User manual

Water pump range

WARNING! Read and understand all

safety warnings and instructions carefully

before using this machine. Failure to

follow the warnings and instructions may

result in electric shock, fire and/or serious

injury. Save this manual for future

reference.

ATTENTION! Products covered by this

manual will vary in appearance, assembly,

inclusions, description and packaging.

NOTE! This manual covers multiple styles

of product as well as options / accessories

that may not be suitable for the machine

you have purchased.

Table of Contents

Need help?

Do you have a question about the PTLPMP-154095 and is the answer not in the manual?

Questions and answers

Summary of Contents for Edisons PTLPMP-154095

Page 1 User manual Water pump range WARNING! Read and understand all safety warnings and instructions carefully before using this machine. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save this manual for future reference.
Page 2: Table Of Contents
Product Manual –water pumps Index Index ............................1 Safety ............................2 Parts Diagram ..........................6 Before Use ..........................7 Getting Started ........................... 8 Engine Oil .................................. 8 Connecting the Battery (if equipped).......................... 8 Fuel .................................... 9 Petrol Four Stroke Engines ............................9 Diesel 4-Stroke Engines ............................
Page 3: Safety
Product Manual –water pumps Safety adjustments, changing accessories, It is important you read and reduce the risk of injury or damage, do not storing equipment. Such preventive safety understand instruction allow any other persons within a radius of 5 measures reduce the risk of starting the manual before use and keep the metres of your own position.
Page 4 Product Manual –water pumps WARNING! Use only clean, fresh non- Always shut off the engine, allow the engine remains hot for a while after stopping the to cool before performing any maintenance. engine. Exhaust may contain chemicals that ethanol 95+ unleaded or fresh clean Such preventative measures reduce the risk may cause cancer or reproductive harm.
Page 5 Product Manual –water pumps IMPORTANT! – If you are not familiar with the safe operation / handling of this equipment, or are in any way unsure of any object of this products suitability or correct use for your application you should complete training conducted by a person or organisation qualified in safe use and training related to this product. This includes fuel / electrical handling and safety if applicable to this product or your application.
Page 6 Product Manual –water pumps 241014133500...
Page 7: Parts Diagram
Product Manual –water pumps Parts Diagram ATTENTION! Products covered by this manual will vary in appearance, assembly, inclusions, description and packaging. Rear View Top View View from side View from side (Diesel model only) Front View Decompression Lever (Diesel model only) Air Cleaner (see also 11) 12.
Page 8: Before Use
Product Manual –water pumps Carry Handle Fuel tank cap 11. Engine stop button Priming filler inlet (see Discharge outlet 12. Engine Throttle lever also 9) Spark plug 13. Drain outlet Choke lever Priming filler inlet (see 14. Water inlet Pull start handle 15.
Page 9: Getting Started
Product Manual –water pumps Getting Started NOTE! Ensure the pump is no further than 5m away from the water's edge. NOTE! Keep all hoses short and as straight as possible, failure to do so may decrease the pressure pumps performance. NOTE! It is recommended that a filter and one-way valve (not included) is installed at the end of the suction hose or pipe.
Page 10: Fuel
Product Manual –water pumps Fuel WARNING! Do not use fuel substitutes such as ethanol, methanol or biofuel in your engine, using such fuel will cause damage and void any applicable warranty. WARNING! Use only clean, fresh non-ethanol 95+ unleaded or fresh, clean commercially available pump Diesel, or correctly mixed 2-stroke fuel mix.
Page 11: Petrol 2-Stroke Engines
Product Manual –water pumps Petrol 2-Stroke Engines IMPORTANT! Never use IMPORTANT! Use only stale or contaminated fuel. IMPORTANT! clean, fresh non-ethanol 95+ Tighten the fuel filler cap unleaded with 2-Stroke oil IMPORTANT! securely after adding fuel. (25:1)” Avoid getting dirt and water in the fuel tank.
Page 12: Connecting The Water Inlet
Product Manual –water pumps Connecting the water Inlet NOTE! Keep all hoses short and as straight as possible, failure to do so may decrease the pressure pumps performance. NOTE! It is recommended that a filter and one-way valve (not included) is installed at the end of the suction hose or pipe.
Page 13: Priming The Water Pump
Product Manual –water pumps Priming the water pump Caution: Do not run the pump dry, this may result damage to the pump. 1. Unscrew the priming cap by turning anti-clockwise. Using a hose, fill the pump by pouring water into the priming plug hole.
Page 14: Starting A 4-Stroke Petrol Engine
Product Manual –water pumps Starting a 4-Stroke Petrol Engine 1. Turn the “Fuel Valve” (A) to “ON”. 2. Set the Choke (if equipped); move the “choke lever” (B) to the left (“Cold Start” position). 3. Move the throttle lever (C) half way between FAST and SLOW. 4.
Page 15: Starting A Diesel 4-Stroke Engine
Product Manual –water pumps Starting a Diesel 4-Stroke Engine Priming the fuel system 1. Occasionally, when an engine is new or has been run completely out of fuel it may be necessary to “reprime” the fuel system. This is simply removing any air bubbles from the fuel line. 2.
Page 16: Pull Start
Product Manual –water pumps b. Pull Start (if equipped): Push the decompression lever (D) “down” then pull the start grip (B) until the engine starts. Note: Each time you pull start you will need to push the decompression lever down or the pull start will be difficult to use. IF ENGINE WILL NOT START: 1.
Page 17: Adjusting The Throttle
Product Manual –water pumps Adjusting the Throttle The throttle is used to regulate the RPM of the engine, which also controls the water flow out of the discharge outlet. 1. To increase the speed of the engine and water flow, loosen the lockable throttle knob and push down to the START position and re-tighten the lockable throttle knob.
Page 18: Troubleshooting
Product Manual –water pumps Troubleshooting Symptom Possible Cause Corrective Action Unit runs but delivers little Leak in suction hose or pipes Tighten suction hoses and use thread sealer or no water Clogged suction strainer Clear debris from suction strainer Water level below intake Lower suction hose into water Pump not primed Turn engine off &...
Page 19: Maintenance
Product Manual –water pumps Maintenance Changing the Oil NOTE! After the first 20 hours of use engine oil needs to be replaced and then every 100 hours after that. NOTE! The high pressure pump is shipped without oil. Check the oil level before use. NOTE! Always use high quality oils, choosing their viscosity grade according to the operating temperatures.
Page 20: Spark Plug Service (Petrol Engines)
Product Manual –water pumps Spark plug service (petrol engines) WARNING! If the engine has been running, the exhaust will be very hot. Be careful not to touch the exhaust. To ensure proper engine operation, the spark plug must be properly gapped and free of deposits. 1.
Page 21 Product Manual –water pumps 241014133500...
Page 22 Product Manual –water pumps 241014133500...
Page 23 Product Manual –water pumps 241014133500...
Page 24: Specifications
Product Manual –water pumps Specifications PTLPMP-154095 Manufacturer: Protégé Pump Type: Fire Fighting (High Pressure / Lower Volume) Power Output: 7.5HP/4.8kW/3600rpm Engine Type: 4-Stoke Engine capacity (cc): 220 Starting System: Recoil Fuel Type: 95+ Non Ethanol Petrol Fuel Capacity: 3.6L Engine Oil Type: 10W30 / 10W40 / 15W30 / 15W40.
Page 25 Product Manual –water pumps PTLPMP-308095 Manufacturer: Protégé Pump Type: Transfer Pump (Lower Pressure / High volume) Power Output: 7.5HP/4.8kW/3600rpm Engine Type: 4-Stoke Engine capacity (cc): 220 Starting System: Recoil Fuel Type: 95+ Non Ethanol Petrol Fuel Capacity: 3.6L Engine Oil Type: 10W30 / 10W40 / 15W30 / 15W40.
Page 26 Product Manual –water pumps DSLPMP-50HLE Manufacturer: SPITFIRE Pump Type: Fire Fighting (High Pressure / Lower Volume) Power Output: 10hp Engine Type: Commercially Available Pump Non-Bio Diesel Engine capacity (cc): 406 Starting System: Recoil & Electric Key Start Fuel Type: Commercially Available Pump Non-Bio Diesel Fuel Capacity: 12.5L Engine Oil Type: 10W30 / 10W40 / 15W30 / 15W40.
Page 28 Some experts believe the incorrect or prolonged use of almost any product could cause serious injury or death. For information that may reduce your risk of serious injury or death consult thepoints below and additionall y , the information available at www.datastreamserver.com/safety - Consult all documentation, packaging and - The product has been supplied by a general merchandise...
