S5
： 5000W Power Station, 5040Wh Battery Capacity
S5 Brief Introduction：
EU Version,5040Wh, AC 5000W 230V ,PV 2100W,DC 120W+360W,QC3.0*2+5V2A+PD60W*2
This product is a high-end fashion off-grid energy storage power product independently developed by
our company. It is light, portable and stylish in appearance. Automotive grade lithium iron phosphate battery,
safe, reliable, durable; Provide 120V/20V, 15V, 12V, 9V, 5V AC/DC output, suitable for a variety of different
equipment such as aerial UAV, portable ventilators, medical equipment, mobile phones, tablets, laptops,
desktop computers, small printers, all kinds of lamps, small fish tanks, photographic equipment, electric
balancing unicycles and so on, convenient for users to travel at home, outdoor work, Camping picnics, hiking
expeditions, etc.
Model
S5
LCD Screen
Anderson Output
USB-C
USB-A 3.0
DC Power Button
AC Ports
AC Power Button
Building A3, Zhengfeng Industrial Park, Tangwei Avenue, Tangwei Community, Fuhai Town, Baoan District, Shenzhen 518103, China
Tel: +86-755-29107971 ; Fax:+86-755-86104343
Website：www.spowerstation.com
AC Output Power
5000W
, Email:
info@spowerstation.com
Cell Spec.
PACK Method
IFP27175200A
LiFePO4
15S（105Ah/48V）
105Ah/3.2V
Battery Pack
Capacity
5040WH
Main Power Button
IOT Button
Fan Tunnel
Car Cahrging
DC5521
DC Power Button
EV Charging
Advertisement
Table of Contents
Related Manuals for AWILCO S5
Summary of Contents for AWILCO S5
- Page 1 ： 5000W Power Station, 5040Wh Battery Capacity S5 Brief Introduction： EU Version,5040Wh, AC 5000W 230V ,PV 2100W,DC 120W+360W,QC3.0*2+5V2A+PD60W*2 This product is a high-end fashion off-grid energy storage power product independently developed by our company. It is light, portable and stylish in appearance. Automotive grade lithium iron phosphate battery, safe, reliable, durable;...
- Page 2 ： 5000W Power Station, 5040Wh Battery Capacity AC Input Port Anderson Input Circuit Breaker Switch Battery Input Battery Capacity Circle Battery Capacity Percentage Fault Warning Discharge Power Display Charge&Discharge Time Charge Power Display Display DC5521 Port Status AC Port Status USB-A Port Status Car Charging Port Status USB-C Port Status...
-
Page 3: Control Display
： 5000W Power Station, 5040Wh Battery Capacity 1、Control+Display Item Feature Remark Master switch for each Long press for 3 seconds to turn on or off the main power supply. When turning Main Power Button function on, the LED light around the key will light up the breathing lamp Under the condition that the main power switch is on, tap the button to turn on the car charger, DC5521, USB-A, USB-C 12V30A output;... - Page 4 ： 5000W Power Station, 5040Wh Battery Capacity Display Car Charger When the output of the car charger is on, the icon is displayed. When it is off, the Car Charger Status Working Status icon is off Display DC5521 Port When output is enabled for DC5521, the icon is displayed. When output is DC5521 Port Status Working Status disabled, the icon is off...
- Page 5 ： 5000W Power Station, 5040Wh Battery Capacity Input Voltage High voltage protection 150V;Low voltage protection 11V 12-150V Range MPPT Voltage 18-140V Range MPPT Input Current The maximum charge time depends on the intensity of Charging Time Hour the light and the power of the solar panel Maximum Time month Storage when the remaining power is greater than 50%...
- Page 6 ： 5000W Power Station, 5040Wh Battery Capacity If the output terminal, cable or external device is short Short-Circuit circuited, the output outlet stops. When the short circuit Protection is removed, you need to manually press the DC switch to resume output DC5521 two channels and cigarette lighter output in Output Port parallel...
- Page 7 ： 5000W Power Station, 5040Wh Battery Capacity Protection will be shut down. After the over-current is removed, you need to manually press the DC switch to restore output When the output terminal, wire or external device is short Short-Circuit circuited, the output outlet stops output. When the short Protection circuit is removed, the output will resume automatically Output Port...
-
Page 8: System Protection Function
： 5000W Power Station, 5040Wh Battery Capacity short-circuit is removed, manually press the AC switch to resume output. Output Circuit You need to open the output circuit breaker to have output Breaker Output Port AC socket 6 parallel outputs 8、Battery Pack Parameters Parameter Symbol Unit... -
Page 9: Environmental Requirements
： 5000W Power Station, 5040Wh Battery Capacity Low-temperature ℃ Discharge Recovery Overload Protection For details, see Overload Protection for Each Port Short Circuit For details, see Short Circuit Protection for Each Port Protection If the AC and DC are loaded at the same time, the DC Total Power output is preferred. -
Page 10: Safety Specifications
： 5000W Power Station, 5040Wh Battery Capacity Note: Unless otherwise specified, all the above parameters are measured at 25℃ under full load condition; 12、Safety Specifications Certification Safety Standard State Remark UL2743 pending 13、Electromagnetic Compatibility EMI/EMS Item Standard Criterion Conduction CE FCC part 15 Class B Radiation RE... - Page 11 ： 5000W Power Station, 5040Wh Battery Capacity AC input over-voltage and The AC icon blinks. The AC has no The voltage recovers automatically low-voltage input protection The AC input The AC frequency icon blinks. No AC The frequency automatically frequency is input is provided recovers normally abnormal...
-
Page 12: Parts List
： 5000W Power Station, 5040Wh Battery Capacity Percentage of battery capacity +DC The total battery The system automatically restores to icon + Red Warning icon Blinking. voltage is too high normal Each function has no output Percentage of battery capacity +DC The total battery The system automatically restores to icon + Red Warning icon Blinking. - Page 13 ： 5000W Power Station, 5040Wh Battery Capacity Note: If the packaging of the product is damaged, please confirm whether the appearance of the product is complete. No cracks are allowed in the external structure of the product. Transportation: Suitable for vehicle, ship, aircraft transportation, transportation should be covered, sunscreen, civilized loading and ...
