OWNER'S MANUAL
BKVR
UNIVERSAL REMOTE LEVEL CONTROL
WITH VOLTMETER
ENGLISH
WE LIKE IT LOUD
V2
GENERAL FEATURES
Number of Channels ........................................ 2 (Left/Right)
RCA Type..................................................... Regular RCA Wire
Housing Material / Color.....................................ABS / Black
Adjustments.................................................................Voltage
Display Type....................................................... Numeric LED
Auto Turn-on ..................................................... Yes (Rem-In)
Remote Turn-on Input/Output ....................................... Yes
SPECIFICATIONS
Operating Voltage ....................................................10-15.9V
Frequency Response ........................................ 10Hz-30KHz
Input Sensitivity .........................................................0.1-16V
Input Impedance..................................................... 20K Ohms
Output Voltage .........................................0.1-16V (Variable)
Output Impedance ................................................. 20K Ohms
Advertisement
Related Manuals for DS18 BKVR
Summary of Contents for DS18 BKVR
- Page 1 OWNER’S MANUAL BKVR UNIVERSAL REMOTE LEVEL CONTROL WITH VOLTMETER ENGLISH WE LIKE IT LOUD GENERAL FEATURES Number of Channels ........2 (Left/Right) RCA Type............. Regular RCA Wire Housing Material / Color........ABS / Black Adjustments..............Voltage Display Type............Numeric LED Auto Turn-on ............. Yes (Rem-In) Remote Turn-on Input/Output ........
-
Page 2: Warranty
Flush Cut-Off Height ..........1" / 27mm Flush Cut-Off Depth...........0.5" / 13mm WARRANTY Please visit our website DS18.com for more information on our warranty policy. We reserve the right to change products and specifications at any time without notice. Images may or may not included optional equipment. - Page 3 FEATURES: • Stereo RCA Line Level Control • Can be used to adjust the amplifier gain and turn ON / OFF the amplifier • Voltmeter Display (10-15.9V) provides real-time voltage monitoring • Voltage Adjustment Control for Distance or Cable Compensation •...
-
Page 4: Installation Wiring Diagram
INSTALLATION WIRING DIAGRAM 1. Inputs: Connect the "Rem In," "GND," and "+12V" wires as labeled. 2. Outputs: Attach RCA cables to "Level Input" and "Level Output." 3. Ensure a reliable voltmeter is used to adjust the voltage accurately. BATTERY REMOTE REMOTE IN RADIO AMPLIFIER... - Page 5 BKVR MANUAL DEL USUARIO CONTROL DE NIVEL REMOTO UNIVERSAL CON MEDIDOR DE VOLTAJE ESPAÑOL WE LIKE IT LOUD CARACTERÍSTICAS GENERALES Número de canales ........2 (Izquierda/Derecha) Tipo de RCA ............Cable RCA normal Material / Color de la carcasa .........ABS / Negro Ajustes ..................
- Page 6 él. Felicidades por elegir llevar tu audio al siguiente nivel y desatar el potencial de tu sistema de audio con el BKVR. MEDIDAS Ancho total ............... 3.26" / 83mm Altura total..............1"...
- Page 7 CARACTERÍSTICAS: • Control de nivel de línea RCA estéreo • Permite ajustar la ganancia del amplificador y encender/apagar el amplificador • La pantalla de Voltímetro (10-15.9V) proporciona monitoreo en tiempo real del voltaje • Control de ajuste de voltaje para compensación de distancia o cableado •...
- Page 8 DIAGRAMA DEL CABLEADO DE INSTALACIÓN 1. Entradas: Conecte los cables "Rem In" (entrada remota), "GND" (tierra) y "+12V" según las etiquetas. 2. Salidas: Conecte los cables RCA a las entradas "Level Input" (entrada de nivel) y "Level Output" (salida de nivel). 3.
