Maintenance

1. The device may only be used by qualified personnel, damage caused by improper use or attempted
repair is not covered by the warranty. There are no service parts inside the packaging, repairs may
only be carried out by authorized service center.
2. Do not allow the device to come into contact with oil, grease or any similar liquid.
3. Regular cleaning allows of long term use and maintains proper operation. Use a soft cloth to clean
the device.

Operation

1. Place the device on a flat, hard surface with an angle of no more than 10°.
2. Fill the fog liquid tank with dedicated water-based liquid (not included).
3. Fill the water tank.
4. Connect the plug of the power cable to the device, the other end of the power cable to the mains
power source with the appropriate parameters, turn on the device with the ON/OFF switch, moving it
to the ON (I) position.
5. The device will begin the heating process which usually takes a few minutes (the display will show
"Warm up"). The device is ready for operation when the display shows "Ready". During fog emission
the fog icon is displayed.
6. The device is operated via a 5-button touch panel:
• MENU - selection between options:
o DMX - DMX address;
o Volume - fog emission volume;
o Wind - fan speed at fog emission (0-100);
o Interval - interval time between fog emissions for the timer function;
o Duration - duration of fog emission for the timer function;
o Language - interface language selection: Chinese, English;
o Manual - manual mode;
• UP - increase the value of the option shown on the display;
• DOWN - decrease the value of the option shown on the display;
• RUNOK - manual mode; press the button to enter manual mode (Manual), next press - start fog
emission, another press - end fog emission;
• TIME - when in manual mode, the TIME button allows you to enable/disable the timer function
according to the pre-set Interval and Duration options.
7. When you have finished using the device, turn it off. To turn off the device, turn the switch on the back
of the housing to the OFF (O) position and disconnect the device from the power source, following
the safety rules for use.
8. After use, remember to empty the fog liquid tank and water tank. It is recommended to rinse the fog
liquid tank with clean water to prevent dust accumulation.

DMX structure

Channel
CH1
CH2
DMX mode - 2CH
Function
Fog emission volume - low-high
Fan speed at fog emission - slow-fast
7
LIGHT4ME FOG DEMON 3000
Instrukcja obsługi / User Manual
DMX values
0-255
0-255
