Viscosity Measuring Overhead Stirrer
OPERATING MANUAL
We greatly appreciate your purchase of the EVO OS1 Viscosity Measuring Overhead
n
Stirrer. To be sure you take maximum advantage of all the features the EVO OS1 has to
offer, read these instructions carefully and use the set properly. Be sure to keep this
manual for future reference, should any questions or problems arise.
SERIAL NO.
PLEASE RECORD UNIT SERIAL NUMBER ATTACHED TO THE
REAR OF THE UNIT FOR FUTURE REFERENCE.
EVO OS1 Operating Manual 〔ENGLISH〕 Version 06/18
Page 1/26
Advertisement
Table of Contents
Summary of Contents for DAIHAN EVO OS1-10
- Page 1 Viscosity Measuring Overhead Stirrer OPERATING MANUAL We greatly appreciate your purchase of the EVO OS1 Viscosity Measuring Overhead Stirrer. To be sure you take maximum advantage of all the features the EVO OS1 has to offer, read these instructions carefully and use the set properly. Be sure to keep this manual for future reference, should any questions or problems arise.
-
Page 2: Safety Precautions
n SAFETY PRECAUTIONS u Safety symbol used in the manual Danger Dangerous voltage exclamation point within The lightning flash with arrowhead equilateral triangle is intended to alert symbol, within an equilateral triangle, is the user to the presence of important intended to alert the user to the operating and maintenance instructions presence of uninsulated “dangerous... - Page 3 WARNING : TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION : TO RECUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
-
Page 4: Precaution In Use
l Precaution in use Please be familiar with the user manual before using this product, and operation Ÿ should be performed only by qualified personnel. This product must be used within the permitted standard load resistance. Ÿ This product should be operated in a room with temperature maintain between Ÿ... -
Page 5: Table Of Contents
n INTRODUCTION Thank you for purchasing Viscosity Measuring Overhead Stirrer of DHIHAN Scientific International Inc. We, DHIHAN Scientific International Inc., started to manufacture and supply highly reproducible and reliable products in the basic equipment for basic science research such as biotechnology, medicine, environment, and chemistry. -
Page 6: ① Before Using
① BEFORE USING Pay attention to the following before using this unit: l Moving the set To prevent short circuits or damaged wires in the connection cords, always unplug the power cord safely. l Before turning the power switch on Check once again that all connections are proper and that there are not problems with the connection cords. -
Page 7: ③ Product Installation
“EVO OS1-10/15/20” Digital Overhead Stirrer Unit (Support Rod is included) “OSIP010” Impeller, Propeller, 3 x bladed, Ø8 rod, Ø50 mm blade In EVO OS1-10 “OSIP020” Impeller, Propeller, 4 x bladed, Ø8 rod, Ø70 mm blade In EVO OS1-15 “OSIP030” Impeller, Diamond, 4 x bladed, Ø8 rod, Ø90 mm blade... -
Page 8: How To Install
How to install 1. Place stand in to the appropriate location. 2. Connect Rod into stand and then fasten it by spanner. 3. Connect Clamp into Rod by turning it to clockwise direction. 4. After installing the support rod with the nut in the threaded hole on the back of the product by turning it clockwise and then tighten the nut clockwise with the included spanner. -
Page 9: Product Specification
Product specification EVO OS1-10 EVO OS1-15 EVO OS1-20 Model /EVO OS1-10-Set /EVO OS1-15-Set /EVO OS1-20-Set Stirring Capacity Max. 25 Lit. (H Max. 40 Lit. (H Max. 60 Lit. (H Maximum Viscosity 70,000 mPas 100,000 mPas 150,000 mPas Maximum Torque 130 Ncm... -
Page 10: ④ Check Before Operation
④ Check before operation Product structure Clamp Full Touch Control TFT LCD Jog Dial Knob Drill Chuck Power Switch sticker Specification Stand <Digital Viscosity Measuring Overhead Stirrer> Full Touch Control TFT LCD: Viscosity and Torque measurement, RPM and Timer control. Ÿ... -
Page 11: Control Panel & Setup
Control panel & Setup 1. Motor Power Bar : Meaning of displayed colors Green: Recommended of use. Ÿ Yellow: Intermittent use, requires user's attention. Ÿ Red: Non-recommended use (operation may be stopped for safety when used for a long Ÿ time). - Page 12 Current Stirring speed User-set Stirring speed If you touch the RPM area, a blue bar on the left side will appear at the RPM position Ÿ and then you can set the RPM. Elapsed timer time User set timer If you touch the timer area, a blue bar on the left side will appear at the Timer position Ÿ...
- Page 13 Viscosity Measurement Mode: Press this button to change to viscosity measurement mode as shown below. Display the measurement time. Viscosity value graph that changes with time (X axis is Time, Y axis is Viscosity value) The maximum displayable viscosity. - 150,000 mPas. Measured viscosity value is displayed.
-
Page 14: Auto Measurement
11. Setup : Click this button to go to the Settings option page. Speed Control Mode 1. Default: Slow - Stirring speed rises slowly to the set target section. 2. Normal – Stirring speed rises at a general high speed up to the set target section. - Page 15 How to set. Torque Offset – If an unwanted torque (torque regardless of solution) is applied depending on the user's Ÿ environment, such as a vacuum reactor or attachment of an arbitrary coupling, the value can be offset through the Torque Offset function. It is used when the torque needs to be arbitrarily offset according to the user's Ÿ...
-
Page 16: ⑤ Operation
⑤ Operation l Confirm whether the power cable is normally connected or not. l Confirm whether or not the Impeller into Overhead Stirrer. l Confirm whether or not the setting of sample. 작 Stirring and Timer Operation Jog Dial Knob Power Switch 1. -
Page 17: Viscosity Measurement Function
점도 측정 기능 Viscosity Measurement Function 1. This instrument is not a viscosity measuring instrument that guarantees the value in measuring viscosity, and it is realized that it is possible to measure viscosity while stirring. This significantly reduces sample waste and experimental time with high reproducibility compared to the existing method, which requires the measurement of viscosity and stirring of the sample as separate experiments. - Page 18 ² Precautions when measuring viscosity : Samples that are difficult to measure with conventional viscometers can be equally difficult or difficult to measure with a viscometer stirrer. Please refer to the other precautions to be taken when measuring viscosity with this equipment. 1.
-
Page 19: Target Viscosity Stirring Function
목표점도 교반 기능 Target Viscosity Stirring Function 1. Touch “Target Viscosity” to move to the target viscosity agitation setting and operation screen. 2. Turn the Jog Dial Knob to set the desired viscosity and push to start preliminary stirring. After about 10 seconds, when the measured value is stabilized, the buzzer sounds once and the main stirring begins. -
Page 20: Real-Time Monitoring Function
통신 Real-Time Monitoring Function (USB Port Connection) Viscosity measuring stirrer can communicate serially with PC using USB cable (B type). Agitation status can be monitored in real time using the provided program, and information about agitation and equipment can be easily stored in a database. Installation and usage for operation법... -
Page 21: Important Features And Actions
숙 Important Features and Action Overload detect function (motor overheat indication) If the Stirrer motor is overloaded due to viscosity, operating time, RPM, etc. exceeding the capacity of the Stirrer, the temperature of the motor increases and it detects this and stops the operation of the Stirrer. -
Page 22: ⑥ Troubleshooting
⑥ Troubleshooting 러 Error Identifications ERROR Message ERROR occurs when the stirrer is overloaded or operates abnormally. Please take appropriate action referring to the information displayed on the LCD or the manual. Error types include ‘Power Error / Current Error’, ‘Overheat Error’, ‘Driver Error’, and ‘System Error’. -
Page 23: System Error
Motor Driver Error Unusable due to damage to the internal circuit of the stirrer. Ÿ If the problem persists even after turning the power off and on again, Ÿ contact the A/S center and take action. System Error Unusable due to damage to the internal circuit of the stirrer. Ÿ... -
Page 24: ⑦ Product Management
Standard Viscosity Material Viscosity Recommend model Water Milk Soybean oil Varnish Lacquer 1,000 EVO OS1-10 Honey 3,000 EVO OS1-15 Standard Viscosity 10,000 EVO OS1-20 Standard Viscosity 15,000 Ketchup 30,000 Standard Viscosity 50,000 Mustard 70,000 Corn Syrup 100,000 Standard Viscosity 150,000... -
Page 25: Cleaning And Storage
Cleaning and storage l Cleaning of the product Maintain the cleaning state of the product by regular cleaning. The regular maintenance of the product extends the use period of the product and minimizes the contamination of specimen. 1. Confirm whether or not any foreign matters exist, and if yes, immediately wipe off them. 2. - Page 26 In case the malfunction occurs by not observing the safety caution and warning described in the user manual. Ÿ In case the malfunction occurs by the handling carelessness of the user. Ÿ DAIHAN Scientific International Inc. —————————————————— B-612 461 Samildaero Jongrogu Seoul, 03147, KOREA Tel : +82 70 5020 1533 E mail : tim.suh@daihan-sci.com...
