EMG 4HR-LP User Manual

HAND OPERATED
ARBOUR PRESS
USER MANUAL
Hand operated arbour presses are robust, precise,
flexible and ergonomic.
The power is linear and constant over the entire stroke
according to the force exerted on the lever.
They are frequently used for assembly operations,
assembly of rings or bearings, small bending
operations, various crimping operations, etc.
Power output according to
the force applied to the lever arm
Presse à crémaillère
Static force exerted
on the lever in kg
Maximum power
allowed by the press
Technical data:
Power(kg)
Working stroke(mm)
Adjustable free height(mm)
Gooseneck depth(mm)
Rotation angle per mm of stroke
Ram bore(mm)
Table bore
Table(mm)
Weight(kg)
Power restituted
by the press in the axis
of the ram in kg
SLOT FOR CLEATS M 6
STANDARD DIN 508
