Summary of Contents for DORIC CamLoop
- Page 1 CamLoop Behavior Camera User Manual Version 1.0.0...
-
Page 2: Table Of Contents
Contents 1 Overview 1.1 System Overview ..........2 Operations Guide 2.1 Getting Started . -
Page 3: Overview
The camera is comprised of the camera itself, the objective lens, and a Trig cable. The image (Fig. 1.1) displays a very simple setup consisting of Doric Neuroscience Studio and a console to run both Camloop and an LED driver for closed-loop light stimulation. - Page 4 • One Objective, with a Focus Adjustment Ring and Iris Adjustment Ring (Fig 1.2a). • The CLCS Mount connects the Camera and the Objective Lens. (a) Camera Side (b) Camera Back (c) Camera Underside Figure 1.2: CamLoop Behavior Camera Chapter 1. Overview...
- Page 5 1.1.2 Trig Cable The Trig Cable assembly allows the use of external triggers. The cable connects to the 12-pin Hirose output of the camera. On the opposite side of the cable there is a BNC Input which allows digital signals to be sent to the camera. Figure 1.3: Trig Cable Chapter 1.
-
Page 6: Operations Guide
The USB key contains 2 pieces of software: 1) the Doric Neuroscience Studio to control Doric hardware, and (DNS) 2) the Cam33U setup software. Instructions to install and maintain the Doric Neuroscience Studio can be found in the appropriate manual. 2.2 Installing the camera driver •... -
Page 7: Specifications
Specifications 3.1 Specifications Table 3.1: CamLoop Behavior Camera Specifications SPECIFICATION VALUE Sensor Sony IMX273 Sensor format 1 / 2.9 Shutter type Global Field of view 53.8 x 40.8 deg (98 x 74 cm at 1 m distance) Dynamic range 12 bit Video formats B&W 1920 x 1080 Y16... -
Page 8: Operation
Table 3.3: Environmental Specifications DESCRIPTION OPERATION STORAGE Indoor Temperature -5-50 C -20-80 C Humidity 20-80% RH, non condensing 20-95% RH, non condensing Chapter 3. Specifications... -
Page 9: Support
4.2 Warranty This product is under warranty for a period of 12 months. Contact Doric Lenses for return instructions. This warranty will not be applicable if the unit is damaged or needs to be repaired as a result of improper use or operation outside the conditions stated in this manual. - Page 10 © 2024 DORIC LENSES INC 357 rue Franquet - Quebec, (Quebec) G1P 4N7, Canada Phone: 1-418-877-5600 - Fax: 1-418-877-1008 www.doriclenses.com...
