SECTION 590-000-911PT
Issue A, July, 1975
PLANTRONICS DS150A
ComSet* DATA TERMINAL
OPERATION/INSTALLATION
1. GENERAL
1.01
This section is a cover sheet for the Plantron-
ics/ComSet Data Terminal DS150A Opera-
tion Manual 09135-00.
1.02
This syst.em uses a "Touch-Tone®" t.ele-
phone with the Plantronics ComSet Data
Terminal attached to input information and receive
a visual response from a remot.e computer via
privat.e line or switched network.
1.03
The Plantronics ComSet DS150A Visual
Data Terminal consists of a cathode ray
tube (CRT) display unit, a modem, and a control
unit. This is a receive only device. Transmission to
the comput.er and connection to the line is via
"Touch-Tone" t.elephone or rotary dial telephone
with an associated "Touch-Tone" pad.
2. USOC CODE/CUSTOMER OPTIONS
ComSet Terminal (USOC DMV ++)
01 300 Baud
02 150 Baud
03 110 Baud
3. ORDERING - SERVICE/RETURNS
3.01
Factory repair service is provided by Plan-
tronics on a repair and return basis.
3.02
All ;purchasing and returns is handled by
West.em Electric (WE).
3.03
Order Wording-
(Qty) Terminal, Data, ComSet, Plantronics, DS-
150A
Maintenance Spares
(Qty) Subassembly, Display ,Plantronics, 09103-01
(Qty) Board, Demodulator, Plantronics, 09110-01
(Qty) Board, Regulator, Plantronics, 09113-01
(Qty) Board, Converter, Data, Plantronics, 09116-
01
(Qty) Panel, Front, Plantronics, 09128-01
(Qty) Cord, Power, Plantronics, 07779-01
(Qty) Buss, Int.erconnect, Plantronics, 09077-01
(Qty) Kit, Fuse, Plantronics, 09172-01
