Summary of Contents for PHS AURORA
- Page 1 AURORA PLAYERS 2/2/2025 SHELTER Installation, Operation & Maintenance Manual PLAY HARD SPORTS EQUIPMENT 13 Alex Fisher Drive Burleigh Heads, QLD 4220...
-
Page 2: Table Of Contents
P a g e Contents Introduction ..............................2 About the Aurora Series ..........................2 Certificate of Compliance: ................Error! Bookmark not defined. Safety Information for the Installer: ....................... 3 Important Safety Information ........................3 Assembly Precautions ..........................3 Site Specific Precautions: ..........................3 Installation Instructions .......................... -
Page 3: Introduction
P a g e Introduction Thank you for choosing the Aurora Series Players’ Shelter from Play Hard Sports Equipment Australia. Ideal for various sports fields such as soccer, AFL, Rugby, & Hockey these shelters are built with high-quality materials to ensure long-lasting performance. -
Page 4: Safety Information For The Installer
P a g e Safety Information for the Installer: Important Safety Information • Read the Manual: Ensure you read this manual in full before beginning assembly or installation. • Supervision: Children should be supervised around the shelter during and after installation. •... -
Page 5: Installation Instructions
The player shelter is modular in design, so, the quantities of the parts supplied will depend on the number of players being seated and the table and the picture below provide the quantities. Table 1: Aurora Model Parts List Model/... - Page 6 P a g e Figure 1 : Aurora Player Shelter Components 2. Site Preparation and Slab Foundation: • Before commencing any groundwork, please survey the ground/field for underground electrical, water, or sewage lines and check for overhead electrical lines. •...
- Page 7 P a g e Figure 2: Aurora Footing Slab Sizes 13 Alex Fisher Drive, Burleigh Heads, QLD 4220 (Australia) Ph: 1300 851 518 | +61 7 5593 4494 Email: email@playhardsports.com.au | W: www.playhardsports.com.au...
- Page 8 • Then, pour a 150mm deep foundation slab with N12 perimeter edge trimmer bar lap + COG 450mm as required. The total length of the N12 bar depends on the Aurora Model as required. • The concrete must be of a minimum 32 MPA – Slab on Grade Exposed to Weather, with a slump of 80 –...
- Page 9 P a g e 6. Once holes are marked, lift the shelter out of position about 100 mm and drill the 12 mm holes for the M12 holes for the anchor screws. 7. Move the shelter back into position. 8. Use a Rattle gun to drive in the M12 anchor bolts 9.
-
Page 10: Assembly Diagram
P a g e Assembly Diagram Figure 4: Typical Aurora Assembly 13 Alex Fisher Drive, Burleigh Heads, QLD 4220 (Australia) Ph: 1300 851 518 | +61 7 5593 4494 Email: email@playhardsports.com.au | W: www.playhardsports.com.au... -
Page 11: Maintenance
P a g e | 10 Maintenance: All our shelters are designed to require a minimal level of maintenance. However, it is advisable to: • Regular Inspections: Check for any signs of wear or damage. Tighten the bolts and spacer on the screen frame. -
Page 12: Warranty Certificate
P a g e | 11 Warranty Certificate: When you purchase a Play Hard Sports Equipment product you have the peace of mind in knowing that your product is covered by Play Hard Sports Equipment’s 5-year manufacturer’s warranty against faulty workmanship and materials. The warranty covers damage or failure of the product during normal intended use.
