Summary of Contents for Houston Radar SS300U
- Page 1 SS300U SS300ULG User Manual and Installation Guide K-Band Ultra Low Speed Doppler Speed Sensor Built Types: SS300U-DFT, SS300U-OFD SS300ULG-DFT, SS300ULG-OFD SS300ULG-BHP Rev 3, November 20, 2023 SS300U and SS300ULG in SS300U and SS300ULG Open Frame Version Weatherproof Enclosure SS300U-DFT...
- Page 2 Houston Radar SS300U User Manual Houston Radar LLC 12818 Century Drive, Stafford, TX 77477 Http://www.Houston-Radar.com Email: sales@Houston-Radar.com Contact: 1-888-602-3111 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 3 Houston Radar SS300U User Manual Warning: SS300U-OFD and SS300ULG-OFD radar is supplied in an open frame format with exposed antenna and electronics and thus is a static sensitive device. Please use static precautions when handling. Warranty does not cover damage caused by inadequate ESD procedures and practices.
- Page 4 Houston Radar SS300U User Manual Note: Specifications may change without notice. Note: Not liable for typographical errors or omissions. Page 4 of 22...
-
Page 5: Table Of Contents
Houston Radar SS300U User Manual Table Of Contents INTRODUCTION......................6 INSTALLATION ......................6 : ........................6 OUNTING :...................... 7 IRECTION OINTING SS300U-OFD: ............. 7 ECOMMENDED NCLOSURE FOR THE : .......................... 8 OOKUP Power Input: ....................... 8 Serial Connection: ...................... 8 Measured Speed Output:..................... -
Page 6: Introduction
Advanced DSP based algorithm yields consistent performance and speed detection SS300U features 90+ m (300+ feet) of pickup distance for incoming vehicles on open and level road. SS300ULG is optimized for close up detection of large targets such as trains, conveyor belts and other industrial applications. -
Page 7: Direction Pointing
SS300ULG. Recommended Enclosure for the SS300U-OFD: The SS300U-OFD radar needs to be enclosed in a weatherproof enclosure for outside use. The following needs to be observed for optimal performance: 1. The front face of the radar (with the golden pads) is the antenna and is the face that must point into traffic. -
Page 8: Hookup
5 seconds at a time (startup current is higher as the radar is initializing its internal systems). Serial Connection: The SS300U features an RS232 interface that is used to output speed and configure the unit as explained later in this document. Page 8 of 22... -
Page 9: Measured Speed Output
ON via a bit in the “MD” variable. Measured Speed Output: The SS300U will send out the measured speed via the ASCII interface as a 3 digit speed with an optional direction indicator. The format is: [?,+]nnn[.ddd][\r,\n]... - Page 10 All configuration variables may be accessed via simple ASCII interface. It is described in greater detail in our ASCII interface application note. Please contact Houston Radar for this document. Page 10 of 22...
-
Page 11: Wire Signal Descriptions
Incorrect hookup may result in the output devices being destroyed and will not be covered under warranty. The SS300U features two low impedance outputs that can trigger/turn on an external display/device to bring it out of power saving mode when a vehicle is detected. -
Page 12: Use
(0KPH). Green LED flashes at 1/3 Hz (12.5% duty cycle) rate when radar is running giving a visual OK signal. In the SS300U-OFD version green LED may be installed on the back depending on the requested build option. Page 12 of 22... -
Page 13: Configuring The Unit
Configuring the Unit: The unit’s internal parameters may be configured after connecting the radar’s RS232 port to a PC’s RS232 serial COM port and using the Houston Radar configuration program’s “Connect To Radar” screen as described here. The following internal “variables” may be set. Their functions are described below. - Page 14 Note 1: Bit 12 of the MO variable sets direction of detection. This functionality is available in firmware versions v115 and higher release date Jan 21 2010. Older radars may be upgraded to this version. Please contact Houston Radar for a firmware update. The following variables are available in the SS300ULG only. SS300ULG...
- Page 15 Houston Radar SS300U User Manual Output decimation value in number of measurement cycles. For example, one cycle is 81ms with range 0 (see Table 1). So a value of 1 will output a new speed value every 81ms. A value of 5 will output a new speed every 5 cycle or every 0.405 seconds.
-
Page 16: Setting Variables In The Radar
Houston Radar SS300U User Manual Setting Variables in the Radar: 1. Install the provided Houston Radar Advanced Stats Analyzer (or Houston Radar Configuration) Windows program on a Windows 2000, XP, Vista or Win 7 computer. 32 and 64 bit computers are supported. - Page 17 Houston Radar SS300U User Manual Set Serial Baud Rate: The supplied Windows configuration program can auto detect the baud rate of the radar serial port. However if you wish to communicate with the radar from your electronics, the radar serial port may be configured to different baud rates.
-
Page 18: Ss300U Specifications
Baud Rates from 1200 to 115200 baud Data & Pwr Connector SS300U-OFD:Molex “C Grid SL” male shrouded 12 pin RA part #70553-0011 SS300U-DFT:Molex “C Grid SL” female 12 pin (mate to above Mechanical Weight approx 33 grams (1.16 oz) Dimensions 2.1”x1.75”x0.6”... -
Page 19: Performance
Houston Radar SS300U User Manual Performance Measurement Limits SS300U 0.25mph to 16mph SS300ULG 0.07mph to 11.2mph, 3 ranges 0.006 mph Resolution 0.5% of reading + 0.01mph Accuracy Detection Range SS3300U Typically 90+ m (300+ feet) for compact vehicles on open and level road with radar mounted 1.5 m (5 feet) high and... -
Page 20: Appendix A: Hooking Up To The Trigger Outputs On The Radar
Appendix A: Hooking up to the trigger outputs on the radar The SS300U radar features two “open drain” outputs. The device used for this purpose is the On Semiconductor relay driver NUD3124. The output configuration of this device is shown below (from the On Semi datasheet). -
Page 21: Appendix B: Optional Breakout Io Board Connections
Houston Radar SS300U User Manual Appendix B: Optional Breakout IO Board Connections: (Non-Isolated Mosfet version with PWM Brightness Control) Connecting the load to the High power and trigger outputs: You may directly connect your high power DC load + & - to J5. The load is activated via fuse F1 when the output is triggered. -
Page 22: Optional Breakout Io Board Connections
Houston Radar SS300U User Manual Optional Breakout IO Board Connections: (Isolated Solid-State Relay version, AC or DC capable) Optional Isolated IO Board. Note: PWM Brightness Control is NOT available with Isolated AC/DC Relay outputs. Page 22 of 22...
