The way to deploy LoopSign on your Philips D-Line BDL4650 screen is to install the LoopSign Android
App og your screen.
Content
1.
Factory Reset .................................................................................................................................. 2
2.
General Settings .............................................................................................................................. 2
3.
Configuration .................................................................................................................................. 5
3.1 Install LoopSign Player Android App. ............................................................................................ 5
3.2 Configure settings .......................................................................................................................... 7
3.3 Enroll/Assign screen in LoopSign ................................................................................................. 13
© Loop24 AS, Olaf Helsets vei 6, 0694 Oslo, Norway - info@loop24.no - https://loop24.no
Philips D-Line BDL4650
LoopSign Deployment Guide
Page: 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the D-Line BDL4650 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Philips D-Line BDL4650

Summary of Contents for Philips D-Line BDL4650

  • Page 1: Table Of Contents

    Philips D-Line BDL4650 LoopSign Deployment Guide The way to deploy LoopSign on your Philips D-Line BDL4650 screen is to install the LoopSign Android App og your screen. Content Factory Reset ..........................2 General Settings ..........................2 Configuration ..........................5 3.1 Install LoopSign Player Android App..................... 5 3.2 Configure settings ..........................

  • Page 2: Factory Reset

    1. Factory Reset If the screen has been used for other purposes earlier, it is highly recommended to do a factory reset before you start. “Press “Home” button quickly followed by numbers 1-8-8-8. Then select “Settings”, “Signage Display”, “System tools” and “Factory reset”. 2.
  • Page 3 In "Clone Media Files into internal”, select "Skip". In "Signage Display Settings", select "Skip". In "Security Setting” Enable “Unknow Sources Installation”, select "Next". © Loop24 AS, Olaf Helsets vei 6, 0694 Oslo, Norway - info@loop24.no - https://loop24.no Page: 3...
  • Page 4 In "Network Setting", choose your preferred network mode (Wi-Fi is only available if the screen has Wi_Fi capabilities) Ethernet is highly recommended. Click "Next" and follow the onscreen instructions. Enable Ethernet Skip Wave configuration. First time installation setup complete. © Loop24 AS, Olaf Helsets vei 6, 0694 Oslo, Norway - info@loop24.no - https://loop24.no Page: 4...

  • Page 5: Configuration

    3. Configuration 3.1 Install LoopSign Player Android App. Download the latest Android App with device management enabled: https://loop24.no/lspdm.zip Unzip the APK file to a USB stick. Preferably unused (That has not been formatted on windows) Insert the USB stick in one of the USB ports on the screen Press the "Home"...
  • Page 6 Select the APK file you downloaded and select “Open” Then select “Install” After installation, select “Open” © Loop24 AS, Olaf Helsets vei 6, 0694 Oslo, Norway - info@loop24.no - https://loop24.no Page: 6...

  • Page 7: Configure Settings

    3.2 Configure settings After starting the LoopSign Player your screen will show enrollment HASH. Before you enroll the screen, do come initial configuration of your screen to make sure it will work properly Press “Home” button. Select “Configuration 1” and set “Switch on state” to “Force on” ©...
  • Page 8 Set “Boot on source input” to “Custom” © Loop24 AS, Olaf Helsets vei 6, 0694 Oslo, Norway - info@loop24.no - https://loop24.no Page: 8...
  • Page 9 Under “Advanced Option” make sure “Date and Time” is correct, should normally be set to “Auto Sync - On” If time and date is not correct, it might indicate that you do not have network connection or firewall is stopping NTP traffic. It is crucial that time and date is set correctly. Select “Schedule”...
  • Page 10 Go back to main screen and press the "Home" quickly followed by the numbers 1-8-8-8 This will enter the “Android menu” Select “Settings” Then select “Signage Display” © Loop24 AS, Olaf Helsets vei 6, 0694 Oslo, Norway - info@loop24.no - https://loop24.no Page: 10...
  • Page 11 Then select “Source Setting” Choose “Custom App” Choose “Select App” © Loop24 AS, Olaf Helsets vei 6, 0694 Oslo, Norway - info@loop24.no - https://loop24.no Page: 11...
  • Page 12 Choos “LoopSign Player” and Save. Press «Sources» button and Select Custom. The screen with HASH code should now appear. © Loop24 AS, Olaf Helsets vei 6, 0694 Oslo, Norway - info@loop24.no - https://loop24.no Page: 12...

  • Page 13: Enroll/Assign Screen In Loopsign

    3.3 Enroll/Assign screen in LoopSign Enter LoopSign console and select “Devices” from top menu Select menu item “Enroll” and enter a name and the HASH for the screen The Screen should now appear under “Unassigned” Select “Device Actions” and “Assign” ©...
  • Page 14 Then assign the screen to the desired “screen” in LoopSign and Save. Screen will now start playing the selected content and screen will be shows as “Online” Setup complete. Please restart the screen to check that everything works. © Loop24 AS, Olaf Helsets vei 6, 0694 Oslo, Norway - info@loop24.no - https://loop24.no Page: 14...
