Summary of Contents for Airvida Pro 90
- Page 1 User Manual AIRVIDA www.airvidachambers.com...
-
Page 2: Safety Notice
Safety Notice To ensure safety, please read the following precautions before using, Warning¦ -If abnormal smell during use, please turn off the power and pull out the plug -Please make sure the socket plug is fully inserted -Please do not disassemble the machine without permission from the supplier -This product must not be exposed to water, fire, or sharp objects -Child use under adult care only -Please do not touch any valves on the chamber when in use... -
Page 3: Specifications
Specifications 1 ,Chamber Capsule Internal Pressure Gauge Window External Pressure Gauge Zippers Automatic Pressure Relief Valves Spare Valve Air Inlet Valve Emergency Pressure Relief Valve Oxygen Inlet Valve Pressure Switch Valve Pressure Deflate Valve Anti-roll Bolsters Model HYPERBARIC CHAMBER Pro90 Specification 230*120*120cm Size... - Page 4 Specifications 2, Operating Unit of All-in-one Machine Timer Oxygen Timer Buzzer Fuse AIRVIDA Water Container Timing Accounter Switch *Please take container out and pour out the water when the container is full of water, then put it back, Power Cable...
-
Page 5: Assembly And Operation
Assembly and Operation 1 ,Working Scheme Oxygen 2, Installation 1 ,Please check the items before beginning installation, Internal/External Pressure Gauge Chamber Anti-roll Bolsters Frame Silencer Activated Carbon Cotton Filter Spare Oxygen Mask Mattress Hexagon Wrench Folding Chair Spare Fuse Air Tube and Oxygen Tube... - Page 6 Assembly and Operation a, Connect the Black Air tube from Air port of ALL-IN-ONE machine to the Air port in Chamber, b, Connect the Blue Oxygen tube from Oxygen port of ALL-IN-ONE machine to the Oxygen port in Chamber, Oxygen c, Install internal¦external pressure gauges, External pressure gauge Internal pressure gauge...
- Page 7 Assembly and Operation Install the metal frame (must be installed inside the chamber - it is recommended to take all frame pieces into the chamber, then install the frame while inflating the chamber for the first time), Hold and tighten the frame rods by the locked tube jointers provided (as shown below), 4, The Silencer is mounted to the Air inlet valve(Black) inside the chamber, The Oxygen Mask/Headset is mounted to the Oxygen inlet valve(Blue) inside the chamber,...
- Page 8 Assembly and Operation 5, Install the mattress and put anti-roll bolsters under the chamber, AIRVIDA 6, Turn on the all-in-one operating unit machine, -Timer¦ Screw the button to set up the time you want to use for a session, (When the timer ends and the pointer returns to the OFF position, the timer buzzer will start to sound as a reminder, please turn the timer pointer to the ON position to turn it off,) -ON/OFF Button¦...
- Page 9 Assembly and Operation 7 ,Get into the chamber, close inside and outside zippers, (be sure to flatten out the silicone seal strip between the zippers) Close the inside and outside zippers 8, Close the manual pressure deflate valve, Open Close Open Close Warning...
- Page 10 Assembly and Operation 1 0 ,In about 8 minutes, the chamber pressure gauge will slowly rise up to 40kPa, At this time the automatic pressure release valve will exhaust air automatically to maintain the pressure, 1 1 ,The recommended session time is 60-90 minutes per session, 12,After the session, turn the Manual Pressure Deflate Valve to deflate the chamber, Open Close...
- Page 11 There is a water container in front of the all-in-one machine uint, – empty the contents, b, Take it off from the holder and empty the container after session finsihed and machine off, *The cooling system lowers the humidity inside of chamber for a more comfortable experience, AIRVIDA...
-
Page 12: Maintenance
2, All-in-one Machine Operating Unit Maintenance and Cleaning a, Take off the filter containers and replace the filters (see below) b, Replace the activated carbon cotton filters every 6-12 months (depending on frequency of use), AIRVIDA Screw the Valve Take out the filter and replace... -
Page 13: Warranty
Precautions When using for the first time, please test the empty chamber first and observe whether the equipment is operating normally, If the equipment is running abnormally, please do not use it, and contact your dealer promptly, When you exit the chamber, wait until the pressure gauge shows 0kPa before you open the inner and outer zippers, Do not force the zipper to open during use or when pressure relief is not complete, In the event of an emergency or if the air deflate valve fails to operate properly, push the emergency relief valve from inside the chamber to relieve pressure, When the pressure is... - Page 14 AIRVIDA Hyperbaric Chamber "Revolutionize Yourself Through Oxygen” TH ANK Y0 U! Website: www.airvidachambers.com Email: contact@airvidachambers.com...
