FOXFURY NOMAD TRANSFORMER 85-600 Manual

NOMAD
1
2
3 4
TRANSFORMER
®
OPTION 1: FULL Y DEPLOYING THE NOMAD
NOMAD TRANSFORMER
®
WITH EXTENSION
(EXPLODED VIEW)
EXTENSION (2.5FT) (P/N 85-600)
®
WITH THE EXTENSION
®
1. Unscrew all five (5) Caps from the four (4) different parts of the Nomad
1
Transformer (Light Head, Tripo-Scope
®
2. Once all Caps are removed, place the Tripo-Scope
2
(male end), line up the I, II, and III marks. Once aligned, tighten the Locking
Ring to secure the Tripo-Scope
Tripo-Scope Legs are now ready to deploy. Unfold each Tripo-Scope
®
and make sure they are locked in place.
3
3. Open the Protective Light Cap to raise the Tripo-Scope
NOT raise the poles all the way , as the Light Head and Extension still needs
to be installed). Install the Extension to the Tripo-Scope
I, II, and III marks then tighten the Locking Ring to secure the Extension to
the Tripo-Scope
®
up the I, II, and III marks then tighten the Locking Ring to secure the Light
Head to the Extension.
Keep the Light Panels as they are for a 360 configuration or, open
the Light Panels for a Directional configuration. Then, based on
preference or need, adjust the Sliding Diffuser Lens to either Area
or Spot lighting.
Adjust the angle and swivel position of the Light Head by loosening
the Tilt Adjustment Knob to the desired orientation and then
re-tighten.
4. 4 Elevate the Light Head to desired height by raising the Tripo-Scope
Tighten the Tripo-Scope
desired height.
IMPORTANT! To reposition, loosen the Tightening Rings, bring the
Tripo-Scope
physically pick up and move the position of the whole Nomad
the Tripo-Scope
damage.
WARNING! The Nomad
®
need to move it once it is deployed, use a Team Lift approach with at least two
people, OR disassemble and then reassemble at new location.
, Power Pack, and Extension).
®
to the Power Pack. The Folding
®
Pole. Place the Light Head on top of the Extension. Line
Tightening Rings (clockwise) to hold the poles at
®
Poles down again, and turn the Light Head OR,
®
Poles against each other can cause permanent
®
Transformer is heavy once fully assembled. If you
® ®
®
onto the Power Pack
®
Leg
®
Poles slightly (do
®
Pole. Line up the
®
Poles.
®
. Turning
®
