DoorLock-RA4-RITTAL-VX – MANUAL | 1
ORDER-CODES:
KXC-RA4-RITTAL-VX
DATASHEET KXC-RA4
Overview
The DoorLock-RA4-RITTAL-VX is an adapter for the DoorLock-RA4 locking solution for Rittal IT racks
of the VX series. The adapter is only supplied in conjunction with a DoorLock-RA4-IPx-L, as the two
components are screwed together at the factory.
Safety instructions
Installation
Installation and commissioning may only be carried out by trained specialist personnel in accordance
with the instructions.
No modifications of any kind, other than those described in an appropriate manual, are permitted to
