Keiser 001023B Installation Manual

BOTTOM POWER CONSOLE INSTALLATION GUIDE
PART LIST
1
Power Console with Compressor
SPECIFICATIONS
Power Console Size and Weight
L x W x H: Bottom Power Console
Weight: Bottom Power Console
Footprint: 37 in. x 17.5 in.
Compressor Overview
Motor: 3/4 HP
Air Tank Capacity: 2.5 gallons (9.5 L) total
Machine Capacity: Up to 8 KEISER machines
Pressurized Air Delivery: 100 – 120 psig (6.89 – 8.27 bar)
Air Line: 3/8 in. x 6 ft. (1.83 m) tubing,
Air Outlets:
Lubrication Type: Oil-less (requires no lubrication)
Decibel rating: 61 – 63 dB
Electrical
Power Supply (PoE)
Hub, and Access Point
Voltage: 100-240 V~
Current: 9-5 A
Frequency: 50-60 Hz
© Copyright 2025, Keiser Corporation. All rights reserved.
2
Hub, x2 SSD,
and SATA Y-Cable
Includes Mount Bracket and
Hardware
5
Power Entry Cords
37 in. x 17.5 in. x 22 in.
(940 mm x 445 mm x 559 mm)
157 lbs (72 kgs)
(940 mm x 445 mm)
with 3/8 in. fittings
Left-hand side
• 3/8" Compression Fitting (qty 1)
• 1/4" Quick-disconnect (qty 2)
Right-hand side
• 1/4" Quick-disconnect (qty 3)
Under normal operating conditions,
distance of 39.37 inches (1 m)
Compressor
Confirm compressor model for
operating voltage
Voltage: 115/230 V~
Current: 10/5 A
Frequency: 50/60 Hz
3
Access Point, wireless
Includes Mount Hardware
6
Ethernet Cables - CAT5e
x2 x2
Please refer to the manufacturer's user manuals for
detailed product and safety information regarding the electronic
devices.
IMPORTANT: DO NOT CONNECT OR REDUCE THE
POWER CONSOLE 3/8" AIR LINE TO A 1/4" AIR LINE
SYSTEM. The A400 System is designed for 3/8" air lines
only. Any modifications/reductions may cause performance
issues, including slow resistance increase.
Air Direct-Connect Note: Machines may connect directly
to the 1/4" outlets on the compressor, using the 1/4" quick-
disconnect with 8 mm tubing (supplied with the machines,
7 ft / 2.13 m in length), in place of the 3/8" air supply line.
This is a direct connection, not part of a 1/4" air line system.
Installation of a 3/8" compression nut with plug is required.
Supports up to five machines.
1/4" Quick-disconnects,
8 mm tubing
3/8" Compression Nut
4
Power Supply (PoE)
7
3/8" Air Tubing (6 ft. / 1,829 mm),
Compression Nut, Plug, and Union
Reference the marking plate
on unit for serial number and
specific product information.
with Plug
1
Additional
1/4" Outlets
105518_C
