  • Page 1 Sterling Power Products THERM : Air Conditioner Range Handbook THERM3300 RoHS compliant www.sterling-power.com www.sterling-power-usa.com Warranty (2 years return to factory)
  • Page 2 STERLING POWER...
  • Page 3: Contents Page

    STERLING POWER INTRODUCTION TABLE OF CONTENTS Introduction Table of Contents Legal / Safety I Legal / Safety II Specifications Dimensions and specifications sheet Skylight/Vent guidance Unpacking and inventory list Installation Preparing for install Install Install Install Installation Remote layout Operations of remote/THERM Faults Faults and troubleshooting There are some requirements that I need to place at the start.
  • Page 4: Safety And Legal

    STERLING POWER SAFETY AND LEGAL LEGAL GUIDELINES Warranty and Terms Your 100 % satisfaction is our goal. We realise that every customer and circumstance is unique. If you have a problem, question, or comment please do not hesitate to contact us. We welcome you to contact us even after the warranty and return time has passed.
  • Page 5: Safety Guidelines

    STERLING POWER SAFETY AND LEGAL SAFETY GUIDELINES Product Guidelines Your Sterling Power product should only be utilised for it’s designated purpose. If you do not feel capable to install an AC item correctly - DO NOT. If there are any doubts about the install - get it professionally installed. Ensure that the mains supply and battery leads are disconnected before transporting or moving the unit.
  • Page 6: Specifications

    STERLING POWER SPECIFICATIONS FOOTPRINT AND SPEC SHEET Dimensions (mm) 1056 Specifications and technical data Rated Cooling Capacity Up to 3300W. 12000BTU Rated Heating Capacity 12500BTU Operating Voltage 220-240VAC 50Hz Compressor current draw 5.5A Locked rotor current Cooling power / Heating power 1300W / 1060W Volume of air moved...
  • Page 7: Direction Of Travel

    STERLING POWER SPECIFICATIONS SKYLIGHT/VENT GUIDANCE Underside dimensions RED: Install area 1056 DIRECTION OF TRAVEL Foam seal dimensions RED: Inside seal dimensions SKYLIGHT...
  • Page 8 STERLING POWER FIRST OPENING ITEM INVENTORY The THERM3300 unboxing The THERM3300 comes in two boxes. If you have only received one, reach out to your distributor or salesperson. Box one holds the upper body of the THERM3300 (and that’s it-) Box two holds the accessories and the inside plate.
  • Page 9: Installation Prep

    STERLING POWER INSTALL INSTALLATION PREP Install preface As I’ve mentioned a few times- the THERM3300 is a heavy and bulky unit. Please ensure that you have assistance with getting this item into place. Dropping it and breaking it - or indeed making a new skylight by dropping it through the roof - is not going to be helpful for anyone.
  • Page 10: Installation

    STERLING POWER INSTALL INSTALLATION Treating the vent The opening that the air-con is going to sit on must be adeuqately supported, and where possible, the inter-layer (between the air-con and the interior of the vessel) is insulated. To really optimise the install, we recommend sealing the area around the vent-hole with insulated battons, of about 20mm thickness or more.
  • Page 11 STERLING POWER INSTALL INSTALLATION Installing the fixing plate With the fixing plate prepped for install, install the fixing plate into the 360*360 ceiling opening, fixing the plate into position with the outdoor unit by using the long bolts found in the smaller secondary pack. Tightening the plate into position It’s advisable to tighten the bolts by hand at first, ensuring everything is in position correctly instead of shearing anything - either the bolt or the housing.
  • Page 12 STERLING POWER INSTALL INSTALLATION Feeding the cabling through With the AC power now connected (not LIVE!) you can install the control cables. The plug-in harness from the outdoor unit can be pulled through and plug it into the corresponding terminal plugs in the control box. Any loose wires will have a housing (other than the temperature sensors-) so check the plug ends for where they may go.
  • Page 13: Operation

    STERLING POWER OPERATION UNDERSTANDING THE REMOTE You’re there! You can now look at powering the item up! You might benefit from looking at the following instructions first, so we can ensure you know what’s going on. You may also benefit from adding a physical switch to the AC IN line to the Air-Con so you can turn it on/off...
  • Page 14 STERLING POWER OPERATION USING THE THERM Using the remote There’s a few different operating modes built into the THERM. We have AUTO, COOLING, DRY, FAN, HEATING, TIMER OFF and TIMER ON... Which is certainly a few. They have some common features, for example : POWER The central button is the POWER button.
  • Page 15: Troubleshooting

    STERLING POWER TROUBLESHOOTING TROUBLESHOOTING Troubleshooting Sometimes faults happen, but hopefully we can narrow things down and fix them from afar. Quick-check If anything is playing up, first check the following basics Ensure the remote has batteries in and that the screen is functioning Check the AC fuse and plug running in to the THERM unit.
