MULTI WASH
– UTENSILS WASHER
Rev.: 00 / 03 - 2022
USER and MAINTENANCE MANUAL
-----------------------------------------------------------------------
MODEL:
- MW STD 2
- MW STD 3
- MW STD 4
-
WARNING !!!
UNIT OPERATES WITH HIGH TEMPERATURE WATER. TO INSERT OR TAKE OUT TOOLS
AND TRAYS FROM THE TANK PLEASE WEAR GLOVES AND GLASSES FOR NOT GETTING
BURNED.
ALWAYS ACCOMPANY THE LID WHEN CLOSING THE COVER
SAME TO AVOID THE OCCASIONAL CRUSHING OF THE HANDS
THE MACHINE IS SUPPLIED BY THE MANUFACTURER WITH THE PARAMETERS
OF TEMPERATURE AND DURATION ALREADY PROGRAMMED AND SET.
IT IS COMPULSORY TO USE ITS SPECIFIC DETERGENT "CLEAN DETERGENT" FOR A
GOOD OPERATION OF THE MACHINE. NO SERVICE OR WARRANTY IS PROVIDED IF
ANOTHER TYPE OF DETERGENT IS USED
THE USER MUST TO CONSULT THE "CLEAN DETERGENT" DATA SHEET BEFORE USING
THE MACHINE.
Pag. 1 di 32

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MULTIWASH MW STD 2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Zernike MULTIWASH MW STD 2

  • Page 1 MULTI WASH – UTENSILS WASHER Rev.: 00 / 03 - 2022 USER and MAINTENANCE MANUAL ----------------------------------------------------------------------- MODEL: - MW STD 2 - MW STD 3 - MW STD 4 WARNING !!! UNIT OPERATES WITH HIGH TEMPERATURE WATER. TO INSERT OR TAKE OUT TOOLS AND TRAYS FROM THE TANK PLEASE WEAR GLOVES AND GLASSES FOR NOT GETTING BURNED.

  • Page 2: Table Of Contents

    MULTI WASH – UTENSILS WASHER Rev.: 00 / 03 - 2022 INTRODUCTION ....................................3 1.1 IMPORTANCE OF THE MANUAL ................................3 1.2 MANUFACTURES IDENTIFICATION DATAS ............................3 1.3 CE MARKS .......................................4 1.4 TYPOGRAPHIC CONVENTION .................................4 1.5 SAFETY INSTRUCTION FOR MAINTENANCE ............................5 1.6 SIGNS APPLIED ON THE MACHINE .................................5 1.6.1 STICKERS AND WARNING LABELS ............................6 SAFETY DEVICES....................................7 2.1 OPERATING CYCLE SAFETY DEVICES ..............................7...

  • Page 3: Introduction

    1.2 MANUFACTURER INDENTIFICATION DATAS The identification of the company ZERNIKE S.r.l. as the manufacturer of the machine, takes place in compliance with the legislation in force by means of the following acts:...

  • Page 4: Ce Marks

    If for accidental reasons the "CE MARKING" plate is damaged or detached from the machine, the customer is obliged to inform ZERNIKE S.r.l. and ask for its replacement. 1.4 TIPOGRAPHICAL CONVENTION...

  • Page 5: Safety Instruction For Maintenance

    MULTI WASH – UTENSILS WASHER Rev.: 00 / 03 - 2022 1.5 SAFETY INSTRUCTIONS FOR MAINTENANCE • Before executing any maintenance and / or cleaning operations on the machine, disconnect the electrical and pneumatic power supply and wait for the hot devices to cool. •...

  • Page 6: Stickers And Warning Labels

    MULTI WASH – UTENSILS WASHER Rev.: 00 / 03 - 2022 1.6.1 STICKERS AND WARNING LABELS General adhesive label "WARNINGS" applied on the lid. “HOT SURFACE DANGER” Warning labels applied on the deck and at the right and left of the lid. Warning labels “DANGER OF CRUSHING HANDS”...

  • Page 7: Safety Devices

    MULTI WASH – UTENSILS WASHER Rev.: 00 / 03 - 2022 2 SAFETY DEVICE 2.1 OPERATING CYCLE SAFETY DEVICES The machine is equipped with the following stop functions: • Main switch Press the main switch (A) to "0" - OFF to disconnect the machine from the power supply •...

  • Page 8: Electrical Safety Devices In Case Of Overload

    MULTI WASH – UTENSILS WASHER Rev.: 00 / 03 - 2022 2.3 ELECTRICAL SAFETY DEVICES IN CASE OF OVERLOAD Positioned in the special drawer inside the compartment technical, there is 1 fuse: - Models 2-3-4 STD mono-phase: n. 1 of 15 A - Model 4 STD three-phase: n.

  • Page 9: Technical Data

    MULTI WASH – UTENSILS WASHER Rev.: 00 / 03 - 2022 TECHNICAL DATA Below are the data and technical characteristics of the machine to which reference must be made, together with the identification data shown on the CE marking plate, for any contact with the Manufacturer's Technical Assistance U.D.M.

  • Page 10: To Start The Machine

    MULTI WASH – UTENSILS WASHER Rev.: 00 / 03 - 2022 The power supply must be carried out by connecting the supplied power cable to the plug (not supplied) and then subsequently connecting it to a power outlet protected by a 400V, 30mA differential switch IMPORTANT THE USE OF EXTENSIONS IS FORBIDDEN The machine is originally equipped with a general protection device from electrical overvoltage (see the...

  • Page 11: Start The Machine

    MULTI WASH – UTENSILS WASHER Rev.: 00 / 03 - 2022 C - Connect the machine to the general grounding line using the equipotential screw (OPTIONAL - in case you have to connect several machines together) D - Check that the unloading handle, located under the machine, is in the "closed" (fig. 2 – frontal MW 4 fig.

  • Page 12: Multiwash Use

    MULTI WASH – UTENSILS WASHER Rev.: 00 / 03 - 2022 Level switch fig. 4 Once the water has reached the set level regulated by the level switch and the temperature set- point, an acoustic alarm will sound to remind you that it is possible to insert the detergent. 4.

  • Page 13: End Of Washing Cycle

    MULTI WASH – UTENSILS WASHER Rev.: 00 / 03 - 2022 CAUTION To remove food residues from utensils before placing them in the tub, never use sponges or detergents. Never pre-wash the utensils with any type of detergent but use only water. 5.4 END OF WASHING CYCLE The washing operating cycle set by default on the machine is 28 days but this parameter can be modified as desired.

  • Page 14: Maintenance

    MULTI WASH – UTENSILS WASHER Rev.: 00 / 03 - 2022 The security measures provided are: • active type, through emergency stop. Risks coming from possible electric energy use The security measures provided are: • Active type, by general main switch. WARNING Machine has to be used by one only operator.

  • Page 15: Scheduled Maintenance Intervention

    MULTI WASH – UTENSILS WASHER Rev.: 00 / 03 - 2022 SCHEDULED MAINTENANCE INTERVENTION The following table lists all the checks and periodic maintenance operations necessary to maintain correct and safe operation of the machine over time. The operations described below must be carried out within the indicated times. Failure to comply with the requirements exempts the Manufacturer from any liability for the purposes of the Warranty.

  • Page 16: Scheduled Replacement Of Parts Subject To Wear

    MULTI WASH – UTENSILS WASHER Rev.: 00 / 03 - 2022 SCHEDULED REPLACEMENT OF PARTS SUBJECT TO WEAR The user is advised that: - the hinge with safety micro on the lid must be replaced no later than 10 years after use DANGER All extraordinary maintenance and repair operations are to be carried out with the machine stopped with sectioned electricity;...

  • Page 17: Ordinary Cleaning

    MULTI WASH – UTENSILS WASHER Rev.: 00 / 03 - 2022 ORDINARY CLEANING The routine cleaning phase now begins. Take the shower and clean the basket and the inside of the tub from residues with a jet of water. Trying to get the water into every crevice. If necessary, use a gel buffered descaler to be applied to the walls and parts to be cleaned.
  • Page 18 MULTI WASH – UTENSILS WASHER Rev.: 00 / 03 - 2022 Using a pressure shower, clean the tub from residues, remove the drain cover and clean everything. . At the end of this phase, put the drain cover back in its place and the basket back to the tank. Close the water drainage handle located under the machine.

  • Page 19: Setting Multi Wash Std System

    MULTI WASH – UTENSILS WASHER Rev.: 00 / 03 - 2022 MULTI WASH STD SETTING ON/OFF Button SETTING Button DRAIN Button CHARGE Button WASH Button Pag. 19 di 32...

  • Page 20: Device Switching On And Off

    MULTI WASH – UTENSILS WASHER Rev.: 00 / 03 - 2022 DEVICE SWITCHING ON AND OFF In case device is OFF in STAND-BY, to switch ON just touch button ON/STAND-BY: PRESS: CHARGE In case device ON, to switch it OFF press for 2 seconds long button ON/STAND-BY HOME PAGE PRESS: CHARGE...

  • Page 21: Load & Heating Phase

    MULTI WASH – UTENSILS WASHER Rev.: 00 / 03 - 2022 LOAD & HEATING PHASE PRESS: CHARGE From HOME PAGE, press button CHARGE. You have WATER LOAD and HEATING PHASE. On display you have LOAD/HEAT. Device starts LOADING WATER till level is reached: in this phase icon CHARGE is blue colored and heating will be disabled.

  • Page 22: Draining Phase

    MULTI WASH – UTENSILS WASHER Rev.: 00 / 03 - 2022 Since button WASH get pressed, a program timer count-down activates only for detergent and work recirculation, it is possible to reset it only through program or manual machine reset. Even by swtiching it off temporarily, the lasting program keeps saved in memory but timer count-down will be temporarily kept on hold untill a new switch on is executed.
  • Page 23 MULTI WASH – UTENSILS WASHER Rev.: 00 / 03 - 2022 DRAINING process consist on 3 automatic and sequential phases: 1) DRAINING 1: you can activate eventual (optional) drain pump or it is possible to drain by vertical fall. 2) DRAINING 2: during the rinse phase, electrovalve for water loading and recycling pump to clean and also drain the boiler.

  • Page 24: Alarms Running

    MULTI WASH – UTENSILS WASHER Rev.: 00 / 03 - 2022 ALARMS RUNNING In case of alarm a writing ALARMS will be displayed in red the one concerned activated. Pressing button STOP buzzer will be switched OFF. To get out the alarmi it is necessary to press long button (with panel control on stand-by).

  • Page 25: Menu Setting

    MULTI WASH – UTENSILS WASHER Rev.: 00 / 03 - 2022 MENU SETTING PRESS: CHARGE Login by pressing button (in the top on the right) On the following page, down on the right, you have the firmware version. Icons move either rightwars as well as leftwards.

  • Page 26: Clock And Calander

    MULTI WASH – UTENSILS WASHER Rev.: 00 / 03 - 2022 CLOCK AND CALENDAR Pressing icon you enter into menu DATE & TIME. On next screen page, press where you wish to modify in order to select it. To modify its value press arrow .

  • Page 27: Digital Output

    MULTI WASH – UTENSILS WASHER Rev.: 00 / 03 - 2022 8.10 DIGITAL OUTPUT It is possible to check the correct relé working. Press this icon to enter into first menù page where you find output check Press buttons K1 …. K5 to activate the corresponding relè; to disable them it is enough to press the button again.
  • Page 28 MULTI WASH – UTENSILS WASHER Rev.: 00 / 03 - 2022 Time OFF relè K2 (in phase detergent recirculation) and relè K3 (drain 1 phase) Duration rinse phase Duration drain 2 phase Max time limit to activate the continuous activation K2 in the phase Detergent recirculation and Drain 1 Minimal temperature set –point settable °C...

  • Page 29: Detergent Schedule

    MULTI WASH – UTENSILS WASHER Rev.: 00 / 03 - 2022 8.12 DETERGENT SCHEDULE (DAYS) Press icon you enter to setting menù where it is possible to plan real working days. With arrows you can set program duration and confirm it with button OK. To cancell the modification just press button BACK.

  • Page 30: Trouble Solving

    MULTI WASH – UTENSILS WASHER Rev.: 00 / 03 - 2022 TROUBLE SOLVING PROBLEM AND MALFUNCTIONS CAUTION Any intervention on the machine whose execution requires precise technical competence and particular skills must be carried out by authorized and qualified personnel. This staff must create all the conditions necessary to comply with the laws in force regarding safety in fixed and / or temporary workplaces.
  • Page 31 MULTI WASH – UTENSILS WASHER Rev.: 00 / 03 - 2022 CAUTION Demolition must be entrusted to specialized firms qualified to perform this type of operation because they have the equipment, tools and machines suitable for the purpose.. The phases of disposal of the parts of the system must be carried out by the operators safeguarding the following conditions: •...
  • Page 32 Inox-Bázis Kft. Arany János u. Központi Major 9090 Pannonhalma, Hungary info@inoxbazis.hu...

This manual is also suitable for:

Multiwash mw std 3Multiwash mw std 4
