  • Page 1 Safety and operating instructions Handheld pneumatic pick hammers CP 0111 CHLA, CP 0111 CHIT www.discount-equipment.com...
  • Page 2 We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman, Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto, Power Blanket, Nifty Lift, Atlas Copco, Chicago Pneumatic, Allmand, Miller Curber, Skyjack, Lull, Skytrak, Tsurumi, Husquvarna Target, Stow, Wacker, Sakai, Mi-T-M, Sullair, Basic, Dynapac, MBW, Weber, Bartell, Bennar Newman, Haulotte, Ditch Runner, Menegotti, Morrison, Contec, Buddy, Crown, Edco, Wyco, Bomag, Laymor, EZ Trench, Bil-Jax, F.S.
  • Page 3: Table Of Contents

    Contents CP 0111 CHLA, CP 0111 CHIT ENGLISH Contents Introduction............... 5 About the Safety and operating instructions.
  • Page 4: Introduction

    CP 0111 CHLA, CP 0111 CHIT Safety and operating instructions Introduction Thank you for choosing Chicago Pneumatic brand products. For over a century, the Chicago Pneumatic brand has represented performance and innovation in the pneumatic tool industry. Today the brand is found around the world on a range of pneumatic and hydraulic tools that includes breakers, rock drills, chipping hammers, clay-diggers, picks and busters, scabblers, pumps and a whole lot more.
  • Page 5: Safety Instructions

    Safety and operating instructions CP 0111 CHLA, CP 0111 CHIT > Proper protective boots Safety instructions > Appropriate work overall or similar clothing (not loose-fitting) that covers your arms and legs. To reduce the risk of serious injury or death to...
  • Page 6: Operation, Precautions

    CP 0111 CHLA, CP 0111 CHIT Safety and operating instructions WARNING Ejected insertion tool WARNING Unexpected movements If the tool retainer on the machine is not in a locked The inserted tool is exposed to heavy strains when position, the inserted tool can be ejected with force, the machine is used.
  • Page 7 Safety and operating instructions CP 0111 CHLA, CP 0111 CHIT Select, maintain and replace consumables/ ► WARNING Dust and fume hazard working tools/ other accessories as recommended Dusts and/or fumes generated or dispersed when in the operating and safety instructions. Incorrect...
  • Page 8 CP 0111 CHLA, CP 0111 CHIT Safety and operating instructions WARNING Projectiles WARNING Vibration hazards Failure of the work piece, of accessories, or even of Normal and proper use of the machine exposes the the machine itself may generate high velocity operator to vibration.
  • Page 9 Safety and operating instructions CP 0111 CHLA, CP 0111 CHIT Immediately stop working if the machine ► WARNING Involuntary start suddenly starts to vibrate strongly. Before Involuntary start of the machine may cause injury. resuming the work, find and remove the cause of ►...
  • Page 10: Maintenance, Precautions

    CP 0111 CHLA, CP 0111 CHIT Safety and operating instructions Maintenance, precautions WARNING Machine modification Any machine modification may result in bodily injuries to yourself or others. Never modify the machine. Modified machines ► are not covered by warranty or product liability.
  • Page 11: Overview

    The CP 0111 handheld pneumatic breaker is designed for light- to medium constructions and plant maintentance work. CP 0111 CHLA and CP 0111 CHIT are fitted with a D-handle and can be used both horizontally and vertically. No other use is permitted.
  • Page 12: Installation

    CP 0111 CHLA, CP 0111 CHIT Safety and operating instructions Data plate Installation Hoses and connections Machine type Maximum permitted compressed air pressure Compressed air source Serial number Water separator (optional) The warning symbol together with the book Oiler (optional)
  • Page 13: Connecting A Water Separator

    Safety and operating instructions CP 0111 CHLA, CP 0111 CHIT NOTICE Never cool a hot insertion tool in water, Connecting a water it can result in brittleness and early failure. separator Selecting the right insertion tool Selecting the right insertion tool is a precondition The length of the air hose between the compressor for proper machine function.
  • Page 14: Operation

    CP 0111 CHLA, CP 0111 CHIT Safety and operating instructions Checking for wear on the tool shank Operation WARNING Involuntary start Involuntary start of the machine may cause injury. ► Keep your hands away from the start and stop device until you are ready to start the machine.
  • Page 15: Operating

    Safety and operating instructions CP 0111 CHLA, CP 0111 CHIT Operating Maintenance Regular maintenance is a basic requirement for the Starting a cut continued safe and efficient use of the machine. ♦ Stand in a stable position with your feet well away Follow the maintenance instructions carefully.
  • Page 16: Periodic Maintenance

    CP 0111 CHLA, CP 0111 CHIT Safety and operating instructions If the machine has a vibration-absorbing CP 0111 CHIT ♦ handle/handles, check that it moves freely (up and down) and does not jam. ♦ Change damaged parts immediately. Replace worn components in good time.
  • Page 17: Storage

    Safety and operating instructions CP 0111 CHLA, CP 0111 CHIT If the machine function is still not satisfactory after ♦ this procedure, contact an authorised service workshop. Storage > Clean the machine properly before storage, in order to avoid hazardous substances. See “Dust and fume hazard”...
  • Page 18: Technical Data

    CP 0111 CHLA, CP 0111 CHIT Safety and operating instructions Technical data Machine data Shank Air Consumption dimension Weight Length foot /min Impact freq. Model (mm) Part number (kg) (mm) (Hz) (l/s) CP 0111 CHLA H1 x 4¼ 8900 0001 20 29.9...
