Assembly Instructions
1.
Slide the Handle Assembly tube through
the Hook Slide Weldment (item 25) and
into the Base Assembly tube and align
drilled holes.
2.
Insert bolt (item 21) through the aligned
holes and secure with Lock Nut (item 22)
to fasten the Handle Assembly to the
Base Assembly.
Note: Hook Slide Weldment slides freely on the
Handle Assembly tube to engage the upper rim of
your drum.
WARNING
dioxide, and 2-methylimidazole, which are known to the State of California to cause cancer, and
bisphenol-A, which is known to the State of California to cause birth defects or other reproductive
harm. For more information go to
Copyright – Morse Mfg. Co., Inc.
Model 155
2-Wheel Self-Standing Drum Truck
SN 0115 to Current (MMYY) or 400000 to Current
Model 155
2-Wheel Self-Standing Drum Truck
Capacity: 1000 Lb. (454 kg)
- This product can expose you to chemicals including barium sulfate, cobalt, titanium
www.P65Warnings.ca.gov
18 September 2024
Handle Assembly
Hook Slide Weldment
Base Assembly
Page 1
Advertisement
Related Manuals for morse 155
Summary of Contents for morse 155
- Page 1 2-methylimidazole, which are known to the State of California to cause cancer, and bisphenol-A, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov Copyright – Morse Mfg. Co., Inc. 18 September 2024 Page 1...
- Page 2 Model 155 2-Wheel Self-Standing Drum Truck morsedrum.com SN 0115 to Current (MMYY) or 400000 to Current Copyright – Morse Mfg. Co., Inc. 18 September 2024 Page 2...
- Page 3 AXLE WELD, 155 1971-P PEG WELD, 155 1962-P BEVEL LINK, 155 1970-P STAND WELD, 155 1968-P TUBING, 5/8 OD X .688 90 155 35-P HHCS, 5/16-18 X 1 GR2 491-P NUT, 5/16-18 REV HEX LOCK 64-P ROLL PIN, 3/16 X 1-1/4 176-P...
