- Page 1 LED TV 43UM662H* 50UM662H* 55UM662H* 65UM662H* Depending on model / Selon le modèle / Tergantung pada modelnya / მოდელის შესაბამისად / حسب الطراز www.lg.com Head washer...
- Page 2 English • Read Safety and Reference. • For the power supply and power consumption, refer to the label attached to the product. WARNING: To prevent injury, this apparatus must be securely attached to the desk/wall in accordance with the Safety and Reference. Français •...
- Page 4 Satellite IN...
- Page 8 43UM662H0LC 57.1 50UM662H0LC 1121 57.1 12.1 55UM662H0LC 1235 57.5 14.0 65UM662H0LC 1454 57.7 21.5 AC 100-240 V~ 50/60 Hz Power requirement / Alimentation / Persyaratan daya AC 100-240 ვოლტი ~ 50/60 ჰერცი / კვების მოთხოვნა / متطلبات الطاقة تيار متردد 001 - 042 فولت ~ 05/06 هرتز...
- Page 9 OWNER’S MANUAL Safety and Reference LED TV* * Disclaimer LG LED TV applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. *MFL720270022406REV06* www.lg.com Copyright © 2023 LG Electronics Inc. All Rights Reserved.
-
Page 10: Table Of Contents
Table of Contents Warning! Safety Instructions Adjusting the Angle of the TV to suit view Preparing Using Remote Control Separate Purchase Troubleshooting 5 Magic Remote Control Specifications 6 Wall Mounting Bracket 6 Stand 24 HDMI-DTV supported mode 24 HDMI-PC supported Mode Lifting and moving the TV 25 Supported Photo Formats 25 Supported Audio Formats... -
Page 11: Warning! Safety Instructions
Warning! Safety Instructions • Ventilation - Install your TV where there is proper ventilation. Do not install in a confined space such as a bookcase. - Do not install the product on a carpet or cushion. - Do not block or cover the product with cloth or other materials while unit is plugged in. - Page 12 • Use only an authorised attachments / accessories approved by type of air freshener, insecticide, lubricants, wax (car, industrial), LG Electronics. Otherwise, this may result in fire, electric shock, abrasive, thinner, benzene, alcohol etc., which can damage the malfunction, or product damage.
-
Page 13: Preparing
Preparing Separate Purchase Separate purchase items can be changed or modified for quality • If the TV is turned on for the first time after it was shipped from the improvement without any notification. Contact your dealer to buy these factory, initialization of the TV may take a few minutes. -
Page 14: Wall Mounting Bracket
Lifting and moving the TV Wall Mounting Bracket Make sure to use screws and wall mount bracket that meet the VESA standard. Standard dimensions for the wall mount kits are described in Please note the following advice to prevent the TV from being scratched the following table. -
Page 15: Mounting On A Table
Mounting on a Table • When transporting the TV, do not expose the TV to jolts or excessive vibration. • When transporting the TV, keep the TV upright, never turn the TV on its side or tilt towards the left or right. (Depending on model) •... -
Page 16: Attaching The Tv To A Desk
Attaching the TV to a Desk • If a television is not positioned in a sufficiently stable location, it can be potentially hazardous due to falling. Many (Depending on model) injuries, particularly to children, can be avoided by taking simple precautions such as: The TV should be attached to a desk so it cannot be pulled in a forward/ - Using cabinets or stands recommended by the backward direction, potentially causing injury or damaging the product. -
Page 17: Using The Kensington Security System
We recommend the use the TV and a table. of LG’s wall mount bracket. LG’s wall mount bracket is easy to move with cables connected. When you do not use LG’s wall mount bracket, please use a wall mount bracket where the device is adequately secured to the wall with enough space to allow connectivity to external devices. - Page 18 • When installing the wall mounting bracket, it is recommended to cover the stand hole using tape, in order to prevent the influx of dust and insects. (Depending on model) Stand hole (Depending on model) • Do not use a sharp object when you detached the cable cover.
-
Page 19: Connections
Connections Other connections Connect your TV to external devices. For the best picture and audio quality, connect the external device and the TV with the HDMI cable. Connect various external devices to the TV and switch input modes to Some separate cable is not provided. select an external device. -
Page 20: External Devices
External Speakers External Devices Available external devices are: Blu-ray player, HD receivers, DVD players, (Depending on model) VCRs, audio systems, USB storage devices, PC, gaming devices, and other external devices. • The external device connection may differ from the model. •... -
Page 21: Network
Network Method of volume control port (Depending on model) (Depending on model) • Cable Spec. Wired network connection This TV can be connected to a Pro:Centric server via the port. After Each up/down pins making the physical connection, the TV needs to be set up for network are connected to CPU communication. -
Page 22: Using Button
Using Button Adjusting the Angle of the TV to suit view (Depending on model) (Depending on model) You can simply operate the TV functions, using the button. Swivel 20 degrees to the left or right and adjust the angle of the TV to suit your view. -
Page 23: Using Remote Control
Using Remote Control * To use the button, press and hold for more than 1 seconds. ** To use the button, press and hold for more than 3 seconds. The descriptions in this manual are based on the buttons on the remote control. - Page 24 (Depending on model) * To use the button, press and hold for more than 1 seconds. ** To use the button, press and hold for more than 3 seconds. *** To use the button, press and hold for more than 5 seconds. (Without facing the TV) (POWER) Turns the TV on or off.
-
Page 25: Troubleshooting
Troubleshooting • Do not mix new batteries with old batteries. This may cause the batteries to overheat and leak. • Failure to match the correct polarities of the battery may cause the battery to burst or leak, resulting in fire, personal The software version can be updated for improvement in performance. -
Page 26: Abnormal Display
Abnormal display • If the product feels cold to the touch, there may be a small “flicker” when it is turned on. This is normal, there is nothing wrong with product. • This panel is an advanced product that contains millions of pixels. You may see tiny black dots and/or brightly coloured dots (red, blue or green) at a size of 1 ppm on the panel. -
Page 27: Specifications
1) Only DVB-T2 support models. (Despite DVB-T2 Model, DVB-T/T2 does not apply in Philippine.) 2) Only DVB-C/S2 support models. 3) Only NTSC-M support models. After Sales Service (Egypt Only) Shelf Life Time : 3 Years LG is committed to providing all spare parts of this device during the shelf life time. - Page 28 (UM76*) Wireless module (LGSBWAC97) specifications Wireless LAN (IEEE 802.11a/b/g/n/ac) Frequency Range Output Power (Max.) 2,400 to 2,483.5 MHz 19 dBm 5,150 to 5,725 MHz 18 dBm 5,725 to 5,850 MHz 13.5 dBm Bluetooth Frequency Range Output Power (Max.) 2,400 to 2,483.5 MHz 9 dBm As band channels can vary per country, the user cannot change or adjust the operating frequency. This product is configured for the regional frequency table.
- Page 29 (Only Philippines) (UM76*) Wireless module (LGSBWAC97) specifications Wireless LAN (IEEE 802.11a/b/g/n/ac) Frequency Range Output Power (Max.) 2,400 to 2,483.5 MHz 18.5 dBm 5,150 to 5,725 MHz 18 dBm 5,725 to 5,850 MHz 18 dBm Bluetooth Frequency Range Output Power (Max.) 2,400 to 2,483.5 MHz 9 dBm As band channels can vary per country, the user cannot change or adjust the operating frequency. This product is configured for the regional frequency table.
- Page 30 (Only Vietnam) (UM76*) Wireless module (LGSBWAC97) specifications Wireless LAN (IEEE 802.11a/b/g/n/ac) Frequency Range Output Power (Max.) 2,400 to 2,483.5 MHz 17.5 dBm 5,150 to 5,725 MHz 17.5 dBm 5,725 to 5,850 MHz 13.5 dBm Bluetooth Frequency Range Output Power (Max.) 2,400 to 2,483.5 MHz 9 dBm As band channels can vary per country, the user cannot change or adjust the operating frequency. This product is configured for the regional frequency table.
-
Page 31: Operating Temperature
Environment condition Operating Temperature 0 °C to 40 °C Operating Humidity Less than 80 % Storage Temperature -20 °C to 60 °C Storage Humidity Less than 85 % • The energy information provided with the product is indicated in accordance with the regulations of each country. (Depending on Country) - The Energy consumption is measured in accordance with IEC 62087. -
Page 32: Hdmi-Dtv Supported Mode
HDMI-DTV supported mode HDMI-PC supported Mode • PC audio is not supported. Horizontal Vertical Resolution • Use HDMI IN 1 for PC mode. (Depending on model) Frequency (kHz) Frequency (Hz) 31.46 59.94 Horizontal Vertical 640 x 480p Resolution 31.50 60.00 Frequency (kHz) Frequency (Hz) 31.46... -
Page 33: Supported Photo Formats
Supported Photo Formats Supported Audio Formats File File Format Resolution Item Info Format Format Minimum: 64 (W) x 64 (H) Bit rate 32 Kbps - 320 Kbps .jpeg Maximum (Normal Type): 15360 (W) x Sample freq. 16 kHz - 48 kHz .mp3 .jpg JPEG 8640 (H) Support MPEG1, MPEG2 .jpe Maximum (Progressive Type): 4800 (W) Channels... -
Page 34: Supported Video Formats
• ULTRA HD Video: 3840 x 2160, 4096 x 2160 • Some HEVC encoded ULTRA HD videos other than the content Extension Codec officially provided by LG Electronics may not be played. VC-1 Advanced Profile (except for • Some codecs can be supported after a software upgrade. Video WMVA), VC-1 Simple and Main Profiles .asf... -
Page 35: Open Source Software Notice Information
Dolby Laboratories Licensing Corporation. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by LG Electronics Inc. is under license. Other trademarks and trade names... -
Page 36: Ir Codes
IR Codes • This feature is not available for all models. Code (Hexa) Function Code (Hexa) Function (POWER) Number Key 0-9 Alphabet buttons 10-19 (SPACE) (BACK) - Page 37 • This feature is not available for all models. Code (Hexa) Function Code (Hexa) Function (BACK) (POWER) (INPUT) (EXIT) Number Key 0, Number Key 1-9 11-19 (MUTE) (SETTINGS)
-
Page 38: External Control Device Setup
External Control Device ►B Type Setup RS-232C IN (CONTROL & SERVICE) RS-232C Setup (Depending on model) • Image shown may differ from your TV. Connect the RS-232C (serial port) input jack to an external control device (such as a computer or an A/V control system) to control the product’s functions externally. -
Page 39: Rs-232C Configurations
RS-232C Configurations Communication Parameters • Baud rate: 9,600 bps (UART) 7-Wire Configurations • Data length: 8 bits (Standard RS-232C cable) • Parity: None • Stop bit: 1 bit • Communication code: ASCII code • Use a crossed (reverse) cable. Set ID For [Set ID] number, see "Real data mapping". -
Page 40: Command Reference List
Command Reference List Data Command1 Command2 (Hexadecimal) (Depending on model) 24 Fail Over Mode (See p. 39) Data Command1 Command2 25 Fail Over Input (Hexadecimal) (See p. 39) Select 1 Power 00 to 01 26 Internal 2 Aspect Ratio (See p. 33) storage media n, a8 (See p. -
Page 41: Transmission / Receiving Protocol
Transmission / Receiving Protocol 1 Power (Command: k a) ►To control Power On/Off of the set. (Depending on Model) Transmission Transmission (k)(a)( )(Set ID)( )(Data)(Cr) (Command1)(Command2)( )(Set ID)( )(Data)(Cr) Data 00 : Off (Command1) : First command to control the TV. (j, k, m or x) Data 01 : On (Command2) : Second command to control the TV. - Page 42 3 Screen Mute (Command: k d) 6 Contrast (Command: k g) ►To select screen mute on/off. ►To adjust screen contrast. You can also adjust contrast in the picture settings. Transmission Transmission (k)(d)( )(Set ID)( )(Data)(Cr) (k)(g)( )(Set ID)( )(Data)(Cr) Data 00 : Screen mute off (Picture on) / Video mute off Data 01 : Screen mute on (Picture off) Data Min : 00 to Max : 64 Data 10 : Video mute on...
- Page 43 9 Tint (Command: k j) 12 Remote Control Lock Mode (Command: k m) ►To adjust the screen tint. ►To lock the front panel controls on the monitor and remote control. You can also adjust tint in the picture settings. Transmission Transmission (k)(m)( )(Set ID)( )(Data)(Cr) (k)(j)( )(Set ID)( )(Data)(Cr)
- Page 44 15 Energy Saving (Command: j q) 17 Equalizer (Command : j v) ►To reduce the power consumption of the TV. You can also adjust ►To adjust equalizer. Energy Saving in picture settings. Transmission Transmission (j)(v)( )(Set ID)( )(Data)(Cr) (j)(q)( )(Set ID)( )(Data)(Cr) Power Saving Level Function...
- Page 45 18 Tune Command (Command: m a) 19 Programme Skip / Add (Command: m b) ►Select channel to following physical number. ►To set skip status for the current Programme. Transmission Transmission (m)(a)( )(Set ID)( )(Data 00)( )(Data 01)( )(Data 02)(Cr) (m)(b)( )(Set ID)( )(Data)(Cr) Data 00 : High channel data Data 00 : Skip Data 01 : Low channel data...
-
Page 46: Data Structure
22 Input select (Command: x b) (Main Picture Input) 23 Programme block/unblock (Command: m d) ►To select input source for main picture. ►This command may work differently depending on model and signal. Transmission (x)(b)( )(Set ID)( )(Data)(Cr) (For South Korea, North/Latin America except Colombia Model) Data Structure Transmission (m)(d)( )(Set ID)( )(Data 00)( )(Data 01)( )(Data 02)(Data 03)(Data 04) - Page 47 (For all other regions including Colombia, Excluding the above 24 Fail Over Mode (Command: m i) countries) ►Selects the Fail Over mode. Transmission Transmission (m)(d)( )(Set ID)( )(Data 00)( )(Data 01)( )(Data 02)(Data 03)(Data (m)(i)( )(Set ID)( )(Data)(Cr) 04)(Cr) Data 00 : Off (Data 00) : Physical Channel Number Data 01 : Auto (Data 01)(Data 02) : Channel Data...
- Page 48 26 Internal storage media contents play (Command: s n, a8) * Real data mapping ►Plays media stored in the internal memory. 00 : Step 0 ►This command may work differently depending on model and signal. Step 10 (Set ID 10) Transmission Step 15 (Set ID 15) (s)(n)( )(Set ID)( )(a)(8)( )(Data)(Cr)
- Page 52 The model and serial number of the product are located on the back and on one side of the product. Record them below in case you ever need service. Model Serial no.
