MODEL : 2120T-3048
DINING TABLE
No
ITEM
Qty
Table
1 pc
A
Leg
4 pcs
B
No
ITEM
Qty
JCBB Bolt m8x60mm
Rbw
8 pcs
1
ALLEN KEY
m5x65mm Blk
1 pc
2
REMARK:
THE HARDWARE IS LOCATED IN THE
PACKING ITEM.
NOTE : MUST TIGHTEN SCREWS PERIODCALLY WITH USE SCREW WILL BECOME LOOSE CHECK TIGHTNESS OF ALL SCREW EVERY 6-8 WEEKS.
ASSEMBLY INSTRUCTIONS
STEP 1
:
Attach Table Dining Top (A) at soft surface
A
STEP 2
:
Attach Leg Post (B) at Table Marble Top (A)
with Flat Washer ,Spring Washer and
JCBB Bolt and tighten with Allen Key (2).
B
Soft Surface
1
2
