Freetech P6F91iV Quick Reference

P6F91iV/ P6F91iVU6 Quick Reference
The User's Manual is located at Compact Disc's \manual\English or Chinese
1. Mainboard Layout:
19
12
1
IR
9
1
2
3
JP13
1
21 1
18
JP12
14
2. Jumpers & Connectors:
Front Panel Connector
HDD
LED
1 2
12131415
SPEAKER
JP13 shunt 1-2: Auto Power On feature is ON
JP13 shunt 2-3: Auto Power On feature is OFF (Default)
JP 6 shunt 1-2: PS/2 keyboard/mouse use power supply's +5V.
JP 6 shunt 2-3: PS/2 keyboard/mouse use power supply's +5Vsb
(+5 volt standby). This is the default setting.
3. DIMM Memory Configuration
EDO/SDRAM
BANK 0
8, 16, 32, 64, 128, 256MB
(DIMM1)
EDO/SDRAM
BANK 1
8, 16, 32, 64, 128, 256MB
(DIMM2)
EDO/SDRAM
BANK 2
8, 16, 32, 64, 128, 256MB
(DIMM3)
8MB to Max. 768MB
Total
Note:
1. P6F91iV does not support mixing of SDRAM and EDO memory
2. When use EDO, it could only run 66MHz (FSB). When you need
to run 100MHz, you have to use SDRAM.
CPU Soft-Menu Setting
SPEED
CPU Frequency
233 MHz 66.6MHz
266 MHz 66.6MHz
300 MHz 66.6MHz
333 MHz 66.6MHz
366 MHz 66.6MHz
400 MHz 66.6MHz
433 MHz 66.6MHz
466 MHz 66.6MHz
Important Note: P6F91iV only supports ATA33.
P6F91iVU6 supports ATA33/66. When use ATA66 Hard driver, it must use the 80-pin cable.
13
20
1
JP1
22
CPU Slot 1
4
17
DIMM1
DIMM2
DIMM3
7
1
1
15
6
1
STB
LED RESET PW_SW
4 5 7 8 10 11
181920 2122
PW LED & KEYLOCK
CPU Ratio
x3.5
x4.0
x4.5
x5.0
x5.5
x6.0
x6.5
x7.0
1: CPU Slot 1
2: ISA ExpansionSlots
3: PCI Expansion Slots
4: AGP Slot
5: DIMM Module Sockets
16 11
8
6: IDE Connectors
1
7: Floppy Drive Connector
JP6
8: Parallel Port Connector (T)
10
9: IR Port Header
1
10: ATX Power Connector
11: PS/2 Mouse Connector (T)
12: Flash BIOS
13: Switching Regulator
14: Front Panel Connectors
15: Battery (CR2032 Lithium)
16: Dual USB Connector
BANK 0
17: CPU FAN Connector
5 BANK 1
18: Secondary FAN Connector
BANK 2
19: System Monitor W83781D
20: Wake on LAN Header
21: Auto Power ON (JP13)
22: Creative Lab SB-Link (JP15)
PS/2 Mouse (TOP)
USB1
PS/2 Keyboard
USB2
Connector:
WOL: Wake On LAN Connector
CD1: CDROM Audio Signal Input (JST Type)
CD2: CDROM Audio Signal Input (MPC2 Type)
MD1: MODEM Voice Signal Input (MPC2 Type)
MD2: MODEM Voice Signal Input (JST Type)
4. CPU Soft-Menu Settings
A. Press <DEL> key to access the AWARD BIOS SETUP Program
B. At the top right hand side of the "Chipset Feature Setup" screen,
there is a "CPU Speed" option. Refer to the table left and select
the correct CPU speed.
C. After set the "CPU Speed", go to "CMOS SETUP UTILITY"
screen and select "SAVE & EXIT SETUP" to save the setting
information in the CMOS memory and continue with the booting
process.
ROM PCI/ISA BIOS (2A6LGF2B)
CHIPSET FEATURES SETUP
AWARD SOFTWARE, INC.
Auto Configuration : Enabled
EDO DRAM Speed Selection : 60 ns
EDO CASx# MA Wait State : 2
EDO RASx# Wait State : 2
SDRAM CAS Latency Time : 2
500 MHz 66.6MHz
533 MHz 66.6MHz
350 MHz 100 MHz
400 MHz 100 MHz
450 MHz 100 MHz
500 MHz 100 MHz
Serial Port Connectors (B)
PS/2 Keyboard Connector (B)
Back Panel Connector
Parallel Port (TOP)
COM1 COM2
CPU Speed : 333Mhz(66.6x5)
AGP Aperture Size (MB) : 64
Auto Detect DIMM/PCI Clk : Enabled
Spread Spectrum Modulated : Enabled
x7.5
x8.0
x3.5
x4.0
x4.5
x5.0
PCB
E
