PRE-INSTALLATION
•
Disconnect power source prior to installation.
•
Before adjusting or rotating the head, the screw must be loosened in
case of damage to the rubber ring, which can cause water leakage.
1 5 0 W Car o b S tr ee t , Comp to n, C A 90 220 | w w w.co r el igh t i ng us a .co m | 888- 737- 9192
FL-800 SERIES
FL-811MP | FL-812MP | FL-821MP
INSTALLATION GUIDE
DIMENSIONS
A
B
F
STEM LENGTH
18 in. | 36 in.
FL-811MP | FL-821MP
STEM LENGTH
18 in. | 36 in.
F
FL-812MP
MODEL
A
B
FL-811MP
Ø39.9mm
4 x Ø5.3mm
Ø56.9mm
FL-812MP
Ø79.8mm
4 x Ø6.4mm
Ø56.9mm
FL-821MP
Ø39.9mm
4 x Ø5.3mm
Ø85.9mm
SAFETY
Read all instructions before installation.
These products may present a possible shock, serious injury, or death if
improperly installed.
Do not cover fixture with heat insulation gasket or similar materials.
Product should be installed by a qualified electrician.
Product should be installed in accordance with these instructions and current electrical codes.
To reduce the risk of fire or ovreheating, all connections should be tight and secure.
C
D
E
167.9mm
E
(6.61 in)
C
D
C
D
E
F
114.8mm
99.8mm
Ø74.9mm
114.8mm
252mm
Ø140mm
168.8mm
79mm
Ø74.9mm
