) 15)
yes
16) 15)
yes
18)
20 m
19)
0..+50ºC
20)
70ºC
21)
110ºC
22) 23)
Basic
37)
38)
Auto configuration active / No driver at DALI output
40) 41)
Status OK, active
42) 43)
Lamp error detected at DALI output
44) 45)
Service mode
Problem at DALI output (overcurrent/short circuit)
48) 49)
No voltage at the control input
25)
Wiring diagram: GROUP mode /
Verdrahtungsschema: Betriebsart GROUP
GROUP mode:
A maximum of 64 DALI-2 ECGs (DT6 or DT8 TW) can be controlled collectively by a higher-level control unit for each DALI-2 Repeater LI. This
significantly reduces the number of subscriber addresses at the higher-level control unit. In addition, up to five DALI-2 sensors (light and presence
sensors) can be connected. These are displayed as a light sensor and a presence sensor at the control input.
Construction site function for checking the wiring:
Short press (<0.5s) the service button to activate service mode (yellow LED) for 5s. Each additional short press switches the connected ECGs
on/off at the output. The connected DALI devices are scanned each time the system is started (mains voltage is applied).
If additional devices are connected at the DALI output, the device must be restarted in order to perform a new scan.
Activate scan manually:
1. Short press (<0.5s) the service button to activate service mode (yellow LED) for 5s.
2. Long press (>3s) with service mode activated (yellow LED) to start a new scan (yellow/green LED flashes).
Reset to factory settings:
1. Short press (<0.5s) the service button to activate service mode (yellow LED) for 5s.
2. Ultra-long press (>10s) with service mode activated (yellow LED) to reset the device to factory settings (LED flashes red/yellow).
Wiring diagram: TOUCH DIM mode /
Verdrahtungsschema: Betriebsart TOUCH DIM
39)
TOUCH DIM mode:
Up to 64 DALI ECGs can be switched and dimmed collectively via a standard pushbutton in TOUCH DIM mode. Option-
47)
ally, the color temperature of DALI DT8 TW devices can be controlled with a pushbutton and upstream diode.
Function:
Short press T1: Switch on/off.
Long press T1: Dim up/down.
Double press T1 when switched on: Save the current brightness as the switch-on brightness.
Double press T1 when switched off: Delete the saved switch-on brightness value.
Long press T2: Change color temperature (warmer/cooler)
26)
27)
28)
50)
52)
51)
