Summary of Contents for HARDKORR HKPSOLRIN30A
- Page 1 USER MANUAL 30A 12V INLINE SMART SOLAR REGULATOR HKPSOLRIN30A V2.0 - 5.2024...
- Page 2 Our aim is for you to be completely satisfied with your purchase, and therefore your new Hardkorr product is backed by a comprehensive warranty and an outstanding after-sales customer service team.
-
Page 3: Table Of Contents
FREQUENTLY ASKED QUESTIONS WARRANTY INFORMATION DISCLAIMER While caution has been taken to ensure the accuracy of the contents of this guide, Hardkorr assumes no responsibility for errors or omissions. Please note that specifications and product functionality may change without notice. -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY • RISK OF FIRE, EXPLOSION AND BURNS: Working in the vicinity of lead acid batteries is dangerous. Explosive gases can develop during normal battery operation. Be certain there is enough ventilation to release the gasses. Do not smoke when in the vicinity of the battery under charge. -
Page 5: Regulator Overview
OVERVIEW REGULATOR OVERVIEW Layout applies to all In-Line Smart Solar Regulator models. The regulator can be permanently attached to any flat surface using the magnetic mounting plate. The mounting plate can be attached to any flat surface using the four included mounting screws, and the regulator then fastens securely to the plate with the inbuilt magnets. -
Page 6: Specifications
SPECIFICATIONS SOLAR REGULATOR SPECIFICATIONS SPECIFICATIONS 30A SOLAR REGULATOR RATED MAXIMUM CURRENT INPUT VOLTAGE 15-22V LOWEST OPERATING VOLTAGE STANDBY CONSUMPTION MAX VOLTAGE DROP 0.25V START CHARGING VOLTAGE VOLTAGE CONTROL ACCURACY ± 1% BATTERY TEMPERATURE -24mV/°C COMPENSATION CO-EFFICIENT TEMP COMPENSATION RANGE -20°C ~ 50°C INPUT/OUTPUT TERMINALS 50A Anderson connector MATERIALS... - Page 7 INSTALLATION...
- Page 8 INSTALLATION...
- Page 9 INSTALLATION...
- Page 10 INSTALLATION...
- Page 11 INSTALLATION IF DISPLAY DOES NOT TURN ON, CHECK CONNECTIONS.
-
Page 12: Operation
OPERATION REGULATOR SET-UP Please check your battery manufacturer’s specifications to select correct battery type. The unit has charge programs for six different battery types: Lithium Iron Phosphate (LiFePO4), Lithium Titanate Oxide (Li₄Ti₅O₁₂), Gel, AGM, Wet and Calcium. SCREEN NAVIGATION Battery charge state Solar panel connection Display units... -
Page 13: Battery Type Selection
OPERATION BATTERY TYPE SELECTION Ensure the regulator is set up for the correct battery type. Failure to do so may harm the battery. SPECIFICATIONS Calcium LiFePO₄ SOFT START 3-10V ± 0.2V / max 15.0A BULK 10-14V ± 0.2V ABSORPTION 14.4V ± 0.2V 14.7V ±... -
Page 14: Charge Programs
OPERATION CHARGE PROGRAMS This smart regulator has a 6-stage charging algorithm designed charge your battery in a way that suits the status and chemistry of the unit. The regulator automatically cycles through each charge setting, and is able to detect the correct stage to use, no matter what condition your battery is in. DIAGNOSE SOFT START BULK... -
Page 15: Troubleshooting
TROUBLESHOOTING FAULT INDICATORS If the regulator detects an issue in your setup, it will use a range of settings or displays to prompt you. SOLAR MAT FAULTS DISPLAY INDICATION BACKLIGHT SOLAR PANEL WEAK Normal Flash SOLAR PANEL REVERSE CONNECTION Flash Flash SOLAR PANEL OVER VOLTAGE (>... -
Page 16: Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS Q. Can I connect this solar regulator to an existing battery management system / DC-DC charger with solar input? A. If you wish to connect your solar panel via an existing battery management system / DC-DC charger, you'll need to bypass included regulator (on HKP200SOL model). Connect your solar panel directly to the solar input port on your battery management system. -
Page 17: Warranty
(e.g. completing and returning your warranty card if applicable). TO BEGIN A WARRANTY CLAIM: If you believe your Hardkorr product is defective, it must be returned to Hardkorr for inspection by our warranty claims department. - Page 18 DISCONTINUED ITEMS Discontinued items that are still under warranty will be reviewed by Hardkorr. If a discontinued item is covered under warranty it may be replaced by an equivalent or superior item. If an equivalent item is not...
- Page 20 WWW.HARDKORR.COM...
