Summary of Contents for Voyager 1400g Series

  • Page 1 Barcode Scanner User settings manual...

  • Page 2: Chapter 1 Introduction

    Chapter 1 Introduction About this manual This user guide provides instructions for installing and programming the scanner, also includes product specifications, dimensions, warranty and customer support information. Note: The options in this user guide depend on the model you purchased. Barcode scanners are factory programmed for the most common terminal and communication settings.
  • Page 3 system on the back of this manual. The default is serial port. Connected with a keyboard wedge The scanner can be connected as a "keyboard wedge" between the keyboard and the PC, and the scanner provides data output similar to keyboard input. The following is an example of a keyboard wedge connection: Turn off the power and disconnect the keyboard cable from the back of the terminal/computer.

  • Page 4: Menu Barcode Security Settings

    Reading skills The scanner has a viewfinder that projects a bright red aiming beam that corresponds to the horizontal field of view of the scanner. The aiming beam should be at the center of the bar code, but it can be positioned in any direction to facilitate reading.

  • Page 5: Set Custom Defaults

    Set custom defaults You can create a set of menu commands as your own custom defaults. To do this, scan the "Set Custom Defaults" barcode below before scanning the menu commands for custom defaults. If the menu command needs to scan the numeric code first and then save the code, the entire sequence will be saved to your custom defaults.

  • Page 6: Chapter 2 Programming Interface

    Chapter 2 Programming Interface RS232 serial port RS232 is scanned when connected to the serial port of a PC or terminal. The following RS232 can add a carriage return (CR) and a line feed (LF) suffix, as well as the baud rate and data format. It also changes the trigger mode to manual.

  • Page 7: Rs232 Baud Rate

    RS232 Baud rate The baud rate sends data from the scanner to the terminal at a specified rate. The host terminal must be set to the same baud rate as the scanner. Default = 115200. (8310030) (8310031) (8310032) 1200 (8310033) 2400 (8310034) 4800...
  • Page 8 (8310037) 38400 (8310038) 57,600 (8310039) *115,200 RS232 Word length: data bits, stop bits and parity check Data Bit: Set the word length to 7 or 8 bits of data per character. If the application only needs ASCII hexadecimal, characters 0 to 7F decimal (text, numbers, and punctuation), select 7 data bits.
  • Page 9 7 data bits, 2 stop characters, even parity bits (8310061) 7 data bits, 2 stop characters, no parity (8310067) 7 data bits, 2 stop characters, odd parity bits (8310065) 8 data bits, 1 stop character, even parity bit (8310062) * 8 data bits, 1 stop character, no parity (8310068) 8 data bits, 1 stop character, odd parity bit...

  • Page 10: Usb Ibm Surepos

    USB IBM SurePos Scan the code below to program the scanner for the IBM SurePos (USB Handheld Scanner) or IBM SurePos (USB Desktop Scanner) interface. Note: After scanning one of the codes, you must restart the cash register. (881001128) USB IBM SurePos USB handheld scanner interface (881001129) USB IBM SurePos...
  • Page 11 USB HID Scan the following code to program the scanner with a USB HID barcode. （881001131） USB HID Bar code scanner USB COM Scan the following code to program the scanner to simulate a regular COM port based on RS232. If you are using a Microsoft® Windows® PC, you will need to download the driver.

  • Page 12: Chapter 3 Input/Output Settings

    Chapter 3 Input/Output Settings Buzzer status at power-on The scanner can be programmed to beep when powered. If you do not want a beep on the power, scan to turn off the barcode. Default = Start Buzzer On - Scanner. (8410130) Start buzzer off –...
  • Page 13 (8990010) *Beep on the BEL character (8990011) Beep on the BEL character Press the scanner button buzzer status To hear a click every time you press the scanner button, scan the barcode below. If you don't want to hear a click, scan the "off" code. (This feature has no effect on serial or automatic triggering.) Default = Trigger Click to close.
  • Page 14 (8410011) *Buzzer - read well open Buzzer volume - read well The buzzer volume code modifies the amount of buzzer sound that the scanner makes when it reads well. Default = high. (8410091) (8410092) Medium (8410093) * High (8410090)
  • Page 15 Buzzer pitch – good reading Buzzer pitch code, modify the tone of the beep sounded by the scanner when reading well, default = medium. (8410061600) Low(1600 Hz) (8410062700) * Medium(2700 Hz) (8410064200) High(4200 Hz) Buzzer pitch - error When there is an erroneous reading, the buzzer pitch encoding modifies the pitch (frequency) of the sound emitted by the scanner.

  • Page 16: Read Delay

    Buzzer duration – good reading The buzzer duration code, which modifies the length of the beep that the scanner makes when it reads well. Default = normal. (8410020) * Normal buzzer (8410021) Short beep LED –Read well The LEDs can be set to on or off in response to good readings. Default = (8410081) *LED –Read well open (8410080)

  • Page 17: Manual Trigger Mode

    (851006500) Short delay (500 ms) (8510061000) Medium delay (1,000 ms) (8510061500) Long delay(1,500 ms) Manual trigger mode In manual trigger mode, the scanner does not scan until the barcode is read or until the button is released. (801030) * Manual trigger – normal Mobile phone reading mode When this mode is selected, the scanner will be optimized to read the barcode from the phone or other LED display.

  • Page 18: Chapter 4 Data Editing

    Chapter 4 Data Editing Prefix/suffix overview When the barcode is scanned, additional information is sent to the host along with the barcode data. This set of barcode data and additional, user-defined data is called a "message string." The selections in this section are used to build user-defined data into a message string.

  • Page 19: Add A Prefix Or Suffix

    Add a prefix or suffix: Step 1. Scan to add a prefix or add a suffix code. (889002) Add prefix Step 2. To apply a prefix or suffix code system, determine the 2-digit hexadecimal value from the code chart. For example, for Code 128, the code ID is "j"...
  • Page 20 Example: Add a suffix to a specific code system Send a CR (carriage return) suffix to U.P.C. only: Step 1. Scan add suffix。 Step 2. Determine the 2-digit hexadecimal value of U.P.C from the code chart. Step 3. Scan 6, 3 from the programming diagram on the back cover of this manual.
  • Page 21 Add a carriage return suffix for all code systems If you want to add a carriage return suffix to all code systems at once, scan the barcode below. This action first clears all current suffixes and then writes a carriage return suffix for all code systems. (890000) Add a carriage return suffix for all code systems Clear one or all prefix suffixes...

  • Page 22: Prefix Selection

    Prefix selection (889002) Add prefix （889004） Clear a prefix （889003） Clear all prefix Suffix selection (888002) Add suffix （888004） Clear a suffix （888003） Clear all suffix...

  • Page 23: Function Code Transmission

    Function code transmission When this selection is enabled and the scan code contains a function code, the scanner sends the function code to the terminal. When the scanner is in keyboard wedge mode, the scan code is converted to a key code before transmission. Default = Enabled.

  • Page 24: Chapter 5 Data Format

    Chapter 5 Data Format Introduction to the Data Format Editor You can use the Data Format Editor to change the output of the scanner. For example, you can use the Data Format Editor to scan for bar code data to insert characters at specific points.
  • Page 25 Increase data format Step 1. Scan input data format code system Step 2. Select primary/alternate format Determine if this is your primary data format or one of the 3 alternate formats. This allows you to save a total of 4 different data formats. To write the main format, use the programming chart scan 0 on the back cover of this manual.
  • Page 26 (800002) Save (800000) Quit Other programming options Clear a data format This will delete a data format of a code system. If you want to clear the main format, scan 0 from the programming chart on the back cover of this manual. If you want to clear the alternate format, scan 1, 2 or 3 depending on the format you want to clear.

  • Page 27: Data Formatter

    Data formatter When the data formatter is closed, the barcode data is read as output to the host, including the prefix and suffix. (8860010) Data formatter closes You may want to ask for data to match the data format you created and saved. The following settings can be applied to your data format: Data formatter is open, no need, keep prefix/suffix The scanned data is modified according to your data format and the prefix...
  • Page 28 Primary/alternative data format You can save up to four data formats and switch between them. Your main data format is saved below 0. Your other three formats are saved under 1, 2 and 3. To set your device to use one of the following formats, scan one of the barcodes below.

  • Page 29: Table Of Contents

    Chapter 6 Code System This programming section contains the following menu options. • All Symbologies • Codabar • Code 39 • Interleaved 2 of 5 • NEC 2 of 5 • Code 93 • Straight 2 of 5 Industrial (three-bar start/stop) •...
  • Page 30 All code system If you want to solve all the code systems allowed by the scanner, scan all code opening codes. On the other hand, if you want to solve only the specific code system, scan all code systems to turn off, and then scan the open code system of the specific code system.

  • Page 31: Codabar

    Codabar Default setting Codabar Enable/Disable * Enable Disable Codabar Start/stop character Start/stop character identifies the front and end of the barcode. You can transmit or not transfer Start/stop character。Default = no transfer. Transmission Do not transmission Codabar Check character...
  • Page 32 Create Codabar check characters with different "modulos". You can program the scanner to read-only Codabar barcodes with Modulo 16 check characters. Default = no check character. No check character indicates bar code data with or without check characters when the scanner reads and sends. When “Check Character”...
  • Page 33 Enable *Disable...

  • Page 34: Code 39 Enable/Disable

    Need Codabar Length of information Scan the barcode below to change the length of the message. For additional information on Disable, please refer to the information length description minimum and maximum length = 2-60. Minimum default = 4, maximum default = 60. Minimum message length Maximum message length Code 39...
  • Page 35 Transmission * Do not transmission...

  • Page 36: Code 39 Check Character

    Code 39 Check character No check character indicates bar code data with or without check characters when the scanner reads and sends. When the "Check Character" is set to "Verify" but "Do Not Send", the unit reads only the Code 39 barcode printed using the check character, but does not send the check character along with the scan data.

  • Page 37: Code 32 Pharmaceutical (Paraf)

    This feature allows the scanner to attach data from multiple Code 39 barcodes before transmitting the data to the host. When the scanner encounters a Code 39 barcode with an additional trigger character, it buffers the Code 39 barcode until it reads the Code 39 barcode without an additional trigger.

  • Page 38: Full Ascii

    FULL ASCII If FULL ASCII Code39 decoding is enabled, some characters in the barcode system will be interpreted as a single character. For example: $V will be decoded as the ASCII character SYN, and /C will be decoded as ASCII character #. Default = Disable. NUL %U DLE $P SP SPACE...

  • Page 39: Code 39 Code Page

    Code 39 code page The Code page defines the mapping of character codes to characters. If the received data does not display the correct characters, it may be because the barcode being scanned was created using a different Code page than the one expected by the host program. If this is the case, scan the barcode below, select the Code page used to create the barcode, scan the values in the internal programming diagram on the back cover of this manual, and save the barcode.

  • Page 40: Default Setting

    Interleaved 2 of 5 Default setting Interleaved 2 of 5 Enable/Disable * Enable Disable Check character No check character indicates that the scanner reads and transmits barcode data with or without a check character. When the check character is set to "Verify" but "Do Not Send", the unit reads only the Interleaved 2 of 5 barcode with the check character printed, but does not transmit the check character with the scanned data.
  • Page 41 Interleaved 2 of 5 Length of information Scan the barcode below to change the Length of information. Minimum and Maximum length is 2-80, Minimum length default=4, Maximum length default=80. Minimum message length Maximum message length...

  • Page 42: Nec 2 Of 5

    NEC 2 of 5 Default setting NEC 2 of 5 Enable/Disable * Enable Disable Check character The unprocessed check character indicates that the scanner reads the barcode with or without the check character to send the data. When the check character is set to be processed but not transmitted, scanner can only read NEC2 which is among 5pcs barcodes with check character, but not transfer the check character with scan data.
  • Page 43 Process check characters and transfer...
  • Page 44 NEC 2 of 5 Length of information Read the following setup code to set the length of the NEC 2 of 5. Minimum and Maximum length is 2-80, Minimum length default=4, Maximum length default=80. Minimum message length Maximum message length...

  • Page 45: Code 93

    Code 93 Default setting Code 93 Enable/Disable *Enable Disable Code 93 Length of information Read the following setup code to set the length of the Code93 barcode. Minimum and Maximum length is 0-80, Minimum length default=0, Maximum length default=80. Minimum message length Maximum message length...

  • Page 46: Straight 2 Of 5 Industrial (Three-Bar Start/Stop)

    Straight 2 of 5 Industrial (three-bar start/stop) Default setting Straight 2 of 5 Industrial Enable/Disable Enable * Disable Straight 2 of 5 Industrial Length of information Read the following setup code to set the length of the Straight 2 of 5 Industrial barcode.

  • Page 47: Straight 2 Of 5 Iata (Two-Bar Start/Stop)

    Straight 2 of 5 IATA (two-bar start/stop) Default setting Straight 2 of 5 IATA Enable/Disable Enable *Disable Straight 2 of 5 IATA Length of information Read the following setup code to set the length of the Straight 2 of 5 IATA barcode.

  • Page 48: Matrix 2 Of 5

    Matrix 2 of 5 Default setting Matrix 2 of 5 Enable/Disable Enable *Disable Matrix 2 of 5 Length of information Read the following setup code to set the length of the Matrix 2 of 5 barcode. Minimum and Maximum length is 1-80, Minimum length default=4, Maximum length default=80 Minimum message length Maximum message length...

  • Page 49: Code 11

    Code 11 Default setting Code 11 Enable/Disable Enable * Disable Code 11 Required check character This setting is for Code 11 barcode to get one or two check characters. Default = two check characters. One check character * One check characters...

  • Page 50: Code 128

    Code 11 Length of information Read the following setup code to set the length of the Code11 barcode. Minimum and Maximum length is 1-80, Minimum length default=4, Maximum length default=80. Minimum message length Maximum message length Code 128 Default setting Code 128 Enable/Disable * Enable Disable...
  • Page 51 ISBT 128 cascading In 1994, the international society for blood transfusion (ISBT) approved a standard for communicating Disable blood information in a uniform manner.The ISBT format requires a paid license. ISBT 128 application specification describes 1) Disable key data elements for marking blood products, 2) due to its highly secure and space-saving design, the current recommendation to use Code 128, 3) Code 128 variants support adjacent Code system connections, and 4) the standard layout of bar codes on...
  • Page 52 GS1-128 Defaut setting GS1-128 Enable/Disable * Enable Disable GS1-128 Length of information Read the following setup code to set the length of the GS1-128 barcode. Minimum and Maximum length is 1-80, Minimum length default=1, Maximum length default=80. Minimum message length Maximum message length...

  • Page 53: Telepen

    Telepen Default setting Telepen Enable/Disable Enable * Disable Telepen Length of information Read the following setup code to set the length of the Telepen barcode. Minimum and Maximum length is 1-60, Minimum length default=1, Maximum length default=60. Minimum message length Maximum message length...

  • Page 54: Upc-A

    UPC-A Default setting * Enable Disable Note: When reading UPC-A Disable, UPC-A barcode do as EAN-13 Transmission. UPC-A check character This option allows you to specify whether the Transmission check character should be at the end of the scan data. Default = Enable. * Enable Disable...

  • Page 55: Upc-A Number System

    UPC-A Number System Digital system digital symbols for UPC type barcodes are typically sent transmisson at the beginning of the scanned data, but the unit can be programmed to prevent Transmission. Default= Enable. * Enable Disable UPC-A Addenda This setting adds two or five additional codes to the end of all scanned UPC-A data.

  • Page 56: Upc-A Addenda Required

    UPC-A Addenda Required When set to have an additional code, the scanner can only decode UPC-A barcodes with additional codes. Then you must turn on the enable of the two or five digit additional code. The default setting is that there is no need to have an additional code. Additional code *No additional code UPC-A Addenda Separator...

  • Page 57: Upc-E0

    UPC-E0 Default setting UPC-E0 Enable/Disable Most U.P.C. barcodes start with a 0 number system.To read this code, use the UPC-E0 Enable option.If you need to read code that uses a 1-number system, use UPC-E1. Default = Enable. * UPC-E0 Enable UPC-E0 Disable UPC-E0 Expand Upc-E Expand extend the UPC-E code to 12-bit UPC-A format.Default =Disable...

  • Page 58: Upc-E0 Addenda Required

    UPC-E0 Addenda Required When set to have an additional code, the scanner can only decode UPC-E barcodes with additional codes. The default setting is that there is no need to have an additional code. Additional code *No additional code * UPC-E0 Addenda Separator When this function is turned on, there will be spaces between the barcode and the additional code.

  • Page 59: Upc-E0 Number System

    UPC-E0 Number System U.P.C digital system, code system usually scan data in the Enable head Transmission, but can be programmed to the unit, so that it will not be transmitted, to prevent the Transmission, please scan Disable close. Default= Enable. * Enable Disable UPC-E0 Addenda...

  • Page 60: Upc-E1

    UPC-E1 Most U.P.C. barcodes start with a 0 number system.To read this code, use the UPC-E1 Enable option. If you need to read code that uses a 1-number system, use UPC-E1. Default = Enable. UPC-E1 Enable * UPC-E1 Disable EAN/JAN-13 Default setting EAN/JAN-13 Enable/Disable *Enable...

  • Page 61: Ean/Jan-13 Addenda Required

    EAN/JAN-13 check character This option allows you to specify whether the Transmission check character should be at the end of the scan data. Default= Enable. * Enable Disable EAN/JAN-13 Addenda This configuration adds two or five additional codes to the end of all scanned EAN/JAN-13 data.

  • Page 62: Ean/Jan-13 Addenda Separator

    EAN/JAN-13 barcode with the additional code. The default setting is that there is no need to have an additional code. additional code *no additional code EAN/JAN-13 Addenda Separator When this function is turned on, there will be spaces between the barcode and the additional code when the data is scanned.

  • Page 63: Ean/Jan-8

    EAN/JAN-8 Default setting EAN/JAN-8 Enable/Disable * Enable Disable EAN/JAN-8 check character This option allows you to specify whether the Transmission check character should be at the end of the scan data.Default = Enable. * Enable Disable EAN/JAN-8 Addenda This configuration adds two or five additional codes to the end of all scanned EAN/JAN-8 data.

  • Page 64: Ean/Jan-8 Addenda Required

    two-digit additional code enable * two-digit additional code Disable five-digit additional code Enable * five-digit additional code Disable EAN/JAN-8 Addenda Required When set to have an additional code, the scanner can only solve the EAN/JAN-8 barcode with the additional code. The default setting is that there is no need to have an additional code.

  • Page 65: Msi Check Character

    Default setting MSIEnable/Disable Enable * Disable MSI check character MSI barcodes use different types of check characters.You can program the scanner to read the MSI barcode using the type 10 check character.Default = verify type 10, but Do not transmission. When the “check character”...
  • Page 66 When the “check character” is set to “Verify Type10, Do not transmission”, the device will only read and use the MSI barcode printed with the specified type of check character, but not send the check character with scan. * Verify Type10, Do not transmission Verify Type10 and Transmission Disable MSI check characters MSI Length of information...

  • Page 67: Gs1 Databar Omnidirectional

    GS1 DataBar Omnidirectional Default setting GS1 DataBar Omnidirectional Enable/Disable * Enable Disable GS1 DataBar Limited...

  • Page 68: Gs1 Databar Limited Enable/Disable

    Default setting GS1 DataBar Limited Enable/Disable * Enable Disable GS1 DataBar Expanded Default setting GS1 DataBar Expanded Enable/Disable * Enable Disable GS1 DataBar Expanded Length of information Read the following setup code to set the length of information. Minimum...
  • Page 69 and Maximum length is 4-74, Minimum length default=4, Maximum length default=74. Minimum message length Maximum message length...

  • Page 70: Pdf417 Enable/Disable

    PDF417 Default setting PDF417 Enable/Disable *Enable Disable PDF417 Length of information Read the following setup code to set the length of information. Minimum and Maximum length is 1-2750, Minimum length default=1, Maximum length default=2750. Minimum message length Maximum message length...

  • Page 71: Qr Code Enable/Disable

    QR Code Default setting QR Code Enable/Disable This option applies to both QR codes and Micro QR codes. * Enable Disable QR Code Length of information Read the following setup code to set the length of information. Minimum and Maximum length is 1-7089, Minimum length default=1, Maximum length default=7089 Minimum message length Maximum message length...

  • Page 72: Data Matrix Enable/Disable

    Data Matrix Default setting Data Matrix Enable/Disable * Enable Disable Data Matrix Length of information Read the following setup code to set the length of information. Minimum and Maximum length is 1-3116, Minimum length default=1, Maximum length default=3116. Minimum message length Maximum message length...

  • Page 73: Aztec Code Enable/Disable

    Aztec Code Default setting Aztec Code Enable/Disable * Enable Disable Aztec Code Length of information Read the following setup code to set the length of information. Minimum and Maximum length is 1-3832, Minimum length default=1, Maximum length default=3832. Minimum message length Maximum message length...

  • Page 74: Postal Codes - Linear

    Postal Codes - Linear Linear zip codes are listed below.Any combination of linear zip code selection is flexible. China Post (Hong Kong 2 of 5) Default setting China Post (Hong Kong 2 of 5) Enable/Disable Enable * Disable China Post (Hong Kong 2 of 5)Length of information Read the following setup code to set the length of information.

  • Page 75: Korea Post

    Korea Post Default setting (937000) Korea Post Enable/Disable (9370011) Enable (9370010) * Disable Korea Post Length of information Read the following setup code to set the length of information. Minimum and Maximum length is 2-80, Minimum length default=4, Maximum length default=48 (937003) Minimum message length (937002)

  • Page 76: Chapter 7 Factory Default Setting

    Korea Post check character This option allows you to specify whether the Transmission check character should be at the end of the scan data. Default =Do not transmission. (9370041) Transmission check character * Do not transmission check character Chapter 7 Factory default setting Show version number Scan the barcode below to output the current software version, cell serial number,...

  • Page 77: Reset Factory Defaults

    and other product information. Show the revised version Reset factory defaults This selection removes all settings and resets the scanner to original factory default value. It also disables all plug-ins. If you are unsure of the programming options in the scanner, or if you have changed some of the options and want to restore the scanner to factory default settings, scan “Remove custom default”...
  • Page 78 Appendix Reference charts Symbol graph Note: "m" represents the AIM modifier character. For detailed information on the DisableAIM modifier characters, refer to the international technical specification, symbolic identifiers. The prefix/suffix entry for a particular symbol system overrides the generic (all symbols, 99) entry. For information about Disable using code ID and AIM ID, refer to editing starting from page 4-1 Enable and data formatting starting from page 5-1 Enable.
  • Page 79 0, 1, 3, 4 EAN-13 (including Bookland EAN) EAN-13 with Add-On EAN-13 with Extended Coupon Code EAN-8 EAN-8 with Add-On...
  • Page 80 Optima Symbology Possible Modifiers （m） GS1 DataBar GS1 DataBar Limited GS1 DataBar Expanded GS1-128 2 of 5 China Post (Hong Kong 2 of Interleaved 2 of 5 0, 1, 3 Matrix 2 of 5 NEC 2 of 5 Straight 2 of 5 IATA 0, 1, 3 Straight 2 of 5 Industrial 0, 1...
  • Page 81 2D Symbologies Optima Symbology Possible Modifiers （m） All Symbologies Aztec Code 0-9, A-C Chinese Sensible Code (Han Xin Code) Codablock A 0, 1, 4, 5, 6 Codablock F 0, 1, 4, 5, 6 Code 49 0, 1, 2, 4 Data Matrix GS1 Composite GS1 DataBar Omnidirectiona...

  • Page 82: Postal Symbologies

    Postal Symbologies Optima Symbology Possible Modifiers （m） All Symbologies Australian Post British Post Canadian Post Optima Symbology Possible Modifiers （m） China Post InfoMail Intelligent Mail Bar Code Japanese Post KIX (Netherlands) Post Korea Post Planet Code Postal-4i Postnet...

  • Page 83: Ascii Conversion Chart (Code Page 1252)

    ASCII Conversion Chart (Code Page 1252) In keyboard applications, ASCII control characters can be represented in three different ways, as shown below.CTRL + X functionality depends on the operating system and the application.The following table lists some common Microsoft features.This table is suitable for American keyboards.Some characters may be different depending on the country/region code/PC locale.

  • Page 84: Lower Ascii Reference Table

    Non-printable Keyboard Control + ASCII (CTRL+X) Mode ASCII control characters Windows Mode Control + X Mode On (KBDCAS2) CTRL + X Control + X Mode Off Char CTRL + X (KBDCAS0) function CTRL+ K hyperlink list, Delete CTRL+ L left align Enter / Ret CTRL+ M Insert...
  • Page 85 Printable Characters (Continued) Character Character Character & < > ⌂ Extended ASCII Characters CP 1252 ASCII Alternate Extended Scan Code ↑ € Ç 0x48 up arrow ↓ ü 0x50 down arrow → ‚ é 0x4B right arrow ← ƒ â 0x4D left arrow „...
  • Page 86 Extended ASCII Characters (Continued) PS2 Scan CP 1252 ASCII Alternate Extended Code † å Home 0x47 ‡ ç 0x4F ˆ ê Page Up 0x49 ‰ ë Page Down 0x51 Š è Right ALT 0x38 ‹ ï Right CTRL 0x1D Œ î...
  • Page 87 Extended ASCII Characters (Continued) PS2 Scan CP 1252 ASCII Alternate Extended Code ¡ Control Break 0x9D ® « Alt Sequence with 1 Character 0x36 ¯ » Ctrl Sequence with 1 Character 0x1D ° ░ ± ▒ ² ▓ ³ │ ´...
  • Page 88 Extended ASCII Characters (Continued) PS2 Scan CP 1252 ASCII Alternate Extended Code Ô ╘ Õ ╒ Ö ╓ × ╫ Ø ╪ Ù ┘ Ú ┌ Û █ Ü ▄ Ý ▌ Þ ▐ ß ▀ à α á ß â...
  • Page 89 Extended ASCII Characters (Continued) PS2 Scan CP 1252 ASCII Alternate Extended Code û √ ü ⁿ ý ² þ ■ ÿ ISO 2022/ISO 646 Character Replacements Code pages defines the mapping of character code-to-character. If the received data does not display the correct characters, it may be because the barcode being scanned was created using a different Code pages from the host program expected.
  • Page 90 Japan ISO/IEC 646‐14 China ISO/IEC 646‐57 Great Britain (UK) ISO /IEC 646‐04 Optima Code Page Selection Standard Keyboard Method/Country Country Code Page Option France ISO /IEC 646‐69 Germany ISO/IEC646‐2 Switzerland ISO /IEC 646‐CH Sweden / ISO/IEC Finland 646‐11 (extended Annex C) Ireland ISO /IEC 646‐207...

  • Page 91: Unicode Key Maps

    35 36 124 125 23 24 à â ç ê î ô é ù è û à â ç ê É ô é ù è û ¥ ⎯ ¥ ⎯ £ ˜ £ à ° ç § µ é ù è...
  • Page 92 5A 5F 64 01 02 03 04 05 06 07 08 09 0A 0B 0C 0D 0F 4B 50 55 10 11 12 13 14 15 16 17 18 19 1A 1B 1C 1D 5B 60 65 4C 51 56 1E 1F 20 21 22 23 24 25 26 27 28 29 2B 5C 61 66 2C 2E 2F 30 31 32 33 34 35 36 37...

  • Page 93: Sample Symbols

    Sample Symbols UPC-A Interleaved 2 of 5 0 123456 7890 Code 128 1234567890 EAN-13 Code 128 Code 39 9 780330 290951 Codabar BC321 A13579B...
  • Page 94 Code 93 Straight 2 of 5 Industrial 123456-9$ 123456 Matrix 2 of 5 GS1 DataBar 6543210 PDF417 (01)0012345678901 Car Registration...
  • Page 95 Data Matrix QR Code Test Symbol Numbers 4-CB (4-State Customer Bar Code) 01,234,567094,987654321,01234567891 ID-tag (UPU 4-State) J18CUSA8E6N062315014880T Aztec Micro PDF417 Package Label MaxiCode Test Message Test Message Postnet Zip Code...

  • Page 96: Programming Chart

    Programming Chart...
  • Page 97 Save Discard Note: if an error occurs while scanning letters or numbers (before scanning Save), please scan Discard, scan the correct letters or numbers, and then save again.
