Reference Ultime Two
Owner's Manual
1
Owner's Manual Stenheim Reference Ultime Two

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Reference Ultime Two and is the answer not in the manual?

Questions and answers

Related Manuals for STENHEIM Reference Ultime Two

Summary of Contents for STENHEIM Reference Ultime Two

  • Page 1 Reference Ultime Two Owner’s Manual Owner’s Manual Stenheim Reference Ultime Two...
  • Page 2 Owner’s Manual Stenheim Reference Ultime Two...
  • Page 3 Owner’s Manual Stenheim Reference Ultime Two...
  • Page 4 Stenheim Reference Loudspeakers Thank you for choosing to entrust your listening pleasure to Stenheim. Here in Switzerland we work hard to bring you a musical experience that will enthral and delight you for many, many years; to bring you your music – live.

  • Page 5: General Safety Instructions

    Information contained in this manual is subject to change without notice. Stenheim Suisse SA has reviewed this manual thoroughly in order that it will be an easy-to-use guide to your Stenheim loudspeakers. All statements, technical information and recommendations in this manual or any related documents are believed reliable.

  • Page 6: Table Of Contents

    Technical Specifications 2. Reference Ultime Two Unpacking Packing List Unpacking Guide Stenheim Castors and Spike Installation Guide 3. Reference Ultime Two SX Unpacking Packing List Unpacking and Assembly Guide Use of Measuring Rod 4. Setup Fine Tuning / Set up...

  • Page 7: The Reference Ultime Two

    The Reference Ultime Two is the most compact speaker in the Reference line. It is designed for large spaces and to front powerful systems; to fill big rooms with dynamic, captivating sound that covers the full bandwidth, providing deep and powerful bass.

  • Page 8: Technical Specifications

    Dimensions: Height 1535mm (60.43”) x Width 368mm (14.49”) x Depth 505mm (19.89”) Dimensions (including Platform): Height 1635-1695mm (64.37-66.73”) x Width 713mm (28.07”) x Depth 573mm (22.56”) Weight: 231kg (509.3lbs) each Weight (including Platform): 266 Kg (586.4 lb) each Owner’s Manual Stenheim Reference Ultime Two...

  • Page 9: Reference Ultime Two Unpacking

    Reference Ultime Two Unpacking Packing List Stenheim Reference Ultime Two Speakers Left Speaker Right Speaker 8x Metal Discs Stenheim Reference Ultime Two Accessories Case 8x Spikes 8x Spikes 8x Washers 8x Metal Discs 2x C-Spanners 1x Swiss Army Knife 1x USB Stick with Selected Tracks and Manuals...

  • Page 10: Unpacking Guide

    Keep the packaging safely to use again should you need to transport your speakers to another location. At least four people are required to unpack your Reference Ultime Two loudspeakers. Do not attempt this job on your own as you risk damaging them.
  • Page 11 You can now lift off the cover you have just unscrewed. Ensure that there is a minimum of 4 people to lift up the cover as straight as possible, so as not to rub it against the cabinet. Owner’s Manual Stenheim Reference Ultime Two...
  • Page 12 Make sure that the 4 castors are aligned in the correct direction, with the castors facing inwards as seen in the picture (right). Lock the castors in this direction with the 2 rubber bands provided. Owner’s Manual Stenheim Reference Ultime Two...
  • Page 13 Remove the strap. Make sure to hold the metallic part so that it doesn’t risk touching the speakers. Step 13: Lastly, you can remove the base of the box from the speaker. One person should take it off while the other holds the speaker. Owner’s Manual Stenheim Reference Ultime Two...
  • Page 14 1 cm off the ground The rubber part dosen't The Castor does not and are unlikely to snag on the touches the ground touch the ground. floor when the speaker is moved. Owner’s Manual Stenheim Reference Ultime Two...

  • Page 15: Stenheim Castors And Spike Installation Guide

    Gently lower the speaker, ensuring that there are at least 4 people to do this. While 3 people keep the speaker tilted, a 4th person should place the 2 Stenheim Metal Discs under the spikes, so that the speaker can be gently placed on them. Use of the Metal Discs is not obligatory.
  • Page 16 4 Stenheim Spikes. The next steps will describe how to adjust the height of your speakers using our Stenheim Spikes system. Step 7: Position the two Stenheim C-Spanners as seen in the picture (right). Owner’s Manual Stenheim Reference Ultime Two...
  • Page 17 Spikes to adjust your speaker height to your preference. Be careful! The maximum height adjustment of each spike is 5mm, because there must be at least 5 mm of thread left in the speaker. Owner’s Manual Stenheim Reference Ultime Two...

  • Page 18: Reference Ultime Two Sx Unpacking

    Reference Ultime Two SX Unpacking Guide Packing List Stenheim Reference Ultime Two Speakers Left Speaker Right Speaker Stenheim Platform 2x Speaker Platforms Speaker Platform Stenheim Platform Accessories - Set 1 1x Technical Descritption Sheet 1x Music CD 1x Strap 1x USB Stick...
  • Page 19 8x M12/20 Screws 1x Product Manual 3x Allen Kyes Stenheim Platform Accessories - Set 3 8x Support Screws 8x Metal Discs 8x Support Screws (f) 8x Metal Discs (g) 8x Castors (h) 8x Castors Owner’s Manual Stenheim Reference Ultime Two...

  • Page 20: Unpacking And Assembly Guide

    Step 3: Remove the screws between the two boxes (shown in red). There are 6 screws in total, 3 on each side. Owner’s Manual Stenheim Reference Ultime Two...
  • Page 21 You can now lift off the lid you have just unscrewed. Ensure that there is a minimum of 4 people to lift up the cover as straight as possible, so as not to rub it against the cabinet. Owner’s Manual Stenheim Reference Ultime Two...
  • Page 22 (as shown in the movie sec. Once you have heard the spike is in the thread, you can quietly screw in the spike clockwise. Owner’s Manual Stenheim Reference Ultime Two...
  • Page 23 Two people should now hold the Platform up while a third threads the bolts through the Platform and screws them into the holes in the bottom of the speaker to hold the Platform in place. Owner’s Manual Stenheim Reference Ultime Two...
  • Page 24 Platform from damage once the pallet is vertical. Step 14: Using three people to lift the speaker and a fourth in front of it to prevent it from sliding forward, lift the speaker into the upright position. Owner’s Manual Stenheim Reference Ultime Two...
  • Page 25 Slide a castor (h) along an arm underneath the Platform towards one of the feet. You will feel it come to a hard stop when it is fully located. Taking one of the short screws (e), screw it into position. Owner’s Manual Stenheim Reference Ultime Two...
  • Page 26 Leave the speakers on the castors until you have found approximately the correct position for the speakers in the room, after which you can do the fine tuning. This will happen once the speakers are standing on their spikes. Owner’s Manual Stenheim Reference Ultime Two...
  • Page 27 Extra-long tipped spikes for penetrating thick carpet. Step 23: Be carefu! The speakers are very heavy, weighing approximately 230 kg each. They will mark the floor over time unless adequate precautions are taken to protect it. Owner’s Manual Stenheim Reference Ultime Two...

  • Page 28: Use Of Measuring Rod

    This will enable you to get the best possible musical performance out of your Ultime Twos in any given room. Owner’s Manual Stenheim Reference Ultime Two...
  • Page 29 Room control - recommended setting: HIGH Flat Response HIGH Boosted Response HIGH Attenuated Response You can switch between flat, boosted and attenuated responses as you wish in order to match the sonic characteristics of your room. Owner’s Manual Stenheim Reference Ultime Two...

  • Page 30: Cabling

    This is due to their compatibility with the type of speaker cable you are using. As a rule of thumb, Stenheim recommends connecting the speaker cables to the right set of binding posts. There may be instances where personal preference in sound rendition leads you to connect to the bass (left) set of connectors instead.

  • Page 31: Break-In Period

    Your speakers should already be performing well, but they will get even better as they break-in. 200 to 300 hours of break-in are recommended for the Reference Ultime Two. After this time, your Reference speakers will have reached their full performance and will not change for many years to come.

  • Page 32: Acoustic Treatment

    (absorbers, diffusers, or bass traps). There are many specialized manufacturers on the market, and it is advisable to consult a room acoustics specialist before purchasing this equipment. Your official Stenheim dealer should be able to help you with this.

  • Page 33: Maintenance

    4.6 Maintenance Your Reference Ultime Two speakers will not require maintenance in normal usage. There is no serviceable part inside. Any attempt to open the speaker by non-authorized personnel will void the warranty. Use only a soft and dry cloth to remove any dust or marks as necessary. Avoid using abrasive or harsh cleaners as they may damage the aluminium finish.

  • Page 34: Warranty Coverage

    3 (three) years. Please note that some products may contain both passive (standard speakers) and active elements (active crossovers, amplifiers). In order for a Stenheim product to be covered by this Extended Warranty, the following conditions shall be met: The original sales receipt, indicating the date and place of purchase and the Dealer's name, must be presented.
  • Page 35 Your music, live Stenheim Suisse SA • Route du Rhône 10 • ZI Botza C3 • 1963 Vétroz • www.stenheim.com Owner’s Manual Stenheim Reference Ultime Two...
  • Page 36 Owner’s Manual Stenheim Reference Ultime Two...

This manual is also suitable for:

Reference ultime two sx
