Badlands Series

2 Burner Gas Griddle

Important: Keep this Owner's Manual for

convenient reference and for part

replacement.

Read this Owner's manual carefully and be

sure your gas grill is properly assembled,

installed and maintained. Failure to follow

these instructions could result in serious

injury and/or property damage.

Please make sure the cylinder valve

connection device shall properly and

safely connected with the connection

device attached to the inlet of the

pressure regulator.

OWNER'S MANUAL

For Outdoor Use Only

Captivate Brands USA, Inc.

25541 Arctic Ocean Drive,

Lake Forest, CA.92630

If you have any questions or problems,

you can contact our customer service at

1-855-200-8445 ext 102 or

help@supportandspare.com

from 9:00 AM - 5:00 PM Monday to Friday.

(Pacific). All emails and voice-mail calls

will be answered within 24 hours.

Model: BMBLS-2B

Item:

BG2458A2

Table of Contents

Need help?

Do you have a question about the Badlands Series and is the answer not in the manual?

Questions and answers

Summary of Contents for BRAND-MAN Badlands Series

Page 1 OWNER’S MANUAL Badlands Series 2 Burner Gas Griddle Model: BMBLS-2B Item: BG2458A2 Important: Keep this Owner’s Manual for For Outdoor Use Only convenient reference and for part replacement. Captivate Brands USA, Inc. 25541 Arctic Ocean Drive, Read this Owner’s manual carefully and be Lake Forest, CA.92630...
Page 2: Safety Precautions
SAFETY PRECAUTIONS READ ALL INSTRUCTIONS BEFORE INSTALLING AND USING THE APPLIANCE SAVE THESE INSTRUCTIONS WARNING DANGER Do not store or use gasoline or If you smell gas: other flammable liquids or Shut off gas to the appliance. vapors in the vicinity of this or Extinguish any open flame.
Page 3 Safety Precautions WARNING • Cylinders must be stored outdoors out of the reach of children and must not be stored in a building, garage or any other enclosed area. • The use of alcohol, prescription or non-prescription drugs may impair an individual’s ability to properly assemble or safety operate this appliance.
Page 4: Burner Flame Check
Safety Precautions WARNING Do not use this appliance under overhead combustible surface or covered area (e.g., awnings, umbrellas, porches or gazebos). Always confirm that this barbecue is not positioned under the overhang of a house, a garage or other structure before lighting it. An overhang will serve to deflect flare-ups and radiated heat into the structure itself, which could result in a fire.
Page 5: Table Of Contents
TABLE OF CONTENTS Safety Precautions ----------------------------------2-4 Burner Flame Check----------------------------------- 4 Model Description------------------------------------- 6 Tools Required for Assembly------------------------ 6 Parts Diagram------------------------------------------- 7 Parts List-------------------------------------------------- 7 Hardware ------------------------------------------------ 7 Assembly Steps -------------------------------------8-11 Connecting LP Gas cylinder to LP Grill --------- 12 Operating Instructions ------------------------- 12-14 Cleaning and Care ------------------------------- 15-16 Warranty ------------------------------------------------ 17 Customer Service------------------------------------- 17...
Page 6: Model Description
2 Burners Grill Description 2 burners gas griddle barbecue designed with: 2 independently controlled stainless steel burners; The rated power of each main burner is 9,000 BTU with a total of 18,000BTU; Push and turn ignition system for firing up; Tools Required for Assembly Philips Head Screwdriver (not included)
Page 7: Parts Diagram
Parts Diagram Parts List Part # Description Part # Description Warming Rack Foot 4pcs Griddle Knob 2pcs Hood Handle Regulator Firebox Assembly Heat Separator 2pcs Grease Cup Hardware List Part# Picture Specification Bolts (M6X20) Flat Washer (Ø6.2) Spring Washer (Ø6.2)
Page 8: Assembly Steps
Assembly Steps • Screw on the four Foot (6) onto each base corner of the Firebox Step 1 Assembly (4) as shown. • Attach two Knobs (7) at the front of the Firebox Assembly as shown. Step 2...
Page 9 Assembly Steps • Install the Hood Handle (3) onto the hood with two Heat Separators (9), Step 3 four screws (A), four ﬂat washers (B) and four lock nut (C). • Open the hood and put on the Griddle (2) into the ﬁrebox as shown. Step 4...
Page 10 Assembly Steps • Put on the Warming rack onto the back of the griddle as shown below. Step 5 • Hook on the Grease Cup (5) as the side of the ﬁrebox. Step 6...
Page 11 Assembly Steps • Attach the regulator (8) onto the connection as the side of the ﬁrebox by Step 7 turning it in clockwise direction.
Page 12: Connecting To A Gas Supply
CONNECTING TO A GAS SUPPLY GAS CYLINDER REQUIREMENTS The griddle is set and tested with liquid propane gas only. When purchasing a gas cylinder for use with this unit, ensure it meets the following requirements: 0.45 kg (1 lb) / 19.6 cm (7.75 in) capacity, marked “PROPANE", constructed and marked in accordance with Specifications for LP Gas Cylinders of the U.S.
Page 13: Checking For Leaks
OPERATING INSTRUCTIONS (CONTINUE) CHECKING FOR LEAKS 1. Make two to three oz. of leak solution by mixing one part liquid dish washing soap with three parts water. 2. Make sure control knobs are in the “O” position. 3. Spray some solution on the tank valve up to the regulator connection. 4.
Page 14: Manual Lighting Procedure
OPERATING INSTRUCTIONS (CONTINUE) MANUAL LIGHTING PROCEDURE 1. Verify that the control knob is turned to the “O” position. 2. Connect LP gas cylinder as per instructions. Turn LP gas tank valve to OPEN. 3. Note the indicator marker on the control knob. Push in the regulator knob and turn 90 degrees (or 1/4) counter-clockwise to “...
Page 15: Cleaning And Care
CLEANING AND CARE CAUTION: 1. All cleaning and maintenance should be done when Barbecue is cool and with the fuel supply disconnected. 2. DO NOT clean any barbecue part in self-cleaning oven. The extreme heat will damage the finish. 3. DO NOT enlarge valve orifices or burner ports when cleaning the valves or burners. Notices 1.
Page 16: Cleaning Frequency
CLEANING AND CARE CLEANING FREQUENCY Follow these cleaning and maintenance tips to service your griddle: 1. BURNER COMPONENTS • Clean the burner whenever heavy build-up is found, to ensure that there are no signs of blockage (debris, insects) on the burner tube or in the burner portholes. After periods of storage, spiders or small insects can build nests, webs, and lay eggs in the burner tube, obstructing the flow of gas to the burner.
Page 17: Warranty
Warranty Two-Year Limited Warranty This warranty is non-transferable and does not cover failures due to misuse of improper installation or maintenance. This warranty is for replacement of defective parts only. We are not responsible for incidental or consequential damage. This warranty does not cover corrosion or discoloration after the grill is used, or lack of maintenance, hostile environment, accidents, alterations, abuse or neglect.
Page 18: Troubleshooting
TROUBLESHOOTING WARNING: Always ensure the griddle is completely cooled to avoid injury. Burner Will Not The ignition wire is broken Contact Customer Service for assistance or a replacement part. Light No igniter spark on Adjust the electrode. Contact Customer Service for assistance or a electrode replacement part.
Page 19 Captivate Brands USA, Inc. 25541 Arctic Ocean Drive, Lake Forest, CA.92630 If you have any questions or problems, you can contact our customer service at 1-855-200-8445 ext 102 or help@supportandspare.com from 9:00 AM - 5:00 PM Monday to Friday. (Pacific). All emails and voice-mail calls will be answered within 24 hours.
