viveroo One Operating Instructions Manual

Hide thumbs Also See for One:
Table of Contents

Advertisement

Quick Links

Download this manual
1. Notes and Warranty
2. Product data wall mount viveroo one
3. Installing the viveroo free wall mount
Operating instructions
Wall mount viveroo one
REV20240708
.........................2
.........................3
.........................4
.........................5
.........................8
...........................9
................10-12
................13-15
.......................17
................18-20
................21-23

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the One and is the answer not in the manual?

Questions and answers

Related Manuals for viveroo One

Summary of Contents for viveroo One

  • Page 1: Table Of Contents

    3.1 Installation MountingSet (310202/310205) ………….…10-12 3.2 one (410XXX) auf viveroo MountingSet ………….…13-15 3.3 Installation Wallbox PoE (310400) ………….……….17 3.4 one PoE (410XXXPD) on viveroo Wallbox PoE ………….…18-20 3.5 one direct mounting on the wall (mounting without flush-mounted box) …….………21-23 REV20240708...

  • Page 2: Safety Instructions

    (mechanics, fire protection, etc.). If it can be assumed that safe operation is no longer possible, the one must be taken out of service immediately and secured against unintentional operation.

  • Page 3: Warranty

    1.2 Warranty Warranty The warranty period is two years from the date of purchase by the original end customer, unless the device has been repaired or replaced under warranty. In this case, the warranty is valid until the end of the original warranty or six months from the date of repair/ replacement, whichever comes first.

  • Page 4: Technical Data

    2.1 Technical data Kompatibilität The one may only be used in conjunction with a free mounting set or viveroo adapter kit. Commissioning without one of these mounting sets will invalidate the guarantee and warranty. Misuse is prohibited. Maße in mm Dimensions in design panel one for ...

  • Page 5: Product Dimensions


 2.2 Product dimensions iPad mini (6.Gen) Compatible iPad model numbers: A2567, A2568, A2569 iPad 10,2 (9.Gen) Compatible iPad model numbers: A2197, A2200, A2198, A2428, A2429, A2430, A2602, A2603, A2604, A2605 iPad 10,9“ (10.Gen) Compatible iPad model numbers: A2696, A2757, A2777 iPad Pro 11“...
  • Page 6
 2.2 Product dimensions iPad Pro 11“ (2024 M4) Compatible iPad model numbers: A2836, A2837, A3006 iPad Pro 12,9“ / iPad Air 13“ (2024 M2) Compatible iPad model numbers: A1876, A2014, A1895,A1983, A2229, A2069, A2232, A2233, A2378, A2379, A2461, A2462, A2436, A2437, A2764, A2767, A2898, A2899, A2900 iPad Pro 13“...

  • Page 7: Scope Of Delivery

    - PoE adapter Scope of delivery - Installation instructions Inwall MountingSet Inwall - one flush-mounted cavity wall box with installation support plate incl. (310202) until 08/2024 spirit level - Power supply unit (IN: 100-240 Vac, 50/60 Hz 0.8A OUT: 5.2 Vdc)

  • Page 8: Further Information

    2.4 Further information Flush-mounted box: If necessary, the following flush-mounted box can be used for installation in masonry: Masonry flush-mounted box: 1656-21 (black) available separately from Kaiser Elektro GmbH. If necessary, the following flush-mounted box can be used for installation in concrete: Concrete flush-mounted box: 1269-01 (yellow-green) available separately from Kaiser Elektro GmbH.
  • Page 9 3. Mounting the viveroo one wall mount 3.1 Installation MountingSet (310202/310205) 3.2 one (410XXX) on viveroo MountingSet 3.3 Installation Wallbox PoE (310400) 3.4 one PoE (410XXXPD) on viveroo Wallbox PoE 3.5 one direct mounting on the wall (mounting without flush-mounted box)

  • Page 10: Installation Mountingset (310202/310205)

    3.1 Installation Installation MountingSet (310202/310205) For installation in landscape format, drill two adjacent holes in the wall with a centre- to-centre distance of 71 mm, ensuring an installation depth of 75 mm. ! Note: These instructions show installation in a cavity wall (1).
  • Page 11 3.1 Installation Installation MountingSet (310202/310205) Installation with flush-mounted boxes: Fasten the flush-mounted box to the wall using the four cross-head lag screws (7). For other installation situations such as concrete or masonry, please read the notes in these instructions on page 9. Loosen the four screws of the mounting plate...
  • Page 12 Finally, check that the flush-mounted cavity wall box is securely seated in the wall. You have now successfully completed all the steps in section 3.1. If you have any further questions, please do not hesitate to contact our sales team: sales@viveroo.com Page...

  • Page 13: One (410Xxx) Auf Viveroo Mountingset

    3.2 Installation one (410XXX) on viveroo MountingSet These instructions show the installation with flush-mounted box. The one is installed here in landscape format as an example. Fasten the mounting plate using the enclosed screws (10) (countersunk screw 10 mm). First tighten the screws lightly and then use a spirit level to make fine...
  • Page 14 3.2 Installation one (410XXX) on viveroo MountingSet Take the cover (12) of the one and feed the USB cable (11) through the centre (marked orange) of the cover. Guide and fix the cable through the cable duct. The cable should then protrude about 2 cm from the cable duct (14).
  • Page 15 3.2 Installation one (410XXX) on viveroo MountingSet Secure the iPad with the cap (16) and fix it w i t h t h e t w o s m a l l s c r e w s ( 1 7 ) (countersunk screw 6 mm).
  • Page 16 DeepBlack viveroo SuperSilver Be impressed by our colour variations!

  • Page 17: Installation Wallbox Poe (310400)

    Fasten the flush-mounted cavity wall box to the wall using the four cross-head lag screws (3). You have now successfully completed all the steps in section 3.3. If you have any further questions, please do not hesitate to contact our sales team: sales@viveroo.com Page...

  • Page 18: One Poe (410Xxxpd) On Viveroo Wallbox Poe


 3.4 Installation one PoE (410XXXPD) on viveroo Wallbox PoE Loosen the four screws of the mounting plate of the flush-mounted box and remove it. Connect our PoE adapter to your CAT cable and place the adapter in the flush- mounted box so that the USB-C opening of the adapter is facing to the right.
  • Page 19
 3.4 Installation one PoE (410XXXPD) on viveroo Wallbox PoE Connect the USB plug (11) to the PoE adapter in the mounting set, which will later be used to supply power and data to the iPad. Take the cover (12)
  • Page 20 3.4 Installation one PoE (410XXXPD) on viveroo Wallbox PoE Place the iPad (15) in the holder one and connect the USB plug to the iPad. Caution: In this state, the iPad is not yet secured in the cover to prevent it from click falling out.

  • Page 21: One Direct Mounting On The Wall (Mounting Without Flush-Mounted Box)

    3.5 Installation
 one direct mounting on the wall (mounting without flush-mounted box) These instructions show how to mount the one in front of a wall. The one is mounted here in landscape format as an example. You can find a suitable template in the download area on our website.
  • Page 22 3.5 Installation one direct mounting on the wall (mounting without flush-mounted box) Take the cover of the one and feed the USB cable through the centre (marked orange) of the cover. Guide and fix the cable through the cable duct. The cable should then protrude about 2 cm from the cable duct (6).
  • Page 23 3.5 Installation one direct mounting on the wall (mounting without flush-mounted box) Secure the iPad with the cap and fix it with the two small screws (countersunk screw 6 mm). The iPad is now secured and can no longer fall out.
  • Page 24 Operating instructions Wall mount viveroo one Our sales team will be happy to answer any further questions you may have sales@viveroo.com REV20240708...
