Instruction Manual
Part No.: XCPSC04622
Fiber Optic Terminal Box
OTO C equipped with SC/APC external shutter adaptor + 900 microns SC/APC pigtail (A2)
Version: A/0
-------------------------------------------------------------------------------------------------------------------------------------------------------
1 / 6
Advertisement
Related Manuals for ORANGE XCPSC04622
Summary of Contents for ORANGE XCPSC04622
- Page 1 Instruction Manual Part No.: XCPSC04622 Fiber Optic Terminal Box OTO C equipped with SC/APC external shutter adaptor + 900 microns SC/APC pigtail (A2) Version: A/0 ------------------------------------------------------------------------------------------------------------------------------------------------------- 1 / 6...
- Page 2 Fiber optic terminal box is available for the distribution and terminal connection for various kinds of optical fiber system, especially suitable for mini-network terminal distribution, in which the optical cables, patch cores or pigtails are connected. Features 1.Industry Standard User Interface, be made of high impact plastic. 2.Anti-UV, Ultra violet resistant and rainfall resistant.
- Page 3 Terminal box assembly -1 Figure 1 Figure 2 Open splice tray, as shown in Figure 2 Open the cover of the box, as shown in Figure 1 Figure 3 Figure 4 Shutter adaptor be installed into the box, Prepare shutter adaptor, as shown in Figure 3 connect with pigtail , and then wrap the cable of pigtail to splice tray along the slot , as shown in Figure 4...
- Page 4 Terminal box assembly -2 Figure 1 Incoming fiber optic cable(3.0mm) is stripped to 0.9 sub-cables, the length is 40CM, and it is heat-shrinked with a hot-melt tube, as shown in Figure 1 Figure 2 Figure 3 Use cable ties to fasten the optical cable, as The 3.0mm optical cable is passed through shown in Figure 3 the cable inlet, as shown in Figure 2...
- Page 5 Fusion fiber Figure 1 Figure 2 The bare fibers from pigtail & incoming fiber The bare fibers installation position, as cable are installed on the fiber fusion shown in Figure 2 machine, as shown in Figure 1 Figure 3 Figure 4 Put on the cover of the fusion splicer then After the fiber fusion is completed, put the start fiber fusion, as shown in Figure 3...
-
Page 6: Installation
Installation Figure 1 Figure 2 Drill holes at the marked positions, as shown Use a marker pen to mark the positions of in Figure 2 the screw holes in the box, as shown in Figure 1 Figure 3 Figure 4 The box corresponds to the screw hole, and Insert the expansion tube into the hole, as then tighten the screw, as shown in Figure 4...
