Danuser MAC Bucket Operator's Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Read this entire manual. This

safety alert symbol is used

throughout this manual to call your

attention to messages involving

your personal safety and the safety

of others. Failure to follow these

instructions can result in injury or

death.

WARNING

Si no entiende ingles, se prefiere que

busque a alguien que interprete las

instrucciones para usted.

MAC

BUCKET

Owner:

Date Purchased:

Model #:

9MMACBUCK2460613

Manual #:

Operator's Manual

Danuser Machine Company, LLC

500 E. 3rd St.

P.O. Box 368

Fulton, MO 65251

Tel: (573) 642-2246

E-mail: sales@danuser.com

Website: www.danuser.com

Serial #:

Table of Contents

Need help?

Do you have a question about the MAC Bucket and is the answer not in the manual?

Questions and answers

Summary of Contents for Danuser MAC Bucket

Page 1 9MMACBUCK2460613 Manual #: death. Operator’s Manual WARNING Danuser Machine Company, LLC 500 E. 3rd St. P.O. Box 368 Fulton, MO 65251 Si no entiende ingles, se prefiere que Tel: (573) 642-2246 busque a alguien que interprete las E-mail: sales@danuser.com...
Page 2: Letter To Owner/Operator
Danuser assumes no liability for damages resulting from the use of the information contained herein. Danuser reserves the right to revise and improve its products as it sees fit. This manual describes the state of this product at the time of its publication and may not reflect the product in the future.
Page 3: Table Of Contents
Foreword Please read this manual thoroughly! Before you assemble, install, operate, maintain, service, remove, or move your Danuser MAC Bucket, read this manual thoroughly. If there is anything you do not understand, immediately contact your dealer, or call our factory direct at (573) 642-2246. Powered equipment can be dangerous if not assembled, installed, operated, maintained, serviced, removed, or moved properly.
Page 4: Safety
Danuser MAC Bucket. If there is anything in this manual you do not understand, contact your dealer or Danuser. The safe use of this attachment is strictly up to you, the operator.
Page 5 Electrocution can occur without direct contact. • The MAC Bucket must be securely latched to the vehicle. Ensure both locking handles are in the locked position with pins fully seated. An improperly latched MAC Bucket can fall without warning. •...
Page 6 Always use care when operating the MAC Bucket. Most accidents occur because of neglect or carelessness. Safety is a primary concern in the design, manufacture, sale, and use of the MAC Bucket. Danuser confirms to you, our customer, our concern for safety.
Page 7: Decals & Safety Signs
Decals & Safety The MAC Bucket comes equipped with all safety signs in place. Their locations are shown in this section. Read and follow their instructions and ensure their care: Signs • Keep safety signs clean and legible at all times.
Page 8 Decals & Safety Signs (continued) Model No. & Serial No. Location: Hopper, motor end PART NO. CA65 Location: Hopper, motor end PART NO. DIG5 Location: Hopper, motor end WARNING Clean or replace all safety signs if they cannot be clearly read and understood.
Page 9: Specifications
Specifications Operator's Manual Direction Terminology Front Right Left MAC Bucket Height, Grate Lowered (A) 33.5” Height, Grate Open (B) 47” Rear Overall Width (C) 26” Overall Length (D) 77.4” Overall Hopper Length (E) 71.3” Rubber Auger: 615 lb. Weight Steel Auger: 620 lb.
Page 10: Hydraulic Requirements
Pressure and Flow Requirements: • The MAC Bucket is designed to operate up to 24 GPM and up to 3,500 PSI. Hydraulic Fluid Selection Requirements: • Premium grade petroleum-based fluids will provide the best performance.
Page 11: Assembly & Installation
Bucket. The vehicle must be equipped with auxiliary hydraulics and a skid-steer quick attach mount. The use of the MAC Bucket may require the addition of counterweights to ensure the combined weight of the attachment and load does not exceed the rated capacity of your WARNING vehicle.
Page 12 General purpose silicone caulk • Vise grips Hopper Extension STEP 1: Park the vehicle on level ground, and rest the MAC Bucket on a solid, level WARNING surface. STEP 2: Shut off the vehicle, and relieve all hydraulic pressure. Personal protection...
Page 13 Clean the top flange of the MAC Bucket. STEP 8: Run a small bead of silicone caulk on the top flange of the MAC Bucket to create a watertight seal between the MAC Bucket and the hopper extension. STEP 9: With the help of a second person, position the hopper extension onto the MAC Bucket.
Page 14: Operation
MAC Bucket. STEP 1: Ensure the MAC Bucket is properly attached and chutes are removed. WARNING STEP 2: Add material(s) to the hopper. Personal protection...
Page 15 STEP 1: Ensure the MAC Bucket is properly attached. Add dry material(s) to the MAC Bucket. dispensing end of the hopper and liquid to the motor end. WARNING...
Page 16 WARNING If material begins to build up on the sides of the hopper, stop mixing. Safe operation of Rest the MAC Bucket on a solid, level surface, and deactivate all hydraulics. equipment requires the operator’s full attention. Open the safety grate to gain access to the inside of the hopper. (The hinge Avoid distractions such pins on the opposite side should remain engaged to serve as a hinge point.)
Page 17 Operation DANGER Concrete Mixing & Do not operate MAC Bucket without the safety grate in place and securely latched. Dispensing (continued) STEP 4: When mixing is complete, position the vehicle and, if necessary, attach additional WARNING chute(s) to reach the desired dispensing location.
Page 18: Cleaning
Depending upon the material dispensed, it may be necessary to add a cleaner or appropriate releasing agent to aid in cleaning the MAC Bucket. STEP 1: Run the MAC Bucket until all of the material is dispensed from the bucket. DANGER STEP 2:...
Page 19: Removal & Storage
Always Storage store the MAC Bucket in a dry, covered location. STEP 1: Lower the MAC Bucket onto a flat, level surface in an area where children do not DANGER play. STEP 2: Disconnect the hydraulic hoses from the vehicle’s auxiliary hydraulics.
Page 20: Troubleshooting
Check hinge pins fully clear edges of safety grate. Hinge pins not fully engaged Check opposite side pivot point hinge pins are fully engaged. For additional assistance, please call your dealer or contact Danuser direct: Tel: (573) 642-2246 E-mail: sales@danuser.com...
Page 21: Maintenance & Lubrication
Never work under CAUTION equipment supported by hydraulics. Even with the vehicle shut off, When making repairs or servicing the MAC Bucket, use only equipment can suddenly parts that meet the original equipment manufacturer’s drop if controls are standards and requirements.
Page 22: Service
Dead-blow hammer or mallet Replacing Rubber Auger Flighting If MAC Bucket is equipped with rubber flighted auger, the discs should only be replaced when performance has been reduced or material leaks out of the discharge end when the auger DANGER is not rotating.
Page 23: Torque Values Chart
Torque Values Chart Torque Values Chart Bolt Head Identification Bolt Head Identification 10.9 12.9 10.9 12.9 Bolt Size Bolt Size Grade 2 (inches) Grade 5 Grade 8 ASTM A574 (Metric) Class 5.8 Class 8.8 Class 10.9 Class 12.9 in tpi ft.-lb.
Page 24: Parts
Parts WARNING This product can expose you to chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov/product.
Page 25 Parts REF. NO. PART NO. DESCRIPTION QTY. (continued) 230410S Hopper - Service 7637 Klik Pin Assembly 230443 Discharge Rubber Flap 176033 Drive Rivet 176010 Roll Pin (3/16” x 1/2”) 170073 Hinge Pin 11047 Rubber Auger Assembly 11063 Steel Auger Assembly 230450 Safety Grate 246005...
Page 26: Accessories
PN 196056 - 1/2” hoses, 25’ long, with 1/2” flush-face couplers (ISO 16028) on one end to connect to MAC Bucket hoses, and ISO 7241 Series A couplers (compatible with ISO 5675 Pioneer couplers) on the opposite end to connect to tractor rear remotes. Includes bolt-on/ weld-on mounting bracket.
Page 27 This page is intentionally blank.
Page 28: Limited Warranty
Any parts or labor required to repair or replace parts not covered under this warranty will be charged to the customer. Parts repaired or replaced by Danuser are then covered by this warranty only for the remainder of the original warranty as if such parts were original parts.

This manual is also suitable for:

230400 230401
