CONCORD CNK8828WPBBA-V3 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
NVR Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CNK8828WPBBA-V3 and is the answer not in the manual?

Questions and answers

Related Manuals for CONCORD CNK8828WPBBA-V3

Summary of Contents for CONCORD CNK8828WPBBA-V3

  • Page 1 NVR Manual...

  • Page 2: Table Of Contents

    NVR User Manual Contents CHAPTER 1 PRODUCT OVERVIEW ............................1 1.1 R ....................................... 1 ANEL CHAPTER 2 NVR INSTALLATION & CONNECTION ......................2 2.1 HDD I ....................................2 NSTALLATION 2.2 C ................................... 3 ONNECTION IAGRAM 2.3 P ................................. 3 OWER UPPLY ONNECTION CHAPTER 3 COMMON OPERATIONS............................
  • Page 3 NVR User Manual 5.2.2 Record ..................................... 66 5.2.3 Capture Images................................... 68 5.3 A ....................................69 LARM ETTINGS 5.3.1 Motion Alarm ..................................69 5.3.2 PIR Alarm ....................................71 5.3.3 I/O Alarm ....................................73 5.3.4 Combined Alarm ................................75 5.3.5 PTZ Linkage................................... 77 5.3.6 Exception Alarm ..................................
  • Page 4 NVR User Manual 6.1.4 Advertise Mode ................................. 238 6.1.5 Search Counting Data ..............................240 6.2 F ....................................241 TTENDANCE 6.3 O ..................................243 BJECT LASSIFICATION CHAPTER 7 SEARCH, PLAYBACK & BACKUP ........................244 7.1 S & P ................................244 EARCH LAY IN ENERAL 7.1.1 Video Clip Backup ................................

  • Page 5: Safety Instruction

    NVR User Manual SAFETY INSTRUCTION Please read the following safety instruction carefully to avoid personal injuries and prevent the equipment and other connection devices from being damaged. The device should be used in compliance with local laws, electrical safety regulations, and fire ...
  • Page 6 NVR User Manual Do not dispose of the battery into fire or a hot oven, or mechanically crush or cut the battery,  which may cause an explosion. Do not leave the battery in an extremely high temperature surrounding environment, which may ...

  • Page 7: Chapter 1 Product Overview

    NVR User Manual Chapter 1 Product Overview 1.1 Rear Panel Item Description Power Switch Power switch to turn on or turn off the NVR. DC Power Input Connect the included DC power adapter AUDIO Output Audio output port. Connect to audio output devices like speakers. VGA Port Connect a VGA monitorAudio line input port.

  • Page 8: Chapter 2 Nvr Installation & Connection

    NVR User Manual WAN Port Connect to a router or network switch Network interface,connect IP cameras. LAN Port *It is strongly recommended to only one camera per PoE port. RESET Button Press and hold for 10 seconds with a pin to restore default settings E-SATA Support E-SATA stoarge HDD to record and backup.

  • Page 9: Connection Diagram

    NVR User Manual Note: Above procedures are for reference only. The practical operation may be different depending on the NVR you purchased. 2.2 Connection Diagram Speaker Note: Above diagram is for reference only. The practical connection may be different depending on the NVR you purchased. 2.3 Power Supply Connection Caution: Use only the supplied power adapter that came with the NVR.

  • Page 10: Chapter 3 Common Operations

    NVR User Manual For some specific models, you may need to press the Power switch to turn on the power. Chapter 3 Common Operations 3.1 Using the Supplied Mouse A. Left Button Click to select menu options.  During live viewing in split-screen view, double-click on a channel to view it in full-screen. ...

  • Page 11: Password

    NVR User Manual 3.3 Password For the first time when you run the recorder, you must be required to set your own password immediately in order to protect your privacy. Please be sure to record your username and password and save them in a secure place. Language: Choose an available OSD language.

  • Page 12: Password Recovery Settings

    NVR User Manual Camera Activation Password: This password is used to activate cameras that are not yet activated and are connected to the NVR. If "Same as recorder's password" is not checked, you can customize the activation password for cameras. If "Same as recorder's password" is checked, the device's login password will automatically be used as the camera activation password.
  • Page 13 NVR User Manual Security Questions: This feature enables the modification of the administrator user's password through security questions. After enabling it, you need to select three questions from a list of 15 common questions and set the answers, with a maximum length of 64 characters for each answer. Password Reset Key: This feature allows the modification of the administrator user's password using a key.

  • Page 14: System Login

    NVR User Manual 3. If your recorder has a Reset button on the back, you can also perform a system reset by long- pressing the Reset button to set a new password. Please note that using this method to reset the password will also reset all other system settings to their factory defaults.

  • Page 15: Chapter 4 Nvr Starting Up

    NVR User Manual Chapter 4 NVR Starting Up For recorders that support face recognition functionality, upon initial system entry, a “Machine Vision Face Recognition Algorithm Protocol” will pop up. Select "I have read and agree to this agreement" and save it. Afterward, if the device is connected to AI cameras that support face recognition, the face recognition feature can be enabled.

  • Page 16: Start Wizard

    NVR User Manual 4.1 Start Wizard When you first use the device, the system will open the Start Wizard menu, allowing you to quickly customize the basic functions of the device. 4.1.1 Start Wizard Log in the system and click the Start Wizard to proceed to the next step.
  • Page 17 NVR User Manual Single Address Mode: In this mode, both network ports are bound to a single IP address. Selecting this mode can increase bandwidth, form network card redundancy arrays, and share the load. If one network port fails, the other network port immediately takes over all the load, ensuring uninterrupted service.
  • Page 18 NVR User Manual http/https/rtsp: This port is used for remote login to the NVR (e.g., using a web client) or allowing the NVR to transmit real-time streaming media to other devices (e.g., using a media player). ONVIF also uses the same port. If the default port 80 is already occupied by another application in the LAN, please make changes.

  • Page 19: Date/Time

    NVR User Manual Enable PPPOE: Enable/disable switch for PPPoE. When enabled, the NVR will restart to activate the PPPoE settings. PPPOE Network Card Select: Select the LAN port corresponding to the dial-up connection. (Note: This option is not displayed in Single Address mode). User: PPPoE user name.
  • Page 20 NVR User Manual NTP stands for Network Time Protocol. This feature allows you to synchronize the date and time automatically on the NVR over Internet. Therefore, the NVR needs to be connected to the Internet. Tick the "NTP" box, and select the NTP server. Note: The default time zone is GMT, and NTP (Network Time Protocol) is enabled by default with the server address set to pool.ntp.org.

  • Page 21: Ip Camera

    NVR User Manual 4.1.4 IP Camera Click "Search" to search for IP cameras in the same network. Select multiple IP cameras you want to add and click the icon Add to NVR.Enter the camera's user name and password to add the camera.

  • Page 22: Disk

    NVR User Manual IP Address/Domain: IP address or domain name of the IP camera. Alias: Name of the IP camera. Port: The port of the IP camera. Protocol: Select the protocol to be used for the add-in. User Name: User name of the IP camera. Password: Password of the IP camera.

  • Page 23: Resolution

    NVR User Manual Record On E-SATA: If your NVR comes with an E-SATA port on the rear panel, you can enable to record the video to E-SATA HDD. This function only available when your E-SATA HDD has been connected to the NVR already. 4.1.6 Resolution Choose an output resolution that matches your monitor.

  • Page 24: Summary

    NVR User Manual 4.1.8 Summary You can tick the system summary information you had set in the start wizard and finish the wizard. Tick "Don’t show the start Wizard on next startup" if you don't want to display the Start Wizard after the system start.

  • Page 25: Live View Screen Overview

    NVR User Manual 4.2 Live View Screen Overview Status Icons Icon Description The camera is being recorded currently A motion alarm is happening An intelligent or AI alarm is happening The external I/O alarm device is being triggered The PIR alarm is being triggered HDD Error Icons Icon Description...

  • Page 26: Camera Quick Toolbar

    NVR User Manual Off-line: The analog camera is disconnected. No Camera: No camera has been added to the channel. Decoding Failed: NVR does not support this IP camera compression standard, please change to H.264 compression standard. Insufficient Resource: The decoding resources for previewing IP channels exceed the decoding specifications limit, or IP channels using MJPEG encoding type can only preview one IP channel, while other IP channels indicate insufficient resources.
  • Page 27 NVR User Manual To switch the live view video stream between HD & SD. HD is Stream Switch mainstream images, SD is substream images. If your camera has a built-in speaker, click this button to turn on or turn off the alarm sound. If your camera has white light LEDs, click this button to turn on or turn off the LEDs.
  • Page 28 NVR User Manual On the fisheye-mode operation page, click the setting button on the toolbar at the bottom to open the menu for setting the fisheye camera installation mode. Then, select the mode in accordance with the actual installation mode, and save the setting to make it take effect. Icon Description Ceiling Installation...
  • Page 29 NVR User Manual VR Mode: In VR mode, the picture will be displayed in fisheye format. You can click and hold the left mouse button in the picture, then drag the mouse to rotate the picture. You can also use the mouse wheel to zoom in and out of the picture.
  • Page 30 NVR User Manual 180° Panorama Mode: In this mode, the picture will display two 180° panoramic views. You can click and hold the left mouse button in the picture and then drag the mouse to scroll the picture. 360° Panorama Mode: In this mode, the picture will be displayed as a 360°...
  • Page 31 NVR User Manual 4-Split Mode: The image will be divided into four panels. You can click and hold the left mouse button in any panel, then drag the mouse to rotate the image. You can also use the mouse scroll wheel to zoom in and out of the image.
  • Page 32 NVR User Manual Fisheye + 8-Split Mode: The screen will be divided into nine sections, with the fisheye view displayed in the center and the remaining eight sections displaying split views. You can click and hold the left mouse button in any split view, then drag the mouse to rotate the image. You can also use the mouse scroll wheel to zoom in and out of the image.

  • Page 33: Taskbar

    NVR User Manual Panorama + 8-Split Mode: The screen will be divided into nine sections, with a 360° panoramic view displayed in the center and the remaining eight sections displaying split views. You can click and hold the left mouse button in any split view, then drag the mouse to rotate the image. You can also use the mouse scroll wheel to zoom in and out of the image.
  • Page 34 NVR User Manual Icon Function Description Start Menu Click to pop up the Start Menu Click to select different display layouts for preview Display Layout channels More Layouts Click to select more layouts for preview display Click to start viewing channels in a sequence. Playback all channels from the beginning of the day, you can also click on the triangle at the bottom right to Quick Playback...
  • Page 35 NVR User Manual On the right side of the Task Bar, the status information of the devices is shown. Icon Function Description Network Status Network is disconnected Network Status Network is connected but offline Network Status Network is well connected Armed Status NVR is in Armed Mode Armed Status...

  • Page 36: Alarm Popup

    NVR User Manual 4.2.3 Alarm Popup The Alarm Notification Panel is located on the right side of the screen and is used to display thumbnails of triggered alarm events. These events are color-coded based on their type. To scroll through the notifications, use the mouse scroll wheel (make sure the mouse pointer is over the notification panel).

  • Page 37: Start Menu

    NVR User Manual 4.2.4 Start Menu With the Start menu, you can switch user, search & playback, enter system setup menu, lock & unlock the screen, shut down, reboot & logout the system. 4.2.4.1 Lock and Unlock Screen When the NVR is left idle for an extended period without menu operations, the screen will be locked to protect system security.
  • Page 38 NVR User Manual 4.2.4.2 Shutdown Click the Shutdown button from Star Menu, you're able to shut down, reboot or logout the NVR. Click button, system will require to input the user password to authenticate. By selecting Logout, you will no longer be able to view the screen in real time and will need to log in to the system before you can proceed further.

  • Page 39: Chapter 5 System Setup

    NVR User Manual Chapter 5 System Setup You are able to configure the NVR for Channel, Record, Alarm, Network, Device, System, AI, AI Scenario from Start Menu. 5.1 Channel In this section, you are able to manage the camera connection, live view display, camera's image, PTZ setup, video cover, motion setup, and more.
  • Page 40 NVR User Manual 5.1.1.1 Adding IP Camera If your NVR has PoE ports and you've connected plug-and-play IP Cameras to these ports, then they should automatically appear in the list of added devices under the IP Channel section. If your connected IP camera doesn't support plug-and-play or requires manual addition, you can follow these steps: Clicking the icon next to "Add Device"...
  • Page 41 NVR User Manual Based on the search results, select one or multiple devices, click "Add, " and enter the corresponding information to complete the addition. If you're adding an IP camera using a private protocol connection, you can use the default ...
  • Page 42 NVR User Manual 5.1.1.2 Camera Protocol NVR supports connecting to IP cameras via 3 different protocols: Private, ONVIF, and RTSP . Through these 3 protocols, you can connect to the majority of IP cameras available on the market. Private: NVR and IP cameras use the same protocol, enabling plug-and-play functionality and ...
  • Page 43 NVR User Manual 5.1.1.3 Editing and Deleting IP Camera When you need to edit or delete an already added IP Camera, you can perform the following steps: 1. In the list of added IP Cameras, click on the icon of the camera you want to edit, and you can modify the IP address of that camera.
  • Page 44 NVR User Manual 3. If you need to delete an IP camera from a specific channel, you can directly click on the delete icon of that channel to remove it. If you need to delete multiple IP Cameras from multiple channels, you can check the boxes in front of the channels you want to delete, then click on the "Delete Camera"...
  • Page 45 NVR User Manual 5.1.1.5 Advanced Setup In the Advanced Setup menu, you can perform actions such as setting default passwords, changing camera passwords, configuring PoE channel online priorities, resetting IP channel connections, and importing/exporting camera settings. Default Password  Set the default password for connecting cameras to NVR via the Private/Onvif/RTSP protocols. The default password for the Private protocol can be used to activate inactive cameras that are connected.
  • Page 46 NVR User Manual Click on the input box for the IP Camera whose password you want to change, enter the new password, then confirm it by entering the same password again. After that, click the "Apply" button to save the changes. You can also use the "Copy" button to copy the password of one IP Camera to other IP Cameras.
  • Page 47 NVR User Manual You can choose to "Prioritize Manually Added Cameras" to keep the previously manually added IP Cameras, or you can select "Prioritize PoE Cameras" to let the PoE-connected IP Cameras replace the previously manually added ones. Restore IP Channel Connection ...

  • Page 48: Live

    NVR User Manual Notes: 1. The total rated power of the PoE interface varies for different models of NVR. 2. The normal operating range of each PoE port is 0 to 30w. 3. If the actual power of a PoE port exceeds the rated power, the PoE ports will be successively shut down in order until the actual power of the PoE port is below the rated power.

  • Page 49: Image Control

    NVR User Manual Channel Name: Set the channel name. Date Format: Choose the format in which the date is displayed on the on-screen display (OSD) of the IP camera. Time Format: Select the format in which the time is displayed on the OSD of the IP camera.
  • Page 50 NVR User Manual 5.1.3.1 Image Control for Standard Day/Night Cameras For a standard day/night IP Camera, the following settings could be configured: IR-CUT Mode: Lets you choose how the camera handles image color and manages the transition between daytime and nighttime: Full Color Mode: Forced Color mode that will not switch to ...
  • Page 51 NVR User Manual Smart IR: This feature intelligently adjusts the infrared (IR) illumination intensity based on the  camera's focal length and overexposure conditions. It helps provide optimal illumination and prevents overexposure during night vision mode. Vertical Flip: Flips the image upside down. Horizontal Flip: Mirrors the image horizontally.
  • Page 52 NVR User Manual Disable: Disables defog functionality.  Auto: Camera automatically applies defogging.  Manual: Allows manually setting the defog level.  Default: Click this button to restore the factory default settings for all image parameters. 5.1.3.2 Image Control for Full Color Cameras For a full color IP Camera, the following settings could be configured: Image Mode: Set the camera's image mode, with 3 modes...
  • Page 53 NVR User Manual Light Distance: Range from 0-100, higher values increase the brightness of the white light illuminator. Vertical Flip: Flips the image upside down. Horizontal Flip: Mirrors the image horizontally. Corridor Mode: Optimizes the camera's vertical viewing angle for monitoring long, narrow scenes like hallways or corridors.
  • Page 54 NVR User Manual Disable: Disables defog functionality.  Auto: Camera automatically applies defogging.  Manual: Allows manually setting the defog level.  Default: Click this button to restore the factory default settings for all image parameters. 5.1.3.3 Image Control for Thermal Cameras If you have connected a thermal imaging IP camera, you can configure the following settings for the camera.

  • Page 55: Ptz

    NVR User Manual Edge Fusion Ratio: The higher the parameter value, the sharper the edges of objects in the fused image. Lower values make edges more blurred. Fusion Distance: The distance for fusing the optical channel and thermal channel images. Horizontal trim: Horizontal adjustment, adjusts the horizontal position of the optical channel image relative to the thermal channel in the fused view.
  • Page 56 NVR User Manual The following menu options are only applicable to supported PTZ IP cameras: Focus mode: There are three focus modes available: Auto: Automatically focuses based on scene changes.  Semi-auto: Default mode. Focuses once after panning or zooming, and does not refocus with ...
  • Page 57 NVR User Manual 5.1.4.1 Controlling Your MFZ Camera You're able to adjust the optical lens to zoom in or zoom out if a MFZ (Motorized Focus & Zoom) camera is connected. In live viewing, click the left button of your mouse on a connected camera to pop up the Camera Quick Toolbar.
  • Page 58 NVR User Manual 5.1.4.2 Controlling Your PTZ Camera In live viewing, click the left button of your mouse on the PTZ camera to pop up the Camera Quick Toolbar. Click the PTZ button to enter PTZ control panel. Mode: Select the method supported by the IP Camera for controlling PTZ. Direction Control Buttons: Clicking any of the 8 directional arrows will cause the camera's pan/tilt to make a slight movement in the corresponding direction.
  • Page 59 NVR User Manual Lens Control Buttons: Icon Function Description Clicking the key causes the lens to slightly zoom out, slightly shrinking Zoom Out the scene. Holding down the "-" key continuously zooms out the lens, resulting in continuous shrinking of the scene. Clicking the key causes the lens to slightly zoom in, slightly enlarging Zoom In the scene.
  • Page 60 NVR User Manual 5.1.4.2.1 Controlling PTZ ① ② ③ ④ ⑤ Select mode. Click the direction control buttons to rotate the camera. To adjust the speed for panning or tilting. To control the optical zoom, focus and iris of the lens. Using function control buttons: Icon Function...
  • Page 61 NVR User Manual 5.1.4.2.2 Preset Points In this section, you're able to configure the preset points. A preset point is a particular position within the image that you would like the camera to focus on. Up to 255 different preset points can be created.
  • Page 62 NVR User Manual 10. You can give a name to the preset position. 11. You can delete the preset position by clicking the Clear button 12. Click the visual icon , you will see the thumbnail of the preset position displayed at the bottom of the live view image.
  • Page 63 NVR User Manual Tour: The camera will implement the Tour function. See more details in Section 5.1.4.1.2.5  Tour. Pattern Scan: The camera will implement the Pattern Scan function. See more details in  Section 5.1.4.1.2.6 Pattern Scan. Click button to save your changes. Click button to start the Watch Mode.
  • Page 64 NVR User Manual 5.1.4.2.5 Tour With the Tour function, you are able to configure a maximum of 4 tracks of automatic cruise sequences by selecting different preset points. To make full use of this Tour function, please ensure that several preset points have already been configured. ①...
  • Page 65 NVR User Manual Change the optical zoom, focus and iris of the lens if needed. When the start position is fixed, click button to start recording. Repeat step 4 & 5 to adjust the position. Press to finish the recording of route. Click button, the camera will be moved exactly same as the route which was recorded in step 6, including zoom, focus, direction.

  • Page 66: Privacy Zone

    NVR User Manual 5.1.5 Privacy Zone This function can obscure all or part of your image for privacy (you can create up to 4 privacy masks per camera). Areas obscured by a mask won't be shown live or playback. Channel: Select a camera that you would like to edit.
  • Page 67 NVR User Manual Sensitivity: Adjust the sensitivity level. Higher numbers make the NVR more sensitive to motion detection, but it may correspondingly increase false detection. SMD by Recorder: For cameras that do not support smart motion detection. There are four detection types to choose from: Motion, Pedestrian, Vehicle, and Vehicle &...

  • Page 68: Pir

    NVR User Manual 5.1.7 PIR When you connect a PIR (passive infrared motion detector) camera, this menu enables you to configure its parameters. When a PIR alarm is detected by one or more cameras, your NVR will alert you to a potential threat. It accomplishes this by sending you an email alert with an attached image from the camera (if this option is enabled) and/or by sending push notifications via the mobile app.

  • Page 69: Roi

    NVR User Manual 5.1.8 ROI This functionality is only applicable to supported cameras. Regions of Interest (ROI) are specific areas in a video that receive focused attention. This feature enhances the image encoding quality within these selected regions and reduces the encoding quality outside them.

  • Page 70: Record

    NVR User Manual 5.2 Record The recording configuration options are available in the Record and Capture menus accessible from the Main Menu. From here, you can access and change the recording frame rate & resolution and recording schedule for each connected camera. Additionally, you can enable and set a schedule for your NVR to take a snapshot each time an event occurs.
  • Page 71 NVR User Manual Video Quality: Available only for VBR, this setting allows you to select the recording quality, which in turn defines the variable bitrate used. Config Mode: Select either User-defined mode to manually set the bitrate or Predefined mode to choose from predefined bitrate.

  • Page 72: Record

    NVR User Manual Enable: Toggle to turn on or off the audio streaming. Local Audio Volume: This is to define the volume level of the audio output on the NVR locally. Input Volume: Adjust the audio input volume. Type: Choose the audio encoding codec. 5.2.2 Record This menu enables you to set up the recording settings for every individual channel.
  • Page 73 NVR User Manual Prerecord: This allows your NVR to capture video for several seconds before an event occurs. It is recommended to keep this enabled. ANR(Automatic Network Replenishment)：Normally, videos are stored on the NVR when the network connection between the NVR and cameras is working. With the ANR (Automatic Network Replenishment) function enabled, the camera will start continuously recording to its SD card if the connection is lost.

  • Page 74: Capture Images

    NVR User Manual 4. The set recording schedule applies only to the selected channel. If you want to use the same schedule for other channels, use the Copy function. 5. If a time slot is marked in black, it means there will be no recording during that period. 6.

  • Page 75: Alarm Settings

    NVR User Manual Choose the Channel you want to set up the snapshot schedule for Click on the mode radio button to choose one of the capture modes: Normal: Snapshots will be captured according to the set normal interval (e.g., every 5 ...
  • Page 76 NVR User Manual Buzzer: When a detection event is triggered, you can enable the NVR's buzzer to provide an audible alert for a preset duration. Click the drop-down menu to select the desired time. Alarm Out: If your NVR or IP camera supports connecting external alarm output devices, the system can send an alert notification to these devices.

  • Page 77: Pir Alarm

    NVR User Manual Post Recording: This option sets your NVR to continue recording for a specified time after an event has occurred. The default selection is suitable for most cases, but you can modify it if needed. Show Message: When a detection event triggers, the alarm icon will appear on the screen.
  • Page 78 NVR User Manual Buzzer: When a detection event is triggered, you can enable the NVR's buzzer to provide an audible alert for a preset duration. Click the drop-down menu to select the desired time. Alarm Out: If your NVR or IP camera supports connecting external alarm output devices, the system can send an alert notification to these devices.

  • Page 79: I/O Alarm

    NVR User Manual FTP Video Upload: Check this box to upload video clips to your FTP server when a detection event triggers. Picture to Cloud: Check this box to upload snapshots to your cloud storage (Dropbox or Google Drive) when a detection event triggers. Video to Cloud: Check this box to upload video clips to your cloud storage (Dropbox or Google Drive) when a detection event triggers.
  • Page 80 NVR User Manual Buzzer: When a detection event is triggered, you can enable the NVR's buzzer to provide an audible alert for a preset duration. Click the drop-down menu to select the desired time. Alarm Out: If your NVR or IP camera supports connecting external alarm output devices, the system can send an alert notification to these devices.

  • Page 81: Combined Alarm

    NVR User Manual Picture to Cloud: Check this box to upload snapshots to your cloud storage (Dropbox or Google Drive) when a detection event triggers. Video to Cloud: Check this box to upload video clips to your cloud storage (Dropbox or Google Drive) when a detection event triggers.
  • Page 82 NVR User Manual Buzzer: When a detection event is triggered, you can enable the NVR's buzzer to provide an audible alert for a preset duration. Click the drop-down menu to select the desired time. Alarm Out: If your NVR or IP camera supports connecting external alarm output devices, the system can send an alert notification to these devices.

  • Page 83: Ptz Linkage

    NVR User Manual Email Alert: An email alert will be sent when a detection event triggers. Tick the checkbox if you want to disable this. (Slide to the right to view more options) FTP Picture Upload: Check this box to upload snapshots to your FTP server when a detection event triggers.

  • Page 84: Exception Alarm

    NVR User Manual Alarm: Click the setting button and select the alarm type(s) to be associated with PTZ linkage from the pop-up menu. PTZ1 ~4: Each channel can be linked with up to 4 PTZ cameras. Click the setting button below each PTZ option to select the corresponding PTZ camera channel and preset point.
  • Page 85 NVR User Manual Alarm Out: If your NVR or IP camera supports connecting external alarm output devices, the system can send an alert notification to these devices. Click button to choose the external alarm devices: Local->x: External alarm devices connected directly to the NVR. ...

  • Page 86: Alarm Schedule

    NVR User Manual 5.3.7 Alarm Schedule You can set the schedule individually for Alarm Out, Mobile Push Notification, FTP Upload, Cloud Upload, Buzzer, and Voice Prompts. By default, the schedule is enabled 24/7, but you can adjust it as needed. Select the channel you want to set the schedule for.
  • Page 87 NVR User Manual 5.3.8.1. Voice File Management You can create and delete voice files in this section. 5.3.8.1.1 Creating & Deleting Voice File The system provides 2 different methods to create customized voices: Import External Files Text-to-Speech: Import External Files: Supports importing MP3, WMA, and WAV files from a USB flash drive ...
  • Page 88 NVR User Manual Text-to-Speech: The system supports converting your plain text into a multi-language audio file  using an internet server. Choose the Text-to-Speech mode and the language you want Input the file name and plain text. The maximum length for the input text is 200 bytes. Click the Import button;...
  • Page 89 NVR User Manual 5.3.8.1.2 Auditioning Voice After creating your voice files, you can audition them using your NVR and/or IP camera's speaker. ② ④ ① ③ Select a voice file first. Choose the voice playback device. Local indicates the NVR's audio output device, IP Camera indicates the speaker or audio output device in the IP camera(s).

  • Page 90: Deterrence

    NVR User Manual To delete a loop playlist, click the delete button Click Apply to save your settings. 5.3.8.3 Voice Prompt for Alarm Events In addition to regular loop playback, you can also set dedicated alarm voices for detected alarm events.
  • Page 91 NVR User Manual Sensitivity: It has no effect here. Light: Turn the white light warning on or off. Duration: This lets you change the length of time (in seconds) the white light will remain lit when an alarm is detected. Adjust accordingly. If you have cameras with red/blue warning lights connected, you will also see the following menu options in the interface: Warning Light:...
  • Page 92 NVR User Manual Deterrence Mode: Click the drop-down menu to select a solid light (Warning Light) or a flashing light (Strobe Light). When picking Strobe Light, you can select a low, medium or high Strobe Frequency setting.  For Full Color Camera: Light: Turn the white light warning on or off.
  • Page 93 NVR User Manual When the camera is connected to the NVR with camera's Media/Client port, the setup page is  shown below: Click or drag the mouse on the schedule to select the time slots. The blue sections indicate the periods during which the warning lights will be activated if a qualifying alarm occurs.

  • Page 94: Siren

    NVR User Manual 5.3.10 Siren If the connected camera has a built-in speaker, it can be configured as a siren in addition to performing the voice intercom function. Depending on the model and features, the main setup methods are as follows: For PIR Camera: ...
  • Page 95 NVR User Manual For Deterrence Camera with Speaker:  Enable: Toggle to enable or disable the siren function. Siren Type: Used to select the siren audio file. Used to select the siren audio file. Depending on the model, the available alarm audio options may vary. Some models only allow you to select the built- in system alarm audio, while others allow you to upload up to three custom audio files.

  • Page 96: Alarm Disarm

    NVR User Manual Click on the radio button of the event you want to set. Click or drag the mouse on the schedule to select the time slots. The blue sections indicate the periods during which the warning lights will be activated if the selected alarm occurs. Click the Switch to activate the schedule.
  • Page 97 NVR User Manual Alarm Disarm: Set to enable or disable the one-click disarming function. Disarm Alarm Action: Used to set the alarm linkage types to be disarmed. All: Select or deselect all types. Buzzer: Enable to disable the buzzer when an alarm is triggered while one-click disarming is enabled.

  • Page 98: Detection Setup

    NVR User Manual 5.4 AI AI (Artificial Intelligence) technology enables advanced functions like face detection, license plate recognition, and behavior analysis by using algorithms for intelligent video data analysis, allowing the system to detect various alarm events based on face, human, and vehicle detection with AI- powered IP cameras and take corresponding actions for a smarter surveillance experience.
  • Page 99 NVR User Manual Setup: Click setup button for further settings: Channel: Select the channel you want to configure face detection for. Capture Mode: Used to set the method for capturing snapshots when a detection target is identified. Optimal Mode: Selects the best quality picture to push during the ...
  • Page 100 NVR User Manual Motion Mode: This mode exclusively detects moving targets within the frame. It focuses solely  on identifying objects in motion, ignoring stationary elements. Trigger Mode: Used to set the area and path for triggering target detection, it allows you to customize the area or path that triggers detection, enabling the system to focus on the specific areas and movement paths you are concerned about.
  • Page 101 NVR User Manual Channel: Select the channel you want to configure the detection for. Capture Mode: Used to set the method for capturing snapshots when a detection target is identified. Default Mode: Selects the best quality picture to  push during the time from when the detection target appears to when it disappears Real-time Mode: Pushes once when the detection ...
  • Page 102 NVR User Manual 5.4.1.3 Perimeter Intrusion Detection Perimeter Intrusion Detection is used to monitor predefined virtual areas for the presence of people and/or vehicles entering or exiting. Switch: To Enable or disable the Perimeter Intrusion Detection function. Sensitivity: Set sensitivity levels from 1 to 4. Higher sensitivity will trigger detection more easily, but it may correspondingly increase false detection.
  • Page 103 NVR User Manual  Rule Type, you can set the direction for detecting objects entering or exiting the detection area. A→B: Detects actions from side A to side B.  B→A: Detects actions from side B to side A.  A↔B: Detects actions from either side A to side B or side B to side A.
  • Page 104 NVR User Manual Setup: Click the configuration button to set detection conditions. Channel: Select the channel you want to configure. Detection Target: Choose the type of detection from Pedestrian and/or Vehicle. For certain models, you can further distinguish between Motor Vehicle and Non-motorized Vehicle in the detection target.
  • Page 105 NVR User Manual Note: 1) The line should not be placed too close to the edges of the camera image, as it may fail to trigger an alert when a target passes through the camera's field of view. 2) The line should not be set too short, as it may fail to trigger an alert when a target crosses over it. 5.4.1.5 Cross Counting Crossing count function counts people, vehicles, vehicles, or any moving objects that cross the virtual line.
  • Page 106 NVR User Manual Start Time: Set the start time of counting. End Time: Set the end time of counting. Recount: Clear the count number to zero and recount. Rule Number: Select the rule number. It represents the number of virtual lines on which the Crossing Count function can be enabled.
  • Page 107 NVR User Manual 5.4.1.6 Heat Map A heat map is a graphical representation that highlights areas of interest or activity within the camera's field of view. It visualizes the areas where movement or activity is most concentrated, helping to identify hotspots or patterns of activity. Switch: To enable or disable the heat map function.
  • Page 108 NVR User Manual Toggle the Rule Enable switch to turn it on. When you enable the Heat Map feature for the first time, the system will default to setting the entire screen as the detection area. If you need to adjust the detection area, click the box at the top left corner of the quadrilateral.
  • Page 109 NVR User Manual Channel: Select the channel you want to configure. Min./Max. Pixels: Set the minimum and maximum pixel sizes for detected target to be recognized. Max capacity: Used to set the maximum number of people allowed in the detection area. When the system detects that the number of people in the area exceeds this limit, it can trigger corresponding alarm actions.
  • Page 110 NVR User Manual 5.4.1.8 Queue Length Detection Queue length detection is a video analytics feature used to monitor and analyze the status of queues or waiting lines. It provides insights into the length of the queue and the stall time (the duration for which people have been waiting in the queue).
  • Page 111 NVR User Manual Click any corner box and drag to adjust the size. You can also click any edge and drag to move the entire octagon. Bounding Box: When enabled, a green bounding box will be displayed on the images, outlining and identifying detected targets.
  • Page 112 NVR User Manual Sensitivity: Set the sensitivity level, ranging from 1 to 100. The higher the value, the more easily it will be triggered. Detection Target: Select the type of license plate, such as American license plates, European license plates, etc. Detection Mode: This setting determines the method used to detect targets within the camera's field of view.
  • Page 113 NVR User Manual Note: Enabling the License plate Enhance will cause the camera's brightness to be adjusted according to the set brightness value. The day and night levels will automatically switch based on whether the camera's infrared mode is enabled or not, without interfering with each other. To use License Plate Enhance, you need to set Exposure Compensation to Off and Shutter to Auto mode on the Image Control page (refer to section 5.1.3 Image...
  • Page 114 NVR User Manual 5.4.1.11 Object Detection The Object Detection function identifies objects that are left behind or lost within a predefined region. This includes items such as baggage, purses, or potentially dangerous materials. Switch: Check the box to enable the Object Detection function. Sensitivity: Set sensitivity levels from 1 to 4.
  • Page 115 NVR User Manual  Rule Type, you can select how the system should detect objects: Legacy: The system will detect if any items are left behind within the defined region  Loss: The system will detect if any items are missing from the defined region ...
  • Page 116 NVR User Manual Volume Intensity: Set the intensity level from 1-100 for the triggered sound alarm. Higher values correspond to louder alarm volumes. Decline Detection: Enable or disable detection of decreasing sound levels. Decline Sensitivity: Set the sensitivity for triggering sound decline detection from 1-100. A higher value increases the sensitivity to detect decreasing sound levels.
  • Page 117 NVR User Manual 5.4.1.14 Intrusion Detection Intrusion detection can detect whether there is an object invading the set restricted area in the video. This feature is useful for monitoring restricted areas and detecting unauthorized entry or trespassing activities.It helps enhance security and surveillance in locations such as warehouses, construction sites,or other restricted premises.
  • Page 118 NVR User Manual The method for setting the detection area is as follows: Select an area number from Rule Number. Toggle the Rule Enable switch to turn it on. In the preview screen, use your mouse to click eight points on the camera image to draw a octagonal.
  • Page 119 NVR User Manual Channel: Select an available to configure. Loitering Duration: It indicates the time duration (in seconds) an object must remain in the alert area before triggering an alarm. For example, if set to 5, the alarm will trigger immediately after the target has invaded the area for 5 seconds.
  • Page 120 NVR User Manual  After making adjustments, click the Save button to save the changes. If you need to delete a specific area, click the box next to the area number you want to delete in the preview screen, then click Remove to delete it.
  • Page 121 NVR User Manual Channel: Select an available to configure. Loitering Duration: It indicates the time duration (in seconds) an object must remain in the alert area before triggering an alarm. For example, if set to 5, the alarm will trigger immediately after the target has invaded the area for 5 seconds.
  • Page 122 NVR User Manual 5.4.1.17 Fire Detection If there is a thermal imaging camera connected to your NVR, the Fire Detection functionality becomes available. This menu allows for the configuration of settings related to fire detection. By utilizing thermal imaging technology, the system can identify temperature anomalies indicative of fire outbreaks.
  • Page 123 NVR User Manual Temperature Measurement Detection Settings  Enable: Enable/disable the temperature measurement function. Temperature Color Bar: When enabled, a color bar representing different temperature ranges is displayed on the right side of the thermal imaging channel preview, along with the max and min temperatures.
  • Page 124 NVR User Manual Reflective Temperature: Sets the ambient temperature of the camera's environment. Note: Reflected temperature refers to the ambient temperature reflected off the surface of the object being measured. Thermal radiation reflected off an object's surface is affected by the ambient temperature.
  • Page 125 NVR User Manual varying emissivity levels, leading to different degrees of infrared reflection and absorption, which can cause deviations in temperature measurement if not accounted for. Distance Unit: Options for meters or inches. Distance: Indicates the straight-line distance between the target being measured and the device's location, which should be set according to the actual setup.
  • Page 126 NVR User Manual Area: Click and drag on the right preview to draw a quadrilateral area-based temperature  measurement rule. This indicates the entire area will be monitored for temperature. Click the rule's checkbox to resize and reposition the area. The preview displays the rule and temperature information for that entire region.
  • Page 127 NVR User Manual Tolerance Temperature: Allows setting a temperature tolerance range to prevent rapidly fluctuating temperatures from triggering/clearing the alarm repeatedly. For example, if the alarm rule is "Above(Average.Temperature)", the Alarm Temperature is set to 40°C, the Duration Time is set to 3 seconds, and the Tolerance Temperature is set to 3°C, then the alarm will be triggered when the average monitored temperature exceeds 40°C continuously for more than 3 seconds.
  • Page 128 NVR User Manual Click on the radio button of the event you want to set. Click or drag the mouse on the schedule to select the time slots. The blue sections indicate the periods during which the warning lights will be activated if the selected alarm occurs. Click the Switch to activate the schedule.

  • Page 129: Ai Recognition

    NVR User Manual Once your settings are complete, click the "Apply" button to save them. 2 AI Recognition AI Recognition primarily serves to allow users to configure and manage the artificial intelligence algorithm models used for video analytics, as well as the related face and license plate databases, so that recognized faces and license plates can be categorized and managed.
  • Page 130 NVR User Manual The face AI algorithm mainly includes two parts: Detection and Recognition. Detection is mostly used to detect and capture face images. Generally, the detection capability is  provided by IP cameras. Recognition is mostly used to extract, analyze and compare facial features. Recognition ...
  • Page 131 NVR User Manual 5.4.2.2 Face Recognition Database Management You're able to create and manage face profiles (databases) to classify different people into different groups in order to quickly identify individuals remotely and enable intelligent alarms in advance. There are 3 default groups: Allow List: Mostly used to define a list of people regarded as acceptable or trustworthy, such as ...
  • Page 132 NVR User Manual From the Group window, click the "Import" button, then click the "Local Storage Device" button. On the pop-up page, perform the following operations in order to select the face image(s): First, select the channels you need to search on. All channels are set to search by default. You can specify the cameras you want to search on.
  • Page 133 NVR User Manual Tick the checkbox to select individual face images, or tick "Select All" to select all face images in the current page of search results. Once you've selected one or more face images, click the "OK" button. The system will go to the profile edit page.
  • Page 134 NVR User Manual 5.4.2.2.2 Create Individual Face Profile from External Storage Device Copy the face images to your USB flash drive, and then insert the USB device into the USB port of the NVR. Note: The supported image formats are .jpg, .jpeg, .png, and .bmp. The supported image dimensions are from 80x80 to 800x800 pixels, and the maximum file size is 500KB.
  • Page 135 NVR User Manual Click on the face image you want to import, and then click the "OK" button. Edit the face profile details of the person, such as name and age. Click the setup button next to the "Name" field to configure the voice prompt for the person. to learn how to set up this feature.
  • Page 136 NVR User Manual Click the setup button next to "Alarm Channel" to configure the Alarm Channel. The system will trigger an alert when the face is detected and captured by the selected cameras. 10. Click the "Import" button to import the face profile. 11.
  • Page 137 NVR User Manual 5.4.2.2.3 Create Bulk Face Profiles from External Storage Device If you want to create a batch of face profiles at once, please proceed as follows: Click the "Edit" button of the group you would like to create face profiles for. Insert your USB flash drive, and then click the "Download Import Template"...
  • Page 138 NVR User Manual Copy the extracted "facetemplate.csv" file and the previously prepared face images into this new folder. Ensure the image formats are .jpg, .jpeg, .png, or .bmp, with dimensions between 80x80 and 800x800 pixels, and file size no more than 500KB. Double click on the "facetemplate.csv"...
  • Page 139 NVR User Manual Please Note: If you input an uninterrupted number more than 11 digits in a cell, the system will display it in scientific notation, e.g. "1.23457E+11". If so, you need to adjust the column format to "Text". Good Select the column (especially ID code and phone number columns) and right-click.
  • Page 140 NVR User Manual 14. Find and click on the "facetemplate.csv" file from your USB drive, then click OK. 15. The face profiles are shown here. Click the Import button to import the face profiles into the NVR. 5.4.2.2.4 Edit Face Profiles If you want to edit or delete a face profile, please proceed as follows: Click on the edit button of the group you want to edit.
  • Page 141 NVR User Manual In the group edit page, you're able to execute the following operations: Import: To import face images.  Export: To export face image(s) to external USB flash drive.  Click Export button directly to export all face images in this group. ...
  • Page 142 NVR User Manual Choose the target group, and then click OK. Delete: To delete the selected face profile.  Detail Information: Click to view the details of the selected face profile.  5.4.2.3 License Plate Management The License Plate Management menu allows you to set up and maintain a database of vehicle license plates organized into different groups.
  • Page 143 NVR User Manual Allow List: Mostly used to define a list of vehicles that are regarded as acceptable or  trustworthy. Block List: Mostly used to define a list of vehicles that are regarded as unacceptable or  untrustworthy and should be excluded or avoided. Unknown: All ungrouped vehicles will be identified as unknown vehicles.
  • Page 144 NVR User Manual On the pop-up page, perform the following operations in order to select the vehicle license image(s): First, select the channels you need to search on. All channels are set to search by default. You can specify the cameras you want to search on. Use the calendar to specify the date range.
  • Page 145 NVR User Manual You will now see a list of license plate numbers. Click on one of the license numbers, and the detailed information will be listed on the right side. You're able to edit the information, including license plate number, color, brand, model of the vehicle, and the owner's profile. Click "Import"...
  • Page 146 NVR User Manual In the pop-up window, enter the license plate details, including the number, color, brand, model/type of the vehicle, and the owner's information. Click the setup button next to the "License Plate" field to configure the voice prompt for the vehicle.
  • Page 147 NVR User Manual 5.4.2.3.3 Create Bulk License Profiles If you want to create multiple license plate profiles at once, follow these steps: Insert your USB flash drive into the USB port of the NVR. Click the edit button of any one of groups that already contains at least one existing vehicle license plate profile.
  • Page 148 NVR User Manual Select the directory where you want to save the exported file, and then click "OK". On your computer, double-click the exported ".csv" file to open it with a spreadsheet program like Excel. The file contents will be displayed with the following column headers: Column A: License plate number ...
  • Page 149 NVR User Manual Edit the cells in the spreadsheet according to the actual information for the new license plates you want to add: Please Note: If you input an uninterrupted number more than 11 digits in a cell, the system will display it in scientific notation, e.g.
  • Page 150 NVR User Manual 11. Click "Import from CSV", select the ".csv" file from the USB drive, and click "OK". 12. You will now see a list of license plate numbers. Click on a number to view its detailed information on the right side. Click "Import" to import all the new profiles into the NVR, then click "Exit"...
  • Page 151 NVR User Manual 5.4.2.3.4 Edit License Profiles If you need to edit or delete an existing license plate profile, follow these steps: Click the edit button of the group containing the vehicle license plate profiles you want to modify. To edit a license plate profile's information, click the edit button next to the license plate number you want to change.

  • Page 152: Ai Alarm Settings

    NVR User Manual If you want to delete, move or export license profile(s), please proceed as below. Tick the checkbox to select First, tick the checkbox next to each profile you want to take action on If deleting, click the "Delete" button and confirm to permanently remove the selected ...
  • Page 153 NVR User Manual Buzzer: When a detection event triggers, you can enable the NVR's buzzer to provide an audible alert for a preset duration. Click the drop-down menu to select the desired time. Alarm Out: If your NVR or IP camera supports connecting external alarm output devices, the system can send an alert notification to these devices.
  • Page 154 NVR User Manual Full Screen: Check this box to display the triggered camera feed in full-screen Live View mode when a detection event triggers. Event Push Platform: Check this option to push notifications of this alarm event type to the client software/app when triggered.
  • Page 155 NVR User Manual Alarm: Click setup button to specify the actions the NVR should take when a face recognition event occurs for this group Buzzer: When a detection event triggers, you can enable the NVR's buzzer to provide an audible ...
  • Page 156 NVR User Manual Voice Prompts: If your NVR is connected to a speaker, you can select a customized voice alert to  play when a detection event triggers. See section for adding custom voice 5.3.8 Voice Prompts alerts. Alarm Schedule: Click setup button to configure the schedule for when this group's alarm actions will be active.
  • Page 157 NVR User Manual Alarm Type: Select the facial attribute that you need to detect. No Mask: When a person is detected without wearing a face mask, the NVR will take the  corresponding actions based on the configured alarm behaviors. Wear Mask: When a person is detected wearing a face mask, the NVR will take the ...
  • Page 158 NVR User Manual Email Alert: An email alert will be sent when a detection event triggers. Tick the checkbox if you want to disable this. Full Screen: Check this box to display the triggered camera feed in full-screen Live View mode when a detection event triggers.
  • Page 159 NVR User Manual plate is allowed to differ from the license plate numbers saved in the group. If the number of differing characters between the detected license plate number and a license plate profile in the group is no more than the set Fault Tolerance value, the detected license plate will be considered a recognized match.
  • Page 160 NVR User Manual Local->x: External alarm devices connected directly to the NVR.  CHx->1: External alarm devices connected to the IP cameras.  Latch Time: Configure the duration for which external alarms will be activated when a detection  event triggers. Capture Face: When a face is detected, a snapshot of the face will be captured and saved.
  • Page 161 NVR User Manual Alarm Schedule: Click setup button to configure the schedule for when this group's alarm actions will be active. Click or drag the mouse over the schedule to select the time slots. The blue sections indicate the active periods when the configured alarm actions will be triggered if a qualifying event occurs. The schedule applies only to the currently selected camera channel.
  • Page 162 NVR User Manual Buzzer: When a detection event triggers, you can enable the NVR's buzzer to provide an audible alert for a preset duration. Click the drop-down menu to select the desired time. Alarm Out: If your NVR or IP camera supports connecting external alarm output devices, the system can send an alert notification to these devices.

  • Page 163: Statistics

    NVR User Manual Full Screen: Check this box to display the triggered camera feed in full-screen Live View mode when a detection event triggers. Event Push Platform: Check this option to push notifications of this alarm event type to the client software/app when triggered.
  • Page 164 NVR User Manual 5.4.4.1 Statistics of Face Recognition You can retrieve and present statistical data related to face recognition when it is enabled on the cameras. It can display bar chart and pie chart for the selected channels, categorized by group, in the form of Day, Week, Month, Quarter, and Year reports Bar Chart: Displays the number of faces detected during a particular time period.
  • Page 165 NVR User Manual At the bottom of the page, three quick access buttons related to face recognition are provided: Face Search, Repeat Visitors, and Face Attendance. For detailed instructions on using these features, 7.9 AI Search please refer to section in the manual.
  • Page 166 NVR User Manual 5.4.4.3 Statistics of Cross Counting If cross counting detection is enabled on the cameras, you can retrieve and analyze statistical data on objects or pedestrians crossing the designated counting lines for each channel. 1. Select Channel and Date: Choose the specific camera channel and date range for your analysis. 2.
  • Page 167 NVR User Manual 5.4.4.4 Statistics of Heat Map You can retrieve and visualize statistical data related to object detection when the Heat Map is enabled on cameras. This feature provides a color-coded visual representation of areas and the frequency of detected motion. To access and analyze Heat Map statistics: Select Channel: Choose the specific camera channel from which you want to obtain heat map data.
  • Page 168 NVR User Manual This intuitive display allows you to quickly identify hotspots of activity and understand movement patterns within the monitored area. It can be particularly useful for optimizing camera placement, improving security measures, or analyzing customer behavior in retail environments. In addition to the heat map, you can also choose to view the data in the form of a bar chart.

  • Page 169: Network

    NVR User Manual 5.5 Network You can configure network-related settings in this menu. 5.5.1 General Settings In this menu,you can configure the basic network connection parameters for your NVR. 5.5.1.1 General In this menu, you can configure the basic parameters of the network interface card (NIC). Depending on the model, there may be configurations with one RJ45 NIC or two RJ45 NICs.
  • Page 170 NVR User Manual Gateway: This allows your NVR to connect to the internet and is typically the same IP address as  your modem or router. The format of the Gateway address is the same as the IP Address. For example, "192.168.001.001".
  • Page 171 NVR User Manual 2) For devices with two NICs, please refer to the following configuration method: Network Card Mode: Switch between Single Address Mode or Double Address Mode. This determines how the two NICs on the NVR device will operate. Choosing the appropriate mode based on your network environment and requirements can improve network performance, add redundancy backups, and enhance system reliability.
  • Page 172 NVR User Manual 3) When selecting Double Address Mode, please ensure the two NICs' IP addresses are not set in the same subnet, otherwise it will cause errors and the network cannot work properly. Network Card Selection: Switch to display the network parameter information for LAN1 (NIC1) or LAN2 (NIC2).
  • Page 173 NVR User Manual IPv6 Address: Input the IPv6 IP address if your network service supports IPv6. It consists of eight  groups of characters between 0 to FFFF, separated by colons. For example, "ABCD:EF01:2345:6789:ABCD:EF01:2345:6789". IPv6 Gateway: Input the IPv6 gateway address. The gateway address is used to route traffic ...
  • Page 174 NVR User Manual 5.5.1.2 PPPoE Settings Enable PPPoE networking, the device can connect to the network via dial-up. Enable PPPoE: Set the "Enable PPPoE" switch to the enabled state. This will allow the NVR to connect to the network via a dial-up connection using PPPoE. PPPoE Network Card Select: If your device has NICs, select the appropriate LAN port that you want to use for the PPPoE dial-up connection.
  • Page 175 NVR User Manual Note: Before setting SNMP parameters, users need to download SNMP software to receive NVR  information through the SNMP port, such as software version number, device type, channel IP , resolution, frame rate, etc. Set the Trap management address, and the NVR can send alarm and exception information to ...
  • Page 176 NVR User Manual Some NVR models support accessing the internet by connecting to a wireless Wi-Fi dongle. When the Wi-Fi dongle is inserted, users can connect to a Wi-Fi network through the configuration page. Ensure the Wi-Fi dongle is plugged into an available USB port on the NVR. This will allow accessing the Wi-Fi configuration tab/page.
  • Page 177 NVR User Manual 5.5.1.5 Port Configuration This menu is primarily used to set the port numbers for the NVR to connect and be accessed from external networks. Correctly configuring these ports is crucial to ensure the NVR can be properly accessed and controlled over the local network or the internet.

  • Page 178: Ddns

    NVR User Manual users remotely access the NVR. Incorrect external port configuration may prevent access to the NVR from the internet. To perform port forwarding for the External Port, you can select Manual Auto in the "Mapping Strategy". If you choose the manual mode, you need to manually enter an External Port number, and then set up port forwarding for this port on your router that the NVR is connected to.

  • Page 179: Email Settings

    NVR User Manual After entering all parameters, click "Test" to verify the DDNS settings. If the test result is "Network unreachable or DNS error", please check if your network is functioning normally and if the DDNS information is correct. Once you've set up DDNS, you can access the NVR remotely through the domain name using a web browser, in the format http://[applied domain name]:[mapped HTTP port number].
  • Page 180 NVR User Manual 5.5.3.1 Email Configuration Email: Check this box to enable email notifications. Encryption: Enable if your email server requires SSL or TLS verification. If unsure, select Auto. SMTP Port: Enter the SMTP port of your email server. SMTP Server: Enter the SMTP server address for your email service.
  • Page 181 NVR User Manual 5.5.3.2 Email Schedule By default, if email alerts are enabled on your NVR, they will be sent 24 hours a day. You can customize this schedule to determine when your NVR sends these alerts. For example, you may prefer to receive alerts only during daytime hours.

  • Page 182: Ip Filter

    NVR User Manual 5.5.4 IP FILTER IP Filtering is an effective method to control access to your network devices for specific groups of IP addresses. By using IP Filters, you can set up allow lists of trusted IP addresses to access the device, or use block lists to prohibit specified IP addresses from accessing the device.

  • Page 183: Voice Assistant

    NVR User Manual Click "Save" to save your changes.  When you have finished setting up the Allow List and Block List, click either "Enable Allow List" or "Enable Block List" to activate the IP Filter function. Please note that the system can only execute either the Allow List or the Block List at any given time, not both simultaneously.
  • Page 184 NVR User Manual Connect the Fire TV Stick to your TV and power it on. Ensure the Fire TV Stick is connected to the same Wi-Fi network as your NVR. On the Fire TV Stick, use your existing profile or add a new one, and log in with the same Amazon account you linked to the NVR.
  • Page 185 NVR User Manual Touch "More", and then tap "Skills & Games". Tap the search icon in the top right corner.
  • Page 186 NVR User Manual Enter the keyword "smart camera view" and search. Tap the "Smart Camera View" app in the search results. Then tap "ENABLE TO USE".
  • Page 187 NVR User Manual 10. Link your Amazon account by signing in with the same account you linked to the NVR. Tap "Done" after successfully linking the skill. 11. Tap "DISCOVER DEVICES" and wait for the app to find the cameras. Tap "Next" when the devices are found and connected...
  • Page 188 NVR User Manual 12. Choose a device and tap "SET UP DEVICE". You can add the camera to a group or skip this step. 13. Repeat step 12 for all cameras, then tap "Done" to finish.
  • Page 189 NVR User Manual 14. All added cameras will be listed under Devices. Tap the "Cameras" icon to view all added cameras. 15. Press and hold the voice button on the Fire TV Stick remote and speak your command clearly. For example, say "Show the [camera name]" or "Show [camera name]". If your camera is named "Office", you could say "Show my office camera"...
  • Page 190 NVR User Manual 16. Shortly, you should see real-time images from the requested camera on your TV.  17. To exit the camera live view, say "Stop". 18. If you change a channel's name, you'll need to rediscover and add that camera again. 5.5.5.2.
  • Page 191 NVR User Manual Search for and install the Google Home app on your mobile phone from the app store. Run the installed Google Home app, tap "OK" to allow the app to use your local network and Bluetooth, and then tap "Get Started". To login with the same Google account you linked to the NVR.
  • Page 192 NVR User Manual Allow location access for the app The app will automatically try to search for devices on your local network. Choose Chromecast / Google TV. Ensure your Chromecast is turned on, then tap "Next. " 10. Your Chromecast will be found. Tap "Next" to connect. Confirm the code by tapping "Yes. "...
  • Page 193 NVR User Manual 11. Choose a location for your Chromecast, then tap "Next". 12. Choose the Wi-Fi network for your Chromecast and input the Wi-Fi password to connect. Ensure the Wi-Fi you choose is the same one your mobile phone is connected to and is on the same local network as your NVR.
  • Page 194 NVR User Manual 14. Tap "Next, " "Skip Tutorial, " and then "Finish Tutorial. " 15. Now the Chromecast has been added to your Google Home. Tap the + icon in the top left corner, and then select "Set up device". 16.
  • Page 195 NVR User Manual 17. Tap on "Smart Camera View" in the search results. You will need to sign in to your Google account and allow Google to access your device. 18. Wait for a moment, and the Smart Camera View application will be linked to Google Home.. 19.
  • Page 196 NVR User Manual 20. Search for and install the Google Assistant app on your mobile phone from the app store. 21. Run the Google Assistant, and log in to your Google account, ensuring it is the same one you linked to the NVR. 22.

  • Page 197: Platform Access

    NVR User Manual 5.5.6 Platform Access This section is primarily used to configure protocols for connecting to third-party platforms. Through these protocols, you can integrate the NVR with third-party platforms to stream video or push event information. 5.5.6.1 Onvif This function is primarily used to connect the NVR to third-party platforms. Enable: Enable switch.
  • Page 198 NVR User Manual Register a YouTube account and create a live streaming studio.  Set the URL and live code of the live streaming studio.  Set the live server address on the NVR.  Enable and configure the code stream type and live broadcasting channels. ...
  • Page 199 NVR User Manual Note: To ensure optimal live broadcasting quality, it is recommended that the resolution of the stream  does not exceed 1920 × 1080. Live broadcasting is supported only for data streams using the H.264 video encoding format ...
  • Page 200 NVR User Manual User Name: User name of the third-party platform Password: Password of the third-party platform Server Address: Address of the third-party platform Port: Port of the third-party platform server (range 1-65535) URL: API endpoint of the third-party platform server Method: Type of HTTP push.

  • Page 201: Storage

    NVR User Manual 5.6 Storage This section is primarily responsible for managing local and remote storage for the NVR, including hard disk storage management, cloud storage configuration, and settings for FTP remote backup storage. It provides users with multiple storage choices to meet different data storage and backup needs.
  • Page 202 NVR User Manual Select the relevant option, then click "OK". Input your password, then click "Authenticate". A message will appear noting the data that will be erased. Click "OK" to continue. Overwrite: This instructs your NVR to overwrite the oldest video files as the hard drive becomes full. You also have the option of selecting the amount of days for recordings to be kept before they are overwritten.
  • Page 203 NVR User Manual User Name: Enter the NAS account name (In NFS mode, it is in an unselectable state) Server IP: Enter the IP address of NAS storage. Password: Enter the NAS password (In NFS mode, it is in an unselectable state) Directory Name: Input the directory name on which you want to save your recording data.
  • Page 204 NVR User Manual 5.6.1.1 Disk Group If your NVR supports installing multiple hard disks, and more than one hard disk is already installed in your NVR, you will see this menu. With the Disk Group function, you can assign different cameras to different hard disks for recording, in order to reduce the loading on a single hard disk and extend the life of the hard disk.
  • Page 205 NVR User Manual 5.6.1.2 S.M.A.R.T The S.M.A.R.T feature is used to display technical information on the hard drive installed inside your NVR. You can also perform a test to evaluate and detect potential drive errors. Self-check Type: There are three types available: Short: This test verifies major components of the hard drive such as read/ write heads, ...

  • Page 206: Cloud Storage

    NVR User Manual 5.6.2 Cloud Storage Your NVR can upload snapshots and video recordings to cloud storage via Dropbox™ or Google Drive™, allowing you to store and access these files remotely whenever needed. Cloud Type: Select whether to use Dropbox or Google Drive. Cloud Status: This will indicate "Activated"...
  • Page 207 NVR User Manual 5.6.2.1 Dropbox Settings Before activation, we recommend creating a Dropbox account first at www.dropbox.com if you don't have one already. Choose "DROPBOX" from the "Cloud Server" dropdown menu. Click "Activate Cloud", and the system will send an activation email to the address configured in Email Setup. Open the email and click the link to go to the cloud server authorization login page.
  • Page 208 NVR User Manual Enter the DVR's local IP address and web port, then click Authorize. Enter the DVR's username and password, then click OK. Once authorized, the webpage will open your Dropbox. Cloud setup is complete if you find a new folder named with your NVR's device name and MAC address in Dropbox, where alarm pictures and videos will be uploaded.
  • Page 209 NVR User Manual 5.6.2.2 Google Drive Settings Before activation, create a Google Drive account at https://www.google.com/drive/ if you don't have one. Choose "Google Drive" from the "Cloud Server" dropdown menu. Click Activate Cloud, and an activation email with a code will be sent. Open the email, click the link, enter the activation code, and click Next.

  • Page 210: Ftp

    NVR User Manual Click Allow to complete setting up your Google Drive cloud storage. 5.6.3 FTP This menu allows you to configure FTP settings for uploading captured snapshots or videos to your FTP server.
  • Page 211 NVR User Manual 5.6.3.1 FTP Settings FTP Enable: Check this box to enable the FTP function. Server IP: Enter the IP address or domain name of your FTP server. Port: Enter the FTP port for file transfers. User Name/ Password: Enter the username and password for the FTP server.
  • Page 212 NVR User Manual 5.6.3.2 FTP Schedule If FTP upload is enabled, alarm images or videos are uploaded 24/7 by default. You can schedule when your NVR uploads alarm images/videos, for example only during daytime hours. Select the camera channel to schedule. Click the checkbox for the alarm type to upload: Motion: Upload for motion detection alarms ...

  • Page 213: System Configuration

    NVR User Manual 5.7 System Configuration Change system information such as date, time and region, change passwords and permissions, and more. 5.7.1 General Modify general system parameters like language, date & time, display and more. 5.7.1.1 General settings Device Name: Customize the name for your NVR if desired.
  • Page 214 NVR User Manual Video Format: Select the video standard for your region. Idle Lock Time: Set the idle timeout period for automatically exiting the main menu and locking the system when there is no operation. Choose a desired timeout duration from the dropdown menu, or select "OFF"...
  • Page 215 NVR User Manual NTP Settings The Network Time Protocol (NTP) automatically syncs your NVR's clock with an internet time server for accurate date/time stamping. Check "NTP", select a "Server Address", and click "Update Now" to instantly sync. With NTP enabled, the time will auto-update daily at 00:07:50 or on system boot.
  • Page 216 NVR User Manual 5.7.1.4 Output Configuration This menu allows you to configure video output parameters. Cycle Mode: Select how many video channels to display simultaneously when your NVR is in cycle mode. Cycle Dwell Time: Enter the maximum duration in seconds to display each set of video channel(s) in cycle mode before switching to the next set (maximum 300 seconds).
  • Page 217 NVR User Manual For NVRs with multiple HDMI outputs, these settings specifically configure the main HDMI1 output. 5.7.1.5 Auxiliary Screen & Decoding When your NVR is configured with 2 or more HDMI interfaces, you can configure the output parameters individually for the auxiliary HDMI outputs besides the main HDMI1 output in this menu. In the HDMI menu, select any auxiliary HDMI output other than the main HDMI1 output that you want...
  • Page 218 NVR User Manual Cycle Mode: Select the number of video channels to display simultaneously during each dwell period of the cycling sequence. Dwell Time: Set the duration, in seconds, for how long each view will be displayed during the preview cycling on the auxiliary screen. Auto Cycle Setting: Choose which channels will participate in the automatic cycling display on the auxiliary screen.

  • Page 219: Multi-User

    NVR User Manual 5.7.1.7 Privacy Statement Click this menu to view the Privacy Statement. 5.7.2 Multi-user This menu allows you to configure usernames, passwords, and user permissions. The system supports the following account types: ADMIN — The system administrator has full control of the system and can change both ...
  • Page 220 NVR User Manual 5.7.2.1 Edit Users You can edit a user's password, enable or disable a user, and set permission. Click the edit button of the user you want to configure. 1) For the Admin account, you can: Change password: The password must be a combination of 8 to 16 characters, including at ...
  • Page 221 NVR User Manual Enable or disable "Unlock Pattern": When enabled, you can draw and save a pattern. You can  then use this pattern to unlock the NVR when you log in to the system. "Max. Login Number": This limits the maximum number of simultaneous remote access ...
  • Page 222 NVR User Manual 5.7.2.2 Edit User Permissions The administrator account is the only account with full control of all system functions. After logging in with the administrator account, you can enable or disable access to specific menus and functions for other user accounts. Click the "Permission"...

  • Page 223: Maintenance

    NVR User Manual 5.7.3 Maintenance In this section, you can search and view system logs, restore default settings, upgrade the system, export and import system parameters, manage system auto-reboot, and perform other maintenance tasks. 5.7.3.1 System Log The NVR logs all system actions and detected events. These log files can be searched, viewed, and exported to a USB flash drive for backup purposes.
  • Page 224 NVR User Manual System: Logs related to system settings, reboots, auto-reboots, upgrades, time settings,  and NTP time synchronization. Configuration: Logs associated with parameter modifications and configurations, such as  recording mode settings, recording schedule settings, network settings, image control, multi-user settings, etc.
  • Page 225 NVR User Manual 5.7.3.3 Reset Button Some models have a Reset button on the rear panel to restore factory settings. Press and hold this button for 10 seconds to restore the NVR to its factory settings. This button is typically used when you forget the user password.
  • Page 226 NVR User Manual 5.7.3.4.1 Upgrade via USB Flash Drive Copy the firmware file (generally with a ".sw" extension) to your USB drive, and insert the USB flash drive into the NVR's USB port. Click the "Select File" button to choose the firmware file on your USB flash drive, then Click OK. Click the "Upgrade"...
  • Page 227 NVR User Manual 5.7.3.4.2 Online Upgrade The device supports over-the-air (OTA) firmware upgrades. To use this function, you need to set up the upgrade server in advance, and correctly fill in the following information: Username: Used to set the server user name. If the server is not configured with a user account, this parameter can be left blank.
  • Page 228 NVR User Manual upgradeable firmware is found, a prompt message will be displayed to notify the user to proceed with the upgrade. You can also click the "Detect Now" button to manually check if the server has any upgradeable firmware available. When it is detected that the server has an upgradeable firmware, the "Upgrade" button becomes available.
  • Page 229 NVR User Manual 5.7.3.7 Developer Mode This is an advanced feature on certain NVR models. When you report a defect, authorized professionals may request you to perform certain operations to obtain the NVR's internal debug logs after reproducing the issue. This helps them quickly locate and identify the problem. In this menu, you can manage the debug logs for both the NVR and IP cameras.

  • Page 230: Ip Camera Maintain

    NVR User Manual 2) For IP Cameras The system supports collecting debug logs from cameras through the NVR (this feature requires camera support) and exporting them to a USB drive. In the "Camera Debug" menu, the system will, by default, enable this feature for all cameras that support it. If a channel number is grayed out, it indicates that the camera does not support this feature.
  • Page 231 NVR User Manual 5.7.4.1 Upgrade IP Cameras Select the individual or multiple IP cameras of the same model that you wish to upgrade Click the "Select File" button to choose the update file from your USB flash drive, then click "OK". Click the "Camera Upgrade"...
  • Page 232 NVR User Manual 5.7.4.2 Load Default Settings for IP Cameras Choose the IP camera(s) you want to restore. Click Load Default to restore settings. You will be required to input the Admin's password to authenticate. 5.7.4.3 Reboot IP Cameras In case of any issues, choose the camera(s) and then click "Reboot Camera"...
  • Page 233 NVR User Manual 5.7.4.4 Parameter Management Select the camera(s), and then click the "Save Settings" button to export the configuration file  containing all the settings that you have customized to your USB flash drive. To load settings, click the "Load Settings"...

  • Page 234: System Information

    NVR User Manual 5.7.5 System Information In this menu, you can view basic information about the NVR, such as device model, firmware version, channel details, network parameters, and more. 5.7.5.1 Information This menu displays technical information about your NVR, including hardware and software versions, IP address, network ports, MAC address, and other relevant details.
  • Page 235 NVR User Manual If your NVR supports P2P functionality, you will find the P2P ID and P2P QR code on the information page. You can scan this QR code with a mobile app to remotely view the NVR. 5.7.5.2 Channel Information View channel information for each connected camera.

  • Page 236: Chapter 6 Ai Scenario

    NVR User Manual Chapter 6 AI Scenario The AI Scenario function offers AI applications tailored for specific scenarios. Click on the submenu title on the main setup page to access the setup page for each individual function. 6.1 Cross Counting This AI application is based on cross-counting functionality.

  • Page 237: Introduction Of Real-Time Display & Controls

    NVR User Manual 6.1.1 Introduction of Real-time Display & Controls ⑥ ① ④ ② ⑤ ③ 1. Navigation Bar Icon Item Description This mode counts and displays real-time results for individual cameras. It is suitable for small spaces with a Individual Mode single entrance and exit.
  • Page 238 NVR User Manual 2. Real-time Counting Statistics Item Description Available Remaining allowed attendance number Inside Current attendance number inside the controlled area Enter Total recorded number of entrants Exit Total recorded number of attendees leaving 3. Screen Display Controls Icon Item Description Allows switching between different layout views...

  • Page 239: Settings Of Individual Mode

    NVR User Manual 5. Statistic Data Chart The all-day counting statistical data for all activated channels will be displayed here. Use the mouse wheel to navigate through the timeline. 6. Full Screen Display Click to expand the Real-time Counting Statistics Information Bar to full screen. Right-click to exit full screen mode.
  • Page 240 NVR User Manual Tick the checkbox of "Enable" for the channel(s) where you want to enable counting. The Setup & Alarm icon will appear in blue if the camera supports AI functions; conversely, if the camera does not support AI functions, the icon will be grayed out. ②...

  • Page 241: Settings Of Grouped Mode

    NVR User Manual Buzzer: Set the buzzer duration in seconds when the Available number is 0.  Alarm Out: If your NVR supports connecting to an external alarm device, you can set it to  emit an alarm tone. Latch Time: Set the duration for the external alarm when the Available number is 0. ...
  • Page 242 NVR User Manual Click the add icon to add channel(s) to the group. Max. 8 groups can be set, and each individual channel can be added to 1 group only. A maximum of 8 groups can be set, and each individual channel can only be added to 1 group.
  • Page 243 NVR User Manual Alarm Out: If your NVR supports connecting to an external alarm device, you can set it to  emit an alarm tone. Latch Time: Set the duration for the external alarm when the Available number is 0. ...

  • Page 244: Advertise Mode

    NVR User Manual Click button to add a map image from your USB drive.  Click button to adjust the positions of the IP cameras. Click and drag the channel icons  to reposition them on the map. click button to display the map in full screen, click button to exit full screen.
  • Page 245 NVR User Manual Click the Configuration button in the Navigation bar to go to the configuration page. Tick the checkbox of "Advertise Mode" to enable it. Click the "Image" button to load advising pictures from your USB flash drive. You can add up to 16 images in JPG, PNG or BMP format with a maximum resolution of 2560x1600.

  • Page 246: Search Counting Data

    NVR User Manual 6.1.5 Search Counting Data The search function enables users to conveniently retrieve and view historical counting data for specified time periods, channels/groups, and target types according to their needs. The data can be presented in multiple formats, facilitating analysis and decision-making. Click the "Search"...

  • Page 247: Face Attendance

    NVR User Manual 6.2 Face Attendance Face Attendance is an AI application based on face detection functionality. It allows you to visually ⑥ view and check real-time statistical data for attendance management. ① ② ④ ⑤ ③ Display the customized title of the face attendance view. Overall attendance statistics for all selected groups.
  • Page 248 NVR User Manual Channels: Click to choose the face attendance channel(s) Group: Click to choose the face attendance group(s). To edit the group database, click the 5.4.2.2 Face Recognition Database Management icon. See section for more information. GUI Theme: Customize the title for the face attendance view. On Duty Time: Set the start time for the on-duty period.

  • Page 249: Object Classification

    NVR User Manual 6.3 Object Classification The Object Classification leverages AI capabilities like face detection, human detection, and vehicle detection to intelligently classify and count the number of detected faces, human beings, motor vehicles, and non-motor vehicles over a certain period, being an important feature in intelligent video analytics systems typically applied in scenarios with concentrated people and vehicle traffic requiring security monitoring, such as commercial complexes, transportation hubs, tourist ①...

  • Page 250: Chapter 7 Search, Playback & Backup

    NVR User Manual Click the search icon to search recordings of human & vehicle detection events. 10. Click the setting icon to configure the object classification settings: GUI Theme: Customize the title for the object classification view. Statistics: Select the time period for which to show the data. Channels: Click to choose the channel(s) for which to show the data Chapter 7 Search, Playback &...
  • Page 251 NVR User Manual Search Options: The system provides various search & playback methods: General, Events, Sub- periods, Smart, Tag, External File, Picture, Slice & AI. Click the respective tab to search for different types of event recordings. Search Date: Click the calendar icon to select the date to search for. A red underline on a date indicates recorded footage is available on those dates.

  • Page 252: Video Clip Backup

    NVR User Manual Tag to record info about a person/object in the video. Select camera, pause on the subject, click this button. Tagging enables you to create a searchable, descriptive index of important events or points of interest within extensive video recordings. Same as above but allows naming the tag Switch between original aspect ratio or stretch for all cameras Timeline:...
  • Page 253 NVR User Manual file you want to save. When you use the dedicated player to play the saved file, you need to enter the password to play it. After setting is complete, click “Save” to save the file to the USB drive.

  • Page 254: Search, Play And Back Up Event Recordings

    NVR User Manual 7.2 Search, Play and Back Up Event Recordings The primary function of the Event Search feature is to locate and retrieve recordings generated by alarm events or normal recordings that occurred within a specified time period. By defining the alarm event, time, and channel, you can quickly search for and review the alarm events you need to see.

  • Page 255: Event Playback Control

    NVR User Manual 10. Click on an event thumbnail to display additional information on the left. 11. Tick the checkbox above each thumbnail to select it. You can tick the "Select current page" checkbox to select all events on the current page, or tick the "Select all page" checkbox to select all events on all pages.
  • Page 256 NVR User Manual Button Function Return to the Event search page Enlarge the video playback to full screen Rewind, subsequent clicks change the rewind speed Slow play, subsequent clicks change the playback speed Play at normal speed Pause Play frame-by-frame, click once to advance a single frame Stop playback Fast forward, subsequent clicks change the speed Digital zoom - click this then use mouse scroll wheel to zoom in/out.

  • Page 257: Sub Periods Playback

    NVR User Manual 7.3 Sub-periods Playback The Sub-periods Playback function allows you to simultaneously play multiple video segments from different time periods on a single channel. The recordings from the selected time range are evenly divided and displayed across split-screen panes according to the selected split-screen mode. For example, if you have a 1-hour video recording and select a 4-pane split-screen mode, the video will be divided into 4 segments of 15 minutes each.
  • Page 258 NVR User Manual Button Function Enlarge the video playback to full screen Rewind, subsequent clicks change the rewind speed Slow play, subsequent clicks change the playback speed Play at normal speed Pause Play frame-by-frame, click once to advance a single frame Stop playback Fast forward, subsequent clicks change the speed Digital zoom - click this then use mouse scroll wheel to zoom in/out.

  • Page 259: Smart Search & Playback

    NVR User Manual 7.4 Smart Search & Playback With the Smart Search function, you will be able to quickly search for and play back motion event recordings from a supported camera, regardless of whether motion detection is enabled or not on that particular camera.
  • Page 260 NVR User Manual Play frame-by-frame, click once to advance a single frame Stop playback Fast forward, subsequent clicks change the speed Digital zoom - click this then use mouse scroll wheel to zoom in/out. Use the picture-in-picture to select viewing area. Right-click to exit. 7.1.1 Video Edit video by setting start/end mark points to copy to USB drive.

  • Page 261: Tag Search & Playback

    NVR User Manual Select a full-screen detection area. Delete all areas created. Search and play video based on the areas defined. Return to the playback interface. To define one or more specific areas, please do the following: Click button to delete all area, and then drag to select the area that you want to define. Multiple areas can be defined.
  • Page 262 NVR User Manual ① ② ③ ⑥ ④ ⑤ ⑦ Click the tab. Select the start day & time and end day & time you want to search for. If you have created one or more customized tags, click this to input the tag name (tag names are case sensitive).

  • Page 263: Play External File

    NVR User Manual 7.6 Play External File The NVR supports playing back videos that you have copied to a USB flash drive. ① ② ③ ④ ⑤ ⑥ Click the “External File” tab. If multiple USB flash drives are connected, click the drop-down menu to select the drive you want to access.

  • Page 264: Search

    NVR User Manual 7.7 Search & View Snapshots The Search & View Snapshots function allows you to search through, view, and export captured snapshot images from the NVR to a USB flash drive. ① ② ③ ⑥ ⑥ ④ ⑤ ⑧...

  • Page 265: Playing Slideshow

    NVR User Manual Click on a thumbnail to display relative information about that snapshot in the bottom-left corner. 10. Check the box above each event thumbnail to select it, or check the "Select" box to select all events on the current page. 11.

  • Page 266: Slice Search

    NVR User Manual Select one or more snapshots, then click this button to copy them to a USB flash drive. Click this to display detailed information about the selected snapshot. Click this button to go back to the previous screen. 7.8 Slice Search This function is able to slice recordings into one-minute segments, which helps to quickly locate and review specific moments of interest.

  • Page 267: Ai Search

    NVR User Manual activities captured by various cameras during the selected hour, facilitating a comprehensive analysis across different monitored areas. 4. Choose the specific channel you want to search. Only one channel can be searched at a time. 5. Select the time you want to search in the order of first specifying the year, then month, date, and lastly the hour.
  • Page 268 NVR User Manual 7.9.1.1 Search for Captured Images of Human Faces Select the start date, time and end date, time you want to search for. Select the channels you need to search, by default all channels are selected, or you can select specific channel(s) to search.
  • Page 269 NVR User Manual for playing the video, with the following options: 5s, 10s, 20s, 30s, 1min, 2min, 5min, 10min and Custom Playback. In Custom Playback, you can set how long to extend the playback time before and after the capture. 10.
  • Page 270 NVR User Manual 7.9.1.2 Match Search for Facial Images In addition to searching for all captured facial images over the entire time period, you can also perform precise matching searches. Select the start date, time and end date, time you want to search for. Select the channels you need to search, by default all channels are selected, or you can select specific channel(s) to search.
  • Page 271 NVR User Manual In the “Similarity” setting, set the percentage threshold for how closely a detected face must match the target faces. The default is 70%. A higher similarity percentage will result in fewer matching results. Click “Search” to start the matching search. The results will be displayed in the window on the right.
  • Page 272 NVR User Manual Click and drag a camera site icon with the left mouse button to move it to the intended position on the map Uncheck the checkbox to save your positioning settings. Click the add button , and then select a face image from an internal or external storage device.

  • Page 273: Search License Plate

    NVR User Manual 10. Click to choose "Time↑" to sort the events from oldest to newest. 11. Click the play button to start an animated demonstration of the person's movement path. Use the following buttons to control playback: Click to display previous movement Stop Play Pause...
  • Page 274 NVR User Manual Click the calendar icon to select a date to search. A red underline on a date indicates license plates were captured on those particular dates. To specify the time range, use the keypad to enter a specific start and end time. The system searches all channels by default.
  • Page 275 NVR User Manual You can also define the length of the video clips to save by setting the Pre-event Time and Post- event Time. These settings determine how much recording time is included before and after the detected event itself. 10.

  • Page 276: Search For Perimeter Intrusion & Line Crossing Events

    NVR User Manual 7.9.3 Search for Perimeter Intrusion & Line Crossing Events You can search for perimeter intrusion detection and line crossing detection events that have been captured by enabled cameras. ③ ⑦ ① ④ ② ⑤ ⑥ Click on any one of the thumbnails, its information will be displayed and its recording will be played.
  • Page 277 NVR User Manual In Custom Playback, you can set how long to extend the playback time before and after the capture. You can click the save button to make a backup. You can choose to save picture files and/or video files. When selecting video files, you can pick the file format for saving. If you choose the RF format, you have the option to encrypt the saved files.

  • Page 278: Intrusion (Enter Region & Exit Region)

    NVR User Manual 7.9.4 Intrusion (Enter Region & Exit Region) You can search for view, backup captured images and recordings triggered by Intrusion Detection events (including entering a region and exiting a region). ⑥ ① ③ ④ ② Click on any one of the ⑤...
  • Page 279 NVR User Manual In Custom Playback, you can set how long to extend the playback time before and after the capture. You can click the save button to make a backup. You can choose to save picture files and/or video files. When selecting video files, you can pick the file format for saving. If you choose the RF format, you have the option to encrypt the saved files.

  • Page 280: Repeat Visitors

    NVR User Manual 7.9.5 Repeat Visitors This is a function to fast search the frequency of occurrence of persons in a certain time period, allowing you to quickly identify and track individuals who have appeared multiple times within the specified date and time range. ⑫...
  • Page 281 NVR User Manual In Custom Playback, you can set how long to extend the playback time before and after the capture. You can click the save button to make a backup. You can choose to save picture files and/or video files. When selecting video files, you can pick the file format for saving. If you choose the RF format, you have the option to encrypt the saved files.

  • Page 282: Face Attendance

    NVR User Manual 7.9.6 Face Attendance The Face Attendance function utilizes facial recognition technology to assist with attendance management. It can automatically record employees' clock-in and clock-out times and analyze cases of tardiness, early departures, and absenteeism By selecting specific camera channels, employee groups or individuals, and setting parameters like date ranges and scheduled work hours, the system will search for and log the facial images and video recordings of those employees captured by the cameras during that time period.
  • Page 283 NVR User Manual in the system. Searching by group allows you to quickly retrieve attendance data for an entire department or team. If searching By Person, only the specific individual(s) you manually select will be included in  the search. This person-based approach provides more flexibility to review the attendance records of designated employees as needed.

  • Page 284: Chapter 8 Remote Access Through The Web Client

    NVR User Manual Chapter 8 Remote Access Through the Web Client You can use the web client on a PC to access the device remotely at any time. Before using the web client, you need to ensure that the device network is functioning properly. 8.1 Basic System Environment Requirements The minimum and recommended requirements for the hardware and operating system to run the web client smoothly are as follows:...

  • Page 285: Web Plug In Downloading And Installation

    NVR User Manual 8.2 Web Plug-in Downloading and Installation When you use Internet Explorer to access the NVR for the first time, you need to download the Web Client plugin. Please refer to the following steps: Open Internet Explorer and enter the IP address or "DDNS + port number" of the NVR device in the address bar.
  • Page 286 NVR User Manual Once the plugin download is complete, run the installer and follow the on-screen instructions to install the plugin on your computer. After successful installation, return to the web browser and refresh the page. You may see a pop-up dialog box at the bottom of the page asking for permission to run the plugin.

  • Page 287: Web Client Management

    NVR User Manual 8.3 Web Client Management This section will mainly introduce the Web Client interface and basic operation methods. For the usage of specific function menus, please refer to the usage methods of the corresponding functions on the local NVR client. 8.3.1 Login Interface Introduction Open a web browser and enter the IP address or "DDNS + port number"...

  • Page 288: Main Interface Introduction

    NVR User Manual 8.3.2 Main Interface Introduction After successfully logging in, you will arrive at the main page of the Web Client. Live: Click to enter the live preview interface  Playback: Click to enter the live preview interface  Remote Setting: Click to enter the live preview interface ...

  • Page 289: Live Preview Interface

    NVR User Manual 8.3.3 Live Preview Interface On the Live Preview page, you can open or close live preview, manually record video to your local computer, take snapshots of the screen, control PTZ cameras, and adjust color settings, etc. 1. Channel List Controls Icons Description Click this icon to hide the channel list...
  • Page 290 NVR User Manual 2. Stream Switching When viewing a channel in full-screen mode on the Web Client, it automatically switches to the main stream mode. When viewing multiple channels in split-screen mode, it automatically switches to either sub-stream or mobile stream mode. Users can select the appropriate stream mode for viewing based on their actual network environment and computer configuration.

  • Page 291: Function Control Buttons

    NVR User Manual 4. Preview Channel Switch Button Click the arrows to switch to the previous or next group of preview channels without changing the current preview channel layout. 4. Preview Channel Switch Button Function Control button Manual Alarm：Turn the IO alarm on or off manually Color setting：Click to display or hide the color control。...
  • Page 292 NVR User Manual 2. Stream Switching When viewing a channel in full-screen mode on the Web Client, it automatically switches to the main stream mode. When viewing multiple channels in split-screen mode, it automatically switches to either sub-stream or mobile stream mode. Users can select the appropriate stream mode for viewing based on their actual network environment and computer configuration.
  • Page 293 NVR User Manual PTZ: Enable or disable the PTZ operation menu. Arrow keys: Click the arrow keys to rotate the PTZ camera. Default cruise. PTZ speed: Set the rotation speed of the PTZ camera. Zoom: Click -/+ to zoom in or out the image. Iris: Adjust the iris size.
  • Page 294 NVR User Manual Line Scan page: Click to record the start position and rotate Area scan: the PTZ camera, and click to record the stop position. Speed: Select the linear cruise speed. Click to start linear cruise. In this mode, the PTZ camera moves on the same horizontal plane only.
  • Page 295 NVR User Manual Pattern Scan page: Record: Click to start recording the cruise route. Click to stop recording. Cruise: Click to start cruise in accordance with the recorded route and action. 6. Live View Control Buttons Switch display mode in the channel area. Open all channel previews.
  • Page 296 NVR User Manual White light control. White light deterrence can be enabled manually (camera support is required). Alarm bell control. Alarm bell can be enabled manually (camera support is required). Warning light control. Warning light alarm can be enabled manually (camera support is required).

  • Page 297: Playback Interface

    NVR User Manual 7. The searched videos are displayed on the timeline. Click the video clip to be played, and click to play the video. 8.3.4 Playback Interface In the dropdown box in the upper left corner, select the search method you want to use: General, Picture, Tag, or AI.

  • Page 298: Local Setting Interface

    NVR User Manual On this page, you can configure the relevant parameters of the NVR. In the sidebar on the left, click on the parameter you need to set to enter the corresponding page. For specific details, please refer Chapter 5 System Setup to the relevant sections in It should be especially noted that if you have checked the "Direct Camera Web...

  • Page 299: Chapter 9 Backup Video Playing

    NVR User Manual Chapter 9 Backup Video Playing This chapter describes how to use the VideoPlayer to play the video files backed up from the device. Minimum Requirements for the Computer System CPU: Intel I3 or above  Operating system: Windows XP/7/8/10/11, MacOS 10 ...
  • Page 300 NVR User Manual Video Player Control 1. Play list Add files. Delete files. Select play mode: Play a single file and then stop; play all listed files in sequence; play one file repeatedly; play all files repeatedly. Filter files by file name. Hide/Show the play list.
  • Page 301 NVR User Manual Fast forward: You can set the video to be played at 2×, 4×, 8×, or 16× of the normal play speed. Volume control. Multi-screen play. Multiple videos can be played at a time. After clicking this icon, you can drag the videos in the play list to the play page.

  • Page 302: Chapter 10 Remote Access Through Mobile Devices

    NVR User Manual Chapter 10 Remote Access Through Mobile Devices The device supports remote access through the mobile devices with Android or iOS operating systems. For such mobile devices with Android or iOS, they can obtain the RXCamView software from Google Store or Apple Store and then install the software. 1) Run the program to display the live view screen.
  • Page 303 NVR User Manual 2) Click the icon to open the menu, choose Device List, and then click + to add a device. 3) Click Manual Add, and enter the device information to add a new device.
  • Page 304 NVR User Manual Scan the QR code: Scan the QR code to add a device. Online search: Search and add a device in the same LAN as the device. Manual Add: IP Address/ID: Enter an IP address or a P2P ID. Port: Enter the port number of the device.

  • Page 305: Chapter 11 Appendix

    NVR User Manual Chapter 11 Appendix 11.1 FAQ 1. Q: What should I do if I cannot detect the hard disk? A: If no hard disk is detected, you need to verify the following: (1) The data cable and power cable of the hard disk are well connected. (2) The ports of the hard disk on the main board are in good condition.
  • Page 306 NVR User Manual 6. Q: Can I use the hard disk drive on my PC in the device? A: It is recommended that you use a hard disk dedicated for video surveillance to ensure the stability of device operation. 7. Q: Can I play back videos while recording videos? A: Yes.

  • Page 307: Use And Maintenance

    NVR User Manual 13. Q: Why do the alarms fail? A: Verify that the alarm setting, alarm connections, and alarm input signals are correct. 14. Why does the buzzer keep ringing? A: Check the following items: alarm settings, whether the motion detection function is enabled, whether there are always moving objects detected, and whether the I/O alarm is disabled.

  • Page 308: Attached Accessories (Subject To The Actual Product)

    NVR User Manual 6.Try to avoid the impact of other electric appliances on audio and video signals, and prevent the hard disk from being damaged by static electricity or induced voltage. If the interface connecting the network cable is frequently plugged in and pulled out, it is recommended that you replace the connection cable regularly to avoid unstable input signals.
