We are here to help you get the best out of your High-Rise LED Light Garden so if you have
any questions about this product, feel free to email us at info@garlandproducts.com.
This item is one of a number of uniquely designed, highly practical garden products o ered
by Garland Products Ltd and our subsidiary Greenhouse Sensation. Please visit our websites
to view our full range.
Garland Products Ltd, First Avenue, The Pensnett
Estate, Kingswinford, West Midlands DY6 7TZ
www.garlandproducts.com
www.greenhousesensation.co.uk
Assembly of this unit should take in the region of 30 minutes and is most easily
achieved by two people, although still possible by one person. All the tools
required for the assembly are included. Please take time to ensure that the parts
contained correspond to the list of parts detailed on the table below. For easy
identi cation, each part is also referenced on the illustrations for Steps 1 to 7 in
these Assembly Instructions.
Location Advice
Select a suitable level location for your High-Rise LED Light Garden. Avoid areas
which are close to radiators as well as those prone to cold draughts. The nished
assembly will measure 106cm (42") wide by 42cm (16.5") deep x 181cm (71") high.
If you wish to connect the Power Cord direct to mains power, your plug socket
will need to be within 1.2 metres (4 ft) from the side where the LED Grow Light
Fixtures connect to the Power Cord. If this is not possible, you will need to use an
extension lead (not included).
G289ALFT
High-Rise LED Light Garden
Part
Part Description
Ref.
A
Side Frame Upper - Left
B
Side Frame Lower - Left
C
Side Frame Upper - Right
D
Side Frame Lower - Right
E
Horizontal Support Bars
F
Swivel Castors with Lock
G
Swivel Castors
H
M6 Screws (10mm long)
I
M8 Screws (35mm long)
J
Tool Set (2 x Allen Keys & 1 Spanner)
K
LED Grow Light Fixtures
L
End Hooks (for LED Light Fixtures)
M
M4 Screws (6mm long)
N
Power Cord
O
Cable Ties
P
Plastic Support Trays
Assembly Instructions
Quantity
1
1
1
1
13
2
2
4
26
1
3
6
12
1
3
3
Advertisement
Summary of Contents for Garland High-Rise LED Light Garden
- Page 1 M4 Screws (6mm long) Power Cord We are here to help you get the best out of your High-Rise LED Light Garden so if you have Cable Ties any questions about this product, feel free to email us at info@garlandproducts.com.
- Page 2 High-Rise LED Light Garden STEP STEP Fix an End Hook (Part Ref. L) to each end of the 3 LED Grow Connect the Power Cord (Part Ref. N) to each of the Assembly Instructions Light Fixtures (Part Ref. K). Each End Hook requires 2 M4 Screws LED Grow Light Fixtures.
