- Page 1 ST·FONT Quick guide ST·FONT NANO Modules - València 2024 ©...
- Page 2 Once you have checked all the connections, you can turn on your modular system. If you notice any anomalies, turn your system off right away and check again your connections. ST·FONT ST·FONT NANO Modules - València 2024 © NANO Modules - València 2024 ©...
- Page 3 Stereo Span Controls. Dedicated FREQ Span, RES Span, and MODE Span knobs allow you to create a wide, immersive stereo field by adjusting the spread of parameters across both channels. ST·FONT NANO Modules - València 2024 © NANO Modules - València 2024 ©...
- Page 4 Layout · General view This image will clarify the function of each of the elements of the module. ST·FONT MODE FREQUENCY LIQUID FILTER Morph between Band Controls the filter’s cutoff, & High Pass filter output. determining which frequencies are attenuated. Frequencies below the cutoff point.
- Page 5 filtering effects, while WILD pushes the resonance to its limits, delivering intense, aggressive sounds with heavy distortion that brings an extra edge to your signal. Fig.3 Differences between Mild & Wild Resonance Mode ST·FONT NANO Modules - València 2024 ©...
- Page 6 MODE Span knobs allow you to create a wide, immersive stereo field by adjusting the spread of Frequency, Resonance and Mode across both channels. Fig.4 Difference between L and R outputs with different Span knob settings ST·FONT NANO Modules - València 2024 ©...
- Page 7 Fig.7 Detail of Shape Mode Knob • Low-Pass . Frequencies below the cutoff are passed. • Band-Pass . Only a specific range of frequencies around the cutoff is passed. • High-Pass . Frequencies above the cutoff are passed. ST·FONT NANO Modules - València 2024 ©...
- Page 8 CV. Modifies the CV modulation applied to the Mode knob, enabling external control over the filter’s FREQ MODE morphing behavior between Low Pass, Band Pass, and High Pass modes. Fig.10 Detail of CV Attenuverters ST·FONT NANO Modules - València 2024 ©...
- Page 9 SPAN Allows external control of the Frequency, Mode or Resonance Span parameters. • Outputs L & R Processed audio signal for both left and right channels. Fig.13 Detail of L & R Outputs ST·FONT NANO Modules - València 2024 ©...
- Page 10 Switches between two resonance MILD WILD styles: • MILD. Smooth and controlled Fig.16 Detail of Resonance Mode Switch resonance for subtle sound shaping. • WILD. Aggressive and distorted resonance for extreme effects and experimentation. ST·FONT NANO Modules - València 2024 ©...
- Page 11 • FREQ & RES Span Tuning Adjust this trimmer to set the center point for the Frequency or the Resonance SPAN control. V-OCT TUNING FREQ SPAN RES SPAN TUNING TUNING LEFT HP RIGHT HP TUNING TUNING ST·FONT NANO Modules - València 2024 ©...
- Page 12 EN 61000-3-3. Limitation of voltage changes, voltage fluctuations and flicker in public low-voltage supply systems. • EN 62311. Assessment of electronic and electrical equipment related to human exposure restrictions for electromagnetic fields. • RoHS2: 2011/65/EU • WEEE: 2012/19/EU ST·FONT NANO Modules - València 2024 ©...
-
Page 13: Technical Specifications
• This guarantee covers Any defect in the manufacturing of this product. Replacement or repair, as decided by NANO Modules. • This guarantee does not cover Any damage or malfunction caused by incorrect use , such as, but not limited to: Power cables connected backwards.
