Page 1 Pet Cam Trail WiFi-Direct Version...
Page 2 HERE WE GO... Thank you for choosing our pet cam. With the PetTec Pet Cam Trail you’ll al- ways have your darling in view. Important safety instructions READ ALL INSTRUCTIONS AND WARNINGS IN THIS OPERATING MANUAL BEFORE USING THE PET CAM TRAIL.
Page 3 PRODUCT OVERVIEW I Status-LED Light sensor Camera IR LEDs (2x) (covered) Microphone Motion sensor (PIR) frontal Motion sensor (PIR) lateral (2x)
Page 4: Product Overview
PRODUCT OVERVIEW II The functions shown here are located behind a cover. 2“ LCD monitor Control buttons Direction & Ok Menu Button Start Button On/off switch SD card slot Reset Button Service compartment cover...
Page 5 PRODUCT OVERVIEW III Opening for padlock Screw hole for wall mounting Locking the rear cover USB-C charging port Silicone cover CONTENTS • Pet Cam Trail • USB type-C cable • Mounting strap • Manual • Mounting bracket and screws...
Page 6: Important Instructions
WI-FI DIRECT In contrast to a conventional PetTec Pet Cam with Wi-Fi, neither an access point nor a hot spot are required for data transmission - the Wi-Fi-Direct-capable wildlife camera itself acts as a base station.
Page 7: Getting Started
As a rule, a pop-up notification will now appear at the bottom of the screen. Press it to connect the camera to the app. The camera is connected to the PetTec app via Bluetooth. The camera is permanently connected to the app or your smartphone via Wi-Fi Direct...
Page 8 USE PET CAM TRAIL WITH THE APP Follow these simple steps to use the Pet Cam Trail via Wifi Direct with the Pet Cam app on your smartphone! Make sure that you are within the communication range of Wi-Fi Direct (max.
Page 9 Do not forget: After completing the settings in the app, reactivate the regular Wi-Fi! The Pet Cam Trail is now connected to the app and you can use the live stream or make changes in the settings. If the app is not used, the Pet Cam Trail and PetTec app will automatically...
Page 10: Mounting The Camera
Screw the bracket to the wall and then screw the bracket to the camera (screw hole on the botto, see illustration a few pages before) Important note • Your Pet Cam Trail is a valuable tool for ob- serving animals, so protect it. • Attach a padlock (not supplied) to the ca- mera to secure the camera and the data it contains.
Page 11 OPERATING THE DEVICE I The display With the 2“ LCD display and the cursor keys, you can operate all the important functions on the appliance directly. Device mode Current temperature Video mode Celsius & Fahrenheit Photo mode Resolution Playback mode Settings 05/10/2024 02:15:00:PM...
Page 12: Operating The Device
OPERATING THE DEVICE II The modes When the device starts up, the LCD display is active and you can select the various modes. The modes are selected by repeatedly pressing the button: Video Mode Photo Mode Playback Mode Settings Operation in the modes Video mode •...
Page 13 SETTINGS Overview of the setting functions Press the button several times to access the settings where you can check the factory settings and change them if necessary. • Use the button to scroll through the individual settings. • Select individual options with the or button. •...
Page 14 All images and videos can be accessed via the PetTec app and your smart- phone, provided the Pet Cam Trail is within Wi-Fi Direct range. You will need a micro SD memory card (not supplied) for your camera to function. This stores all recorded images and videos.
Page 15 Inserting and removing the micro SD card • Remove the cover on the back. The service compartment with reset but- ton, on/off switch and micro SD card slot is located at the bottom. Switch off the camera. • INSERT: Insert the card with the metal contacts facing up-wards (see diagram).
Page 16: Détails Techniques
• Detection angle 120° • Triggering speed 0.3 seconds Operation • On the device via LED screen with cursor control • PetTec app for operating all Pet Cams from PetTec Audio • Front microphone • Speaker at the bottom of the housing Dimensions &...
Page 17 Integrated • Battery capacity: 5,600mAh rechargeable battery • Charging via USB tye-C cable via power adapter • Charging via solar panel possible • Battery life (depending on user behaviour): Up to 6 months Power supply • Consumption in automatic mode without activity: approx.
Page 18: Troubleshooting
LED can be found in the Important operating instructions section) • Charge the camera fully until the LED lights up blue permanently. My Pet Cam Trail takes pictures/videos, but without recording anything in the foreground • The camera is controlled by motion sensors. Falling leaves, moving bran- ches or flowing water can trigger the camera.
Page 19: Customer Service
European Economic Area. MANUFACTURER INFORMATION AND SERVICE If you have questions about the PetTec Trail or experience prob-lems using it, first contact us via email at the following address: info@PetTec.de PetTec® is a brand of...
Page 20 Do not dispose of used devices with household trash! If your Pet Cam Trail is no longer usable, each user is obligated by law to dispose of used devices separately from household trash, e.g.
Page 21 Pet Cam Trail WiFi-Direct Version PetTec© ist eine Marke der Stage10 GmbH Leipziger Platz 9 10117 Berlin Germany WEBSITE & SHOP www.PetTec.com INFOS, MANUALS & SUPPORT support.PetTec.de Pet Cam Trail Art No. 16298...
