Misakai MTV1301 Owner's Manual

MISAKAI HOME ENTERTAINMENT WARRANTY

We appreciate your purchase of a MISAKAI Home Entertainment product. We take pride in the quality of our products and
have manufactured your new Home Entertainment unit to exacting quality standards. We feel confident that in normal use, it
will provide you with satisfactory performance. However, should you experience difficulty, you are protected under the
provisions of this warranty.
MISAKAI Home Entertainment products are warranted against manufacturing defects in materials and workmanship in
normal use for the following periods from the date of purchase by the original user, and is conditional upon the unit being
installed and used as directed in the instruction manual.
Product
Colour Televisions
Remote Control
B/W Televisions
MISAKAI's obligation under this warranty shall be limited to the repair, including all necessary parts and the cost of the
labour connected therewith, or at our option the exchange of any Home Entertainment product which shows evidence of a
manufacturing defect within the warranty period.
Replacement parts, furnished in connection with this warranty shall be warranted for a period equal to the unexpired portion
of the original equipment warranty.
CUSTOMER OBLIGATIONS
This warranty applies to the product from the original date of purchase at retail. Therefore, the owner must provide a copy of
the original, dated bill of sale. No warranty service will be performed without a bill of sale. Transportation to and from the
service depot is the responsibility of the owner.
WARRANTY EXCLUSIONS
This warranty is extended to MISAKAI Home Entertainment products purchased and used in Canada. This warranty shall
not apply to appearance or accessory items including but not limited to: antenna, cabinet, cabinet parts, knobs, batteries,
connecting cables. This warranty shall, in addition, not apply to damages due to handling, transportation, unpacking, set-up,
installation, customer adjustments that are covered in the instruction book, repair or replacement of parts supplied by other
than the MISAKAI authorized service depot, any malfunction or failure caused by or resulting from abnormal environmental
conditions, improper unauthorized service, improper maintenance, modifications or repair by the consumer, abuse, misuse,
neglect, accident, fire, flood, or other Acts of God, and incorrect line voltage. This Home Entertainment product is only
warranted to the original retail purchaser. This warranty becomes void in the event of commercial or rental use. This
warranty becomes void in the event serial numbers are altered, defaced or removed. MISAKAI reserves the right to make
changes in design or to make additions to or improvements upon this product without incurring any obligation to install the
same on products previously manufactured. The foregoing is in lieu of all other warranties expressed or implied and
MISAKAI neither assumes nor authorizes any person to assume for it any other obligation or liability in connection with the
sale or service of this product. In no event shall MISAKAI or its MISAKAI dealers be liable for special or consequential
damage arising from the use of this product, or for any delay in the performance of this warranty due to cause beyond our
control.
The purchaser may have other rights under existing provincial or federal laws, and where any terms of this warranty are
prohibited by such laws, they are deemed null and void, but the remainder of the warranty shall remain in effect.

HOW TO OBTAIN SERVICE

Should this product require service, you may obtain specific information on how to obtain service by contacting the
MISAKAI Dealer from whom this product was purchased, or by contacting us directly:
PHONE: (905) 940-5089
0EMN01896

ANTENNA/CABLE CONNECTIONS

CAUTION: TO PREVENT ELECTRIC
SHOCK, MATCH WIDE BLADE OF
PLUG TO WIDE SLOT, FULLY
INSERT.
Before plugging the UHF/VHF Rod
Antenna into the ANT(enna). IN jack, check
that the pin is not bent. If it is bent, straight-
en the pin as illustrated, then plug the pin
into the ANT(enna). IN jack.
Bent pin
Cable Plug
(Straight pin)
(Needs to be straightened)
CLOSED CAPTION
This TV can receive C1 and C2 of Caption and Text.
Caption Mode
(1) Characters can be displayed on the TV screen when the received broadcast signal contains the
Caption Signals.
(2) Paint-on mode: Displays input characters on the screen immediately.
Pop-on mode: Once characters are stored in memory, it is displayed all at once.
Roll-up mode: Displays the characters continuously by scrolling (max. 4 lines)
Note: If the CAPTION C1 or C2 is selected but the caption signal is not included, characters will
not be displayed.
Text Mode
(1) Displays the text on the screen by scrolling (max. 7 lines)
(2) If the received broadcast signal does not contain the caption or text signal, no change will
occur.
Labour Parts Picture Tube
1 Year 1 Year 3 Years
90 Days 90 Days —
90 Days 1 Year 1 Year
SONIGEM SERVICE
300 Alden Road
Markham, Ontario
L3R 4C1
FAX: (905) 940-2303
1-800-287-4871
VHF
Antenna
(Not supplied)
UHF
Antenna
(Not supplied)
VHF/UHF Combiner
(Not supplied)
VHF/UHF
Combination Antenna
(Not supplied)
Owner's
Manual

FEATURES

●
Tinted, Bright Black Matrix Picture Tube
●
181 Channel Selection- All VHF/UHF channels plus up to 125 cable channels.
●
PLL Frequency Synthesized Tuning- The latest PLL frequency synthesized electronic tun-
ing system provides free and easy channel selection, and lets you tune directly to any channel
using the channel number buttons (0~9 and +100-key) on the remote control.
●
On-Screen Function Display.
●
Full-Function Remote Control
●
Sleep Timer
●
Closed Caption Decoder- You may view specially labeled (cc) TV programs, movies, news,
prerecorded tapes, etc. with either a dialogue caption or text display added to the program.
●
Auto Shut Off Function- If there is no air signal input from the antenna terminal and no
operation for 15 minutes, the TV will turn itself off automatically.
●
V-CHIP- Enables parents to prevent their children from watching inappropriate material on TV.

PRECAUTION

●
Place your TV in a room with adequate ventilation.
●
Keep your TV set away from sources of direct heat, such as heat registers or direct sunlight.
●
Do not place your TV on soft surfaces, such as rugs or blankets.
●
Leave enough room for air to circulate around the bottom, top and back of the set.
NOTE:CHANNEL SET UP MUST BE COMPLETED BEFORE THE SET WILL FUNC-
TION PROPERLY. SEE INSIDE FOR PROCEDURE.
The serial number of this product may be found on the back of the TV. No others have the same
serial number as yours. You should record the number and other vital information here and retain
this book as a permanent record of your purchase to aid identification in case of theft.
Date of Purchase
Dealer Purchase from
Dealer Address
This Owner's Manual is made of recycled paper.
IF YOU NEED ADDITIONAL ASSISTANCE FOR SET-UP OR OPERATING
AFTER READING OWNER'S MANUAL, PLEASE CALL TOLL FREE
Printed in Malaysia
1-800-287-4871.
L6014QC * * * * *
UHF/VHF Rod
Antenna
ANT.IN
ANT. IN
OR
OR
Notes:
(1) When your TV receives a special effects playback signal (i.e., Search, Slow, Still) from a
VCR's video output channel (CH3 or CH4), your TV may not display the correct caption or
text.
(2) Captions and texts may not match the TV voice exactly.
(3) Interference may cause the closed caption system not to function properly.
(4) The caption or text characters will not be displayed while the menu display or function's dis-
play is shown.
(5) If you see this screen!!
If your TV displays a black box on the screen, this means that your TV is set to TEXT mode. To
clear screen, select CAPTION C1, C2 or CAPTION [OFF].
COLOR TELEVISION
MTV1301
Dealer Phone No.
Model No.
Serial No.
*
Some cable TV systems use scram-
bled signals and require a special con-
verter to receive these channels.
Consult your local cable company.
*
CATV Box
or Satellite Box
(Not supplied)
OUT
IN
From Cable System
or Satellite Antenna
75-ohm
Coaxial Cable
75-ohm
Coaxial Cable
From Cable System
