BTE Eccentron LE1 Operator's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OPERATOR'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Eccentron LE1 and is the answer not in the manual?

Questions and answers

Related Manuals for BTE Eccentron LE1

Summary of Contents for BTE Eccentron LE1

  • Page 1 OPERATOR’S MANUAL...
  • Page 2 40060004...
  • Page 3 The furnishing of this document does not give you license to these patents, trademarks, copyrights, or other intellectual property except as expressly provided in any written license agreement from BTE Technologies. Printed in the U.S.A.
  • Page 4 This limited warranty is in lieu of all warranties, expressed or implied, and all other obligations or liabilities on the part of BTE Technologies. We neither assume nor authorize any person to assume any other obligation or liability in connection with the sale of this product.

  • Page 5: Table Of Contents

    Operator’s Manual Table of Contents Safety Important Notes Assembly and Maintenance General Operation System Startup General Hardware Operation General Software Operation System Shutdown Dosing and Exercise Eccentron Training Paradigm Client Training Client Positioning Practice Session Clinician Management Clinician Menu Administration Resources Utilities Client Management...
  • Page 6 40060004...

  • Page 7: Safety

    Safety Before Operating the Eccentron 1. Remove the transport casters 2. Attach the front panel 3. Attach the rear side panels 4. Adhere to all usage and positioning instructions 5. View the Clinician Usage Video prior to setting up clients for exercise Warnings Grounding To avoid the risk of electric shock, this equipment must only be connected to supply mains...
  • Page 8 For instructions on removing or replacing the panels, see the Assembly and Maintenance section. Network Connection The Eccentron is not intended to be connected to a network, do not do so unless instructed by BTE. Equipment Modification Do not modify this equipment without authorization of the manufacturer...
  • Page 9 Client Safety Instruct clients on proper positioning and exercise motion for safety and efficacy. It is very important that all Clients and Clinicians are aware of correct and incorrect positioning before and during exercise. • The Eccentron is not recommended for use by people under the age of 16. •...
  • Page 10 40060004...

  • Page 11: Important Notes

    This page highlights important considerations regarding the Eccentron. Please follow these important notes. • ANY CHANGES OR MODIFICATIONS TO THE DEVICE OR SOFTWARE NOT EXPRESSLY APPROVED BY BTE COULD VOID THE WARRANTY • A dedicated circuit is necessary to operate the Eccentron. The circuit should have: Voltage Supply...
  • Page 12 Definitions of Symbols and Certification Marking Manufacturer General Warning Sign Catalogue Number Medical Device (Product and Model Number) Serial Number Type B Applied Part Where applicable: Authorised Representative In CE Marking with the Notified The European Community Body number MET Mark - Certified for Follow Instructions for Use safety by MET Laboratories Alternating Current...
  • Page 13 Manufacturer BTE Technologies 7455-L New Ridge Road Hanover, MD 21076 Telephone: (410) 850-0333 Fax: (410) 850-5244 Website: www.btetechnologies.com Maintenance The Eccentron requires the following checks to be performed daily before use: • Verify that the seat locking pin engages and prevents the seat from moving.
  • Page 14 Intended Use (Intended Purpose) Summary The system is intended to be used to increase muscle strength of the lower extremities. Detailed The Eccentron is intended for use in physical rehabilitation of patients with injuries and conditions that affect lower extremity strength. It is used in functional and sport rehabilitation where the patient performs compound motions to strengthen muscles used in real life tasks, for example transitioning between standing and sitting, descending stairs, jumping, and stopping forward motion (braking motion).
  • Page 15 There are no components on which preventative inspection and maintenance shall be performed by service personnel. Components will be replaced if needed in accordance with BTE service policy. In addition, documentation and instructions for any in-field repairs to be conducted by service personnel will be provided.
  • Page 16 Notified Body Notified Body ID Number 0413 Certificate Number 41319556 A copy of the EC Declaration of Conformity can be obtained by sending a written request to BTE at the listed above address. Notice to Customers Located in the European Union Emergo Europe is BTE’s Authorized Representative in the European Union as noted in section...

  • Page 17: Assembly And Maintenance

    System Components Please inspect all parts for any visible damage from shipping. Notify BTE upon discovery of any damage. The system consists of the main Eccentron frame, display, front console, 2 side housings, 2 side panels, and the pendant attachment.

  • Page 18: Installation

    Installation and Assembly Tools Required The following tools are needed for installation and assembly of the equipment: • Phillips Screwdriver (#2) • ¾" Wrench Unpack the Eccentron Unwrap all packaging around the Eccentron frame and discard. Keep the front console, side housings, and side panels packaged until ready to be attached to the frame.
  • Page 19 Figure 2 - Lower Casters 2. Use a ¾” wrench to remove the screw from frame tube on the side of the frame. Then, pull the caster out of the frame tube. Figure 3 – Unscrew Tube Screw Figure 4 - Remove Caster 3.
  • Page 20 Figure 5 - Bracket Screws Figure 6 - Display with Screws Removed 3. Line up the holes on the back of the display with the holes on the mounting plate. Use the four M4 X10 screws sent with the system to attach the monitor to the mounting bracket. Figure 7 - M4 x 10 screws 4.
  • Page 21 Attach the Side Housings 1. Using a Phillips screwdriver, remove the 3 screws in the frame. Repeat on the opposite side. Figure 9 - Frame Screws 2. The side housing assemblies are not interchangeable; the truncated apex faces forward on both the right and left sides.
  • Page 22 3. Align the right side housing and secure it using the 3 screws previously removed from the frame. Repeat for the left side housing. Figure 11 - Side Housing Attachment Attach the Rear Side Panels 1. Locate the blue side panel and position it inside on side housing. 2.
  • Page 23 Attach the Front Console 1. Remove the 2 screws on each side that secure the center console to the frame. Figure 13 - Console Frame Screws 2. Carefully lift and place the studs of the front console onto the steel mounting hooks of the frame. Then, lower the console down onto the frame.
  • Page 24 Figure 16 - Front Console Hooks Figure 17 - Lower Console onto Frame 3. Secure the front console and center the console to the frame using the 4 screws previously removed. The screw must pass through both covers, adjust as required. Figure 18 - Console Screw Attachments Figure 19 - Console Screw Attachments 40060004...
  • Page 25 Connect the Pendant Cable and Power Cable 1. Insert the pendant cable into the back panel and tighten it. 2. Place the pendant into its holder as shown. Figure 20 - Pendant Cable Figure 21- Pendant Holder 3. Plug the power cord into the rear cover, and plug into the dedicated outlet. 4.
  • Page 26 Figure 24 – Fully Assembled Eccentron 40060004...
  • Page 27 Relocation This section describes how to move the Eccentron to another location in the facility. 1. Shut down the software, turn of the power switch, and unplug the power cable from the wall outlet. 2. Have the transport casters and hardware ready. Remove the Rear Side Panels 1.
  • Page 28 Remove the Front Console 1. Remove the 2 screws on each side that secure the center console to the frame. Figure 27 - Console Screw Attachments 2. Carefully lift and remove the front console. Figure 28 - Lift Console off Frame 40060004...
  • Page 29 Attach the Transport Casters 1. The casters must be in place in order to move the device. 2. Slide the four casters into the square tubes located at the base of the frame. 3. Using a ¾” wrench, attach and tighten the screw securing the transport caster to the frame. Repeat for the other 3 casters.

  • Page 30: Recommended Maintenance

    Recommended Enhancements In addition to the equipment shipped to you from BTE, the purchase of the following items from a local supplier is recommended for additional protection of your clients, equipment, and data: • Disinfectant wipes to clean the commonly used surfaces •...
  • Page 31 For optimal performance, shut down the software and turn of the power switch the every night. • Do not install any additional software onto the computer. The BTE Eccentron system is in constant communication with the computer, so a “clean,” dedicated computer is crucial to the integrity of the system.

  • Page 32: Software Maintenance

    Creating a log file • You may be instructed by a representative of BTE to supply a log file from the system during a service event. To retrieve the log file from the system follow the procedure below. 1. Plug a USB flash drive into the USB port on the back of the monitor.
  • Page 33 5. From the Software screen select Update 6. The system will update the software and restart the application upon completion. Exporting the database • To export the database you will require a USB flash drive 1. Plug a USB flash drive into the USB port on the back of the monitor 2.
  • Page 34 6. The system will export the database Restoring the database • To restore the database you will require a USB flash drive with the database to restore on the flash drive 1. Plug a USB flash drive into the USB port on the back of the monitor with the database 2.
  • Page 35 Touch Screen Display • Moisten a soft towel with a manufacturer recommended cleaner and wipe off the screen. • Do not spray any liquid onto the back of the touch screen display. Eccentron Frame • Wipe down the system with an alcohol-based or approved disinfectant solution. Housing •...

  • Page 36: Environmental Protection

    Preventive Inspections • Prior to each use, be sure the pendant is stored correctly and the cable attachment is free of cracks or other damage. • Periodically inspect the seat adjustment mechanism for any unusual wear or damage. • Periodically inspect the cables for unusual wear or damage. Environmental Protection At the end of the system’s useful life, please remove the hard drive and have it professionally cleaned to remove all data;...

  • Page 37: General Operation

    General Operation This chapter highlights features of the Eccentron and how they work. It is important that clinicians familiarize themselves with the instructions in each section for best results. Figure 1 - Back Panel Power Switch Pendant Cable Power Cord System Startup 1.

  • Page 38: General Hardware Operation

    General Hardware Operation Seat The seat has features designed to facilitate access and client positioning. These include pivoting armrests and a sliding seat; both are described below. Armrest Adjustment For ease of client access to the seat, the armrests are moveable. Manually raise the armrests as needed for clients to get in and out of the seat.
  • Page 39 Seat Position CAUTION: Do not allow knee extension beyond 30° Proper client positioning in relation to the pedals is critical for safe and effective use of the Eccentron. Follow the on-screen instructions carefully for seat set up. 1. While the Client is seated with feet on pedals and heels touching the bottom pedal rim, position the seat so that the knee of the most extended leg has at least 30°...
  • Page 40 Stride Length Adjustment Stride length is available travel distance of the pedals. The Eccentron has three stride length settings for short, medium, and long strides. Stride selection will depend on client’s ergonomics, comfort, and range of motion. Stride length adjustment can be found on the Seat & Stride Adjustment screen. Use the up/down arrows on screen to increase or decrease the stride length as instructed on the screen.
  • Page 41 Machine Settings Match Once a client is set up into the system, the software will require the same seat and stride settings to be used each time for that client. As a reminder for seat positioning, the seat setting saved will show on screen, and the previously saved stride position will show to the left of the Current Stride box.
  • Page 42 Pendant Pendant Actions The pendant offers four simple functions for client convenience: Start and Pause exercise; Emergency Stop; Pedal Speed adjustment; and End exercise session. All other functionality must be performed on the touch screen display by the clinician. Always return the pendant to its holder when the device is not in use.

  • Page 43: General Software Operation

    The first screen that appears in the software is the Welcome, or Log In, screen. A Username and PIN are required to access the software, so BTE has provided a default log in for first time access to the system.
  • Page 44 Enter the Username and PIN. The first clinician who uses the BTEAdmin log in can perform the following functions. • View the Usage Video • Set up the Clinic information • Add New Client Users • Add New Clinician Users Clinician Functions Within the Eccentron software program Clinicians can: •...

  • Page 45: Shut Down The System

    Shut Down the System The computer is sensitive to improper shutdown. Shutting down the Eccentron system improperly can cause damage to the computer and/or the database utilized by the Eccentron software that can render the Eccentron system inoperable. When you are done using the equipment for the day, it is recommended that you shut down the system. To shut down the Eccentron, perform the following steps: 1.
  • Page 46 40060004...

  • Page 47: Dosing And Exercise

    Dosing & Exercise This chapter presents a general testing and treatment paradigm and a step-by-step process for a first time Client user. As with any exercise program, it is necessary to determine a client’s baseline performance in order to administer proper exercise and progression parameters. For best results, clients should be regularly evaluated against their baseline to be sure treatment is sufficient and effective.
  • Page 48 Dosing Test The Dosing Test begins with a warm-up, consisting of 6 repetitions (12 strides total) performed at a submaximal effort. The purpose of the warm-up is to ease the client into their dosing test so that maximum effort is not applied from a cold start. The Dosing Test itself consists of 6 repetitions (12 strides total), performed at the Client’s safe maximum effort.

  • Page 49: Client Training

    30 minutes. Dosing Re-Test BTE suggests re-testing Clients after they complete 3 successful exercise sessions, due to the rapid strength gains many people experience with eccentric muscle work on the Eccentron. Re-testing every 4th session provides an appropriate and accurate target range that is individually tailored to each Client’s current capability.
  • Page 50 Client Training Screen Sequence Introduction The training introduction screens provide basic instruction and safety guidelines to follow. Figure 3 - Training Introduction Screen “The Eccentron is an easy and highly effective way to strength train without lifting weights. When exercising, the pedals will move automatically.
  • Page 51 Figure 4 - Safety Guidelines Screen Always Never • • Follow the usage Exercise with straight, instructions and locked, or warnings. hyperextended knees. • Exercise only under • your own Log In. Resist the pedals when you are out of •...
  • Page 52 Client record. Select Proceed to proceed under the usage terms. Figure 5 - Acceptance of Terms Screen “I understand and agree to follow all safety, positioning, and usage guidelines for the Eccentron. If further information is desired, please contact a facility Clinician, or BTE.” 40060004...

  • Page 53: Client Positioning

    Client Positioning The key to safe and successful outcomes on the Eccentron is proper Client positioning. It is very important to follow the positioning recommendations provided here and in the Clinician and Client Training materials. Ingress and Egress The Eccentron is designed to facilitate Client seating regardless of level of assistance they may need. Raise the armrests as needed for Clients to get in and out of the seat.
  • Page 54 2. Lift and hold the seat lock pin, and slide the seat until the client’s knee has no less than 30° of flexion. If you are unsure between 2 seat settings, use the one closer to the screen. 3. Once the proper setting is found, input the number on the screen. CAUTION: Do not allow knee extension beyond 30°...
  • Page 55 Foot Position Instruct clients to keep their feet flat on the foot pedal beds with heels against the heel cup at all times during exercise, and to never remove feet from the moving pedals. If foot movement is needed for any reason like repositioning, Pause the exercise first.

  • Page 56: Practice Session

    Practice Session The software allows first-time users an opportunity to practice the exercise prior to performing the Dosing Test. During the Practice Session, encourage the Client to resist against the pedals as they come toward the Client. Effective cues, depending on the advised effort, include, “Try to slow down the pedal motion,” and, “Try to stop the pedal from coming toward you.”...
  • Page 57 Figure 13 - Activate Pedals Screen Figure 14 - Speed Adjustment Screen “If the motor is not moving, please start it. Press the “Press the center button to start the pedals moving. down arrow button to slow down the pedals.” Press it again to pause the pedals.
  • Page 58 Figure 17 - Resistance Motion Screen Figure 18 - Resistance Motion Screen “Now we’ll try the other leg. “Now let’s try both legs. Using just your left leg, resist—or brake—against the Practice resisting on both legs until you see the pedal as it comes toward you as shown.
  • Page 59 Dosing Test Screens The Dosing Test consists of a warm-up of 6 reps (full strides on each leg), and then a recorded test of 6 reps. During the warm-up, instruct the Client to resist at a comfortable submaximal level. Figure 19 - Dosing Warm-up Figure 20 - Dosing Warm-up During the Dosing Test, instruct the Client to resist at their safe maximum level for each stride.
  • Page 60 Once the Dosing Test is finished, there are 3 options for proceeding. Figure 23 - Dosing Test Completion Screen 1. Manually override the set exercise parameters for the Client by modifying the Session Settings. To do this, select the Override icon, which takes you to the Session Settings screen. Manually enter the desired values and proceed to exercise.
  • Page 61 Exercise Screen Controls There are various screen controls that the Clinician and Client should be aware of during exercise. See General Hardware Operation/Pendant. Pendant Buttons The pendant allows the client to start, pause, resume, and stop the exercise program. The clinician can use the corresponding buttons on screen for the same functions.
  • Page 62 Pause/Resume Exercise The Client can pause the exercise (pedal and screen activity) by pressing the center button once. To resume exercise, press it again. To exit the exercise session from the Pause screen, hit the down arrow button. Session data will be saved.

  • Page 63: Exercise Program

    Exercise Program The Eccentron exercise program provides a “ramp-up” of gradually increasing duration, with intermittent Dosing Tests to properly set the Target Range. Additionally, the exercise session itself includes a short warm-up, active exercise, and brief cool-down stages. Exercise Preparation Clients should perform a general warm up for 5–10 minutes, or as Clinician recommends, prior to using the Eccentron.
  • Page 64 Pre-set Exercise Manually-set Exercise Sample Exercise Session Stages Warm Up In addition to the general therapy warm up, the pre-set exercise session provides a short period of time at the beginning of the session for the Client to become adjusted to the exercise resistance. This lasts for 1 minute, or 10% of the duration, whichever is greater.
  • Page 65 Interactive Game The Eccentron software displays a fun, animated game screen to teach, entertain, and motivate the client while exercising. The game screen portrays the Client as a hiker going downhill. Select Start to begin the pedal and screen activity. Force bars below the hiker show real-time force effort exerted on the pedals. Figure 27 - Start of Game Screen Live Data Display The screen displays live collection data for the exercise to help the Client and Clinician monitor...
  • Page 66 Performance Motivation The interactive game trains clients to stay in a particular force range, for neuromuscular performance gains. The goal for the “hiker” is to have all the force bars land inside the Target Range band. The “% on Target” area displays the accuracy of each leg individually in hitting the target, as well as an average for both legs.
  • Page 67 • If a diamond is earned, the diamond accrual at the top of the screen increases. • If a diamond is missed, there is no “penalty”. A new diamond will start forming with the next on- target stride. Excessive Effort Control Force exceeding the Target Range is discouraged and will not earn diamonds.
  • Page 68 Demo Exercise There is a “demo” session pre-programmed on the Eccentron. This is available to test out the device and get a feel for the eccentric resistance motion as well as the software and game features. Demo data results are not saved. The Demo parameters are: •...

  • Page 69: Clinician Management

    Clinician Management The Eccentron software provides helpful administrative and treatment features in order to get the most out of your equipment. In addition to the ability to add and search for client records, more options and features are available via the Clinician Menu. Clinicians should execute the Administration and Resource sections prior to treating Clients on the Eccentron.
  • Page 70 • Machine Settings for the client Seat Setting Stride Setting • Session Settings for exercise Target Force Duration Pedal Speed • Reports Session Reports Progress Reports 2. Administration The Administration section contains the Eccentron setup information. This section allows the modification of software, exercise, and data collection defaults.

  • Page 71: Administration

    3. Resources The Resources section contains usage and training materials. • Operator’s Manual • Clinician Usage Video 4. Utilities • Software Update Export Log Files • Database Export Restore Administration Use the Administration section to set up the clinic, clinical users, and system preferences. Action buttons at the top right of the screen allow for Demo exercise, and Log Out of the system.
  • Page 72 Clinic Setup From the Administration screen, select Clinic Setup to enter your clinic information. This step is optional, however, if it is filled out your clinic information will print on the client reports. Figure 3 - Clinic Setup Screen 1. Enter the following Clinic information from the keypad: a.
  • Page 73 Figure 4 - Administration Screen: Clinician Setup Add Clinician Each Clinician should have an individual Login, and each user must have a unique Username. Clinician name and credentials (if entered) will print on Reports. When the Add Clinician icon is clicked, the following screen appears.
  • Page 74 3. Create a Username of < 25 alphanumeric characters (required) 4. Create a 4-digit PIN using the numeric keypad (required) 5. Enter Clinician credentials of < 50 characters (optional) 6. Save the entry when finished by choosing OK Search/Select Clinician Use the Search feature to locate an existing Clinician record.
  • Page 75 Figure 7 - Edit Clinician Screen 1. To edit Client info, touch inside the field you wish to edit. All information can be edited except Username. 2. Save the entry to keep your changes, or select Cancel to keep the current information. Delete Clinician Press the Delete (trash can) icon to permanently delete a clinician record.
  • Page 76 1. Select the Delete icon, which prompts a warning asking for confirmation. 2. If you chose Delete in error, select Cancel. 3. If you wish to continue with the deletion, select OK. NOTE: Deleted records cannot be recovered. System Configuration The Eccentron software is pre-programmed with default settings allowing a clinician to safely use the system while becoming familiar with all its functionality.
  • Page 77 Figure 10 - Compilation of System Configuration Options NOTE: It is recommended that no changes be made to the formula default settings until the Clinician has a thorough understanding of the Eccentron usage guidelines and pre-set treatment plan. Before making changes to these parameters, it is critical that you have an understanding of functions and calculations.
  • Page 78 Units of Measure The system permits the user to set force readings in either Imperial (pounds) or Metric units (Newtons) for force measurement. Press the toggle button to change from one to the other. The default measurement displayed is Metric. System Language The default language displayed on the Eccentron is English.
  • Page 79 Decreasing this setting will decrease the usefulness of the diagnostic logging utility. Unless specified by BTE, it is strongly encouraged to leave the logging level at 4.

  • Page 80: Resources

    Rate of Perceived Exertion Display At the conclusion of an exercise session, the Rate of Perceived Exertion (RPE) scale appears, providing the clinician an opportunity to track client effort during treatment. RPE tracking is an optional feature on an individual client basis if utilized. Figure 11 - RPE Selection Screen The ability to track RPE also can be globally turned on or off for individual clinicians if desired.
  • Page 81 Figure 12 - Resources Screen Operator’s Manual Instructions for use included in this Operator’s Manual must be followed. For your convenience, clicking on the Operator’s Manual icon will open on screen a digital version of the printed Operator’s Manual provided with your Eccentron device. Clinician Usage Video The training materials provided include a brief Usage Video on the use and performance of the Eccentron.
  • Page 82 Figure 14 - Video Warning Message Figure 15 - Video Reminder Message The Usage Video can be accessed 2 ways: Immediately after a new Clinician is added to the database, and via the Resources tab under Administration. Clinicians will be able to conveniently review any of the training materials as needed.

  • Page 83: Utilities

    Figure 16 - Video Player Screen The training video covers: • Client access on and off the device • Proper client positioning for exercise • Pendant use • Eccentric resistance motion • Dosing Tests Utilities (Database & Software) Occasionally system maintenance may be necessary for database operations and software updates, which are accessed via the Utilities section.
  • Page 84 Figure 17 - Utilities Screen Software Management The Software screen provides two options: Update and Export Log Files. Software Update Software updates may periodically be provided via an external device. Press the Update button and follow the simple on-screen instructions. Once the update file is located, simply press “OK” to start the install.
  • Page 85 Figure 18 - Export Dialog Purchase a USB drive and export the database from the computer on to the USB drive (the E: Drive) by clicking on the Export icon. The unique export file name default shall be “Eccentron-C drive identifier-date-time”. The following screen appears when the database icon is clicked.

  • Page 86: Client Management

    Client Management This Chapter addresses client record management, which includes adding, viewing, modifying, and deleting Client records. Additional options in this section allow for individual machine and session settings for each Client, including pre-set and manual exercise options. Client Add/Search To access the Client Add/Search screen, select Clients from the Clinician Menu.
  • Page 87 Figure 2 - Add Client Screen 1. Enter the new Client name of up to 40 alphanumeric characters into the First and Last Name text fields. 2. Create a Username of up to 24 alpha characters. 3. Create a 4-digit PIN using the numeric keypad. 4.
  • Page 88 Figure 3 - The Client Detail Screen From the Client Record screen, a Clinician can: 1. Edit or Delete a Client 2. Modify seat and stride settings 3. Set or modify exercise parameters 4. View Client Reports 5. Administer a Dosing Test 6.
  • Page 89 Edit Client Client information can be modified as needed or permanently deleted from the system. Also, if a client forgets their PIN, a new PIN may be entered here. To access the Edit screen, click the Client icon on the Client Record screen.
  • Page 90 Delete Client The Delete option is available from the Edit screen. Press the Delete (trash can) icon to permanently delete a client record. Figure 5 - Delete Client 1. Select the Delete icon, which prompts a warning asking for confirmation. 2.

  • Page 91: Machine Settings

    Machine Settings Machine Settings are physical adjustments to be made on the Eccentron so that the Client is comfortably and safely positioned for exercise. These seat position and stride length settings are determined during the Client’s first session. There may be instances when range of motion increases as the Client’s rehab progresses, so seat and stride settings may be adjusted if necessary.
  • Page 92 Session Settings Session Settings refer to the parameters set for the current Exercise Session. Target Force, Session Duration, and Pedal Speed are pre-set in the software, or they can be manually set by the Clinician. Overriding the pre-set Session Settings is considered to be a Manual Session. Once the Client has performed a Manual session, the Session Settings will stay as entered until the Clinician changes them again.

  • Page 93: Reports

    Reports This chapter highlights the reporting functions of the Eccentron software. For each Client, reports can be generated, saved, exported, and printed. There are two types of reports available: session reports and progress reports. Session Report Screen After the completion of an exercise session, the performance data collected is displayed as a Session Report.
  • Page 94 If a client is logged in, selecting “Done” will log them out and return to the Login screen. The same happens if Exit is pressed. If a clinician is logged in, selecting “Done” will revert to the Client Add/Search screen. Progress Report Screen To switch from the Session Report to the Progress Report, select the Progress button.

  • Page 95: Export Reports

    Export Reports The Export function on the Report screens allows for saving and printing reports. The exported Session Report contains charts for force and work performed over the duration of the exercise. The force chart does not include data from the warm-up and cool down periods, however, the work chart does.
  • Page 96 When you select Export, the software provides a filename, which CANNOT be modified. Use the following steps to export either a Session or Progress Report. Figure 4 - Export File Naming 1. Insert a flash drive into the USB port. 2.
  • Page 97 Session Report Sample 40060004...
  • Page 98 Progress Report Sample 40060004...
  • Page 99 40060004...
  • Page 100 40060004...

  • Page 101: References

    References Albert, M. (1995) Eccentric Muscle training in Sports and Orthopaedics (2 Ed.). Churchill Livingstone, London, UK, pp. 174. Friedmann, B., Kinscherf, R., Vorwald, S., Muller, H., Kucera, K. Borisch, S., Richter, G., Bartsch, P., Billeter, R. (2004). Muscular adaptations to computer-guided strength training with eccentric overload. Acta-Physiol.
  • Page 102 40060004...
  • Page 103 Appendix EMC Guide Guidance and manufacturer’s declaration – electromagnetic emissions Eccentron is intended for use in the electromagnetic environment specified below. The customer or the user of Eccentron should assure that it is used in such an environment Emissions test Compliance Electromagnetic environment - guidance RF Emissions CISPR 11...
  • Page 104 Guidance and manufacturer’s declaration – electromagnetic immunity Eccentron is intended for use in the electromagnetic environment specified below. The customer or the user of Eccentron should assure that it is used in such an environment. IEC 60601 test Immunity test Compliance Level Electromagnetic environment guidance level...
  • Page 105 Guidance and manufacturer’s declaration – electromagnetic immunity Eccentron is intended for use in the electromagnetic environment specified below. The customer or the user of Eccentron should assure that it is used in such an environment. IEC 60601 test Immunity test Compliance Level Electromagnetic environment guidance level...
  • Page 106 Recommended distance between portable/mobile RF communication equipment and Eccentron Eccentron does not need to be used in a radiated RF controlled environment. Customers or users of Eccentron shall maintain the minimum safe distance between portable/mobile RF communication equipment (transmitter) and Eccentron to prevent electromagnetic interference. The minimum distance shall be accordance with the maximum output of the communication equipment as recommended below.
