Summary of Contents for Euhomy IM-15S-AZ-HM
- Page 1 PORTABLE NUGGET ICE MAKER USER Manual SKU ：IM-15S-AZ-HM Email：support@euhomy.com Facebook：@Euhomy.Official...
- Page 3 Email: support@euhomy.com Facebook: @Euhomy.Official The Euhomy team is available 24/7 to address your questions, comments, and concerns. Your satisfaction is our ultimate goal. We want to make everything right so you'll share your positive experience with other shoppers on Amazon.
- Page 5 It may be that the PUA tube inside the machine fell off during transportation. You can remove the back cover of the machine and connect it by yourself. If you don't know how to operate, please contact the Euhomy team. We will give you a professional video to help you solve the problem.
-
Page 7: Table Of Contents
Contents SAFETY INSTRUCTIONS 03-04 PREPARING YOUR ICE MAKER FOR USE GETTING TO KNOW YOUR UNIT OPERATING PROCEDURES & MAINTENANCE 07-12 USING YOUR ICE MAKER TROUBLESHOOTING TECHNICAL PARAMETERS & CIRCUIT DIAGRAM... -
Page 8: Safety Instructions
SAFETY INSTRUCTIONS Your safety, as well as the safety of others, is of utmost importance to us. We have incorporated many important safety messages in the manual of your appliance. Always read and follow all the safety instructions. Below is the safety alert symbol. AII Safety messages will follow the safety alert symbol and the word "... -
Page 9: Preparing Your Ice Maker For Use
PREPARING YOUR ICE MAKER FOR USE When using electric appliances, it's vital to follow basic safety SAFETY TIPS steps to lower the risk of fires, electric shocks, or harm to people and property. Make sure to read all the instructions before you start using any appliance. - Page 10 PREPARING YOUR ICE MAKER FOR USE WARNING: This appliance must be grounded. DANGER: Risk Of Fire or Explosion. Flammable Refrigerant Used. Do Not Use Mechanical Devices To Defrost Ice Maker. Do Not Puncture Refrigerant Tubing. To Be Repaired Only By Trained Service Personnel. Consult Repair Manual/Owner’s Guide Before Attempting To Install or Service CAUTION: This Product...
-
Page 11: Getting To Know Your Unit
GETTING TO KNOW YOUR UNIT 1. Float Switch； 2. Secondary Water Reservoir (It connects directly with the evaporator)； 3. Water Reservoir； 4. Maximum Water Level； 5. Filter； 6. Control Panel： A.Ice making and cleaning buttons； B.Ring indicator light； C.Water lack indicator light； D.Ice full indicator light；... -
Page 12: Operating Procedures & Maintenance
OPERATING PROCEDURES & MAINTENANCE 1. Remove both the exterior and interior packaging, and then check to ensure that all the accesso- ries are included. If any of the parts are missing, please contact our customer service for assis- tance. 2. Remove all the tapes from the unit and take out the accessory parts inside. 3. -
Page 13: Using Your Ice Maker
USING YOUR ICE MAKER Before using your ice maker, it is strongly recommended to clean it thoroughly. Unplug the unit before cleaning or making any maintenance. 1.Take out the ice basket. 2.Clean the interior with diluted detergent, warm water, and a soft cloth. 3.Rinse the inside parts with water and drain out the water by unplugging the drain cap located on the bottom front side. - Page 14 USING YOUR ICE MAKER CLEAN We recommend running the initial cleaning,procedure before using the appliance for the first time or if the device has not been cleaned in a long time. Here are the steps to follow: 1.Before cleaning, make sure to insert the water drain cap into the appliance to ensure it works properly 2.Press and hold the “ICE/CLEAN”...
- Page 15 USING YOUR ICE MAKER Tips: remove the top back cover by pulling up the front clear cover gently. Change the water in the reservoir every 24 hours to ensure a reasonable hygiene level. If the unit is not in use, drain and dry the water reservoir. System Cleaning/Sanitizing Procedure 1.
- Page 16 USING YOUR ICE MAKER 3. For daily cleaning, dilute one teaspoon of household bleach in five cups of water. 4.For monthly cleaning of removing mineral deposits, use the white vinegar instead of the water solution mentioned above(and then plug in to turn on the “cleaning function” for about 5 minutes. After that, unplug it again to leave the white vinegar in the unit for at least 12hours).
- Page 17 USING YOUR ICE MAKER 8. Repeat steps 4 to 6 with fresh water for two more cycles to rinse the inside. 9. Replace the drain cap on the bottom. 9. After completing the cleaning process, fill the reservoir with fresh water and press the "Ice/Clean"...
- Page 18 USING YOUR ICE MAKER How to obtain the ice cube 1. Before making ice, make sure to insert the water drain cap into the appliance to ensure it works properly 2. Press and hold the “ICE/CLEAN” button for 5 seconds. The ice making procedure will be activated when the Ring indicator light flashes white.
-
Page 19: Troubleshooting
TROUBLESHOOTING Possible Cause Problem Solution Stop the ice maker, fill water, and “Add Water ” Lack of Water. press “ICE/CLEAN” button again to indicator turns on restart the unit. The amount of ice is Time to grab some ice cubes out. excessive “ICE FULL”... -
Page 21: Technical Parameters & Circuit Diagram
TECHNICAL PARAMETERS & CIRCUIT DIAGRAM TECHNICAL PARAMETERS Model IM-15S IM-15S-AZ-HM Protection Type Power 115V/60Hz Ice Making Current 2.7A Refrigerant R600a.0.57Oz / 16g Vesicant Dimension 287x220x322mm CIRCUIT DIAGRAM... - Page 24 Email：support@euhomy.com Facebook：@Euhomy.Official...
